Page 106 of 388
INSTRUMENT CLUSTER
Meter cluster
1. Fuel gauge
2. Tachometer
3. Speedometer
4. Engine coolant temperature gauge
5. Odometer6. Trip odometer
7. Trip odometer reset button
D01A2700
106 INSTRUMENTS AND CONTROLS
Page 110 of 388
Odometer/Trip odometer
When the ignition switch is turned to the ªONº position,
an ªODOº or ªTRIPº indication is given.
Every time the reset button (3) is pressed lightly (less
than one second), the indicators will change from ªODOº
to ªTrip Aº to ªTrip Bº.
1. Odometer
2. Trip odometer
3. Reset buttonODO --- Odometer
The odometer indicates the total distance the vehicle has
travelled.
TRIP --- Trip odometer
The trip odometer indicates the distance traveled during
a particular trip or period.
As a feature, there are two trip odometer displays:
and.
Trip
can be used to measure the distance traveled
D03F0320
1D03F0120
110 INSTRUMENTS AND CONTROLS
Page 111 of 388
since the current trip began and Tripcan be used to
measure the distance from an intermediate location.
To return either Trip
or Tripdisplay to zero,
press the reset button (3) for more than one second. Only
the currently displayed value will be reset.
If Trip
is displayed, for example, only Tripwill
be reset.
NOTE
1. Display TRIPand TRIPeach have a maxi-
mum distance of 9999.9 mile (16 093.28 km)
2. When disconnecting the battery for a long time, the
memory of trip meter display
andwill clear,
and the display returns to ª0º.
Engine coolant temperature gauge
This gauge indicates the engine coolant temperature.
When the engine temperature is low, the indicator will
remain at the ªCº (cold) position. The indicator will
gradually rise as the engine is warmed up.
The indicator will normally stay near the center while
driving, but may rise slightly in congested traffic or when
the engine is under a heavy load.
D06A0600
INSTRUMENTS AND CONTROLS 111
4
Page 142 of 388

NGear positions........................156
NDriving speed
(Vehicles with automatic transaxle).........157
NHolding on an upgrade.................157
NTransaxle reset mode...................158
mAutomatic transaxle Autostick
(if so equipped)
........................158
NSelector lever operation.................159
NIndicator lights.......................161
NSelector positions (Main gate).............162
NSelector positions Manual gate Autostick.....163
NHolding on an upgrade.................165
NTransaxle reset mode...................166
mManual transaxle (if so equipped)..........166
NTo start.............................167
NProper shift points.....................167NRecommended downshifting speed.........169
NDriving precautions....................169
mParking brake.........................169
mBrake pedal...........................171
mPower brakes.........................172
mBrake pad wear alarm...................172
mAnti-lock braking (ABS) system
(if so equipped)
........................173
NGeneral driving hints
(standard/anti-lock brakes)...............173
mSteering wheel tilt lock lever..............175
mPower steering........................176
mInside Day/Night rearview mirrors.........177
NElectrochromic inside rearview mirror
(if so equipped.......................178
NElectrochromic mirror operation
(if so equipped).......................179
142 STARTING AND DRIVING
Page 158 of 388

Transaxle Reset Mode
The transaxle is monitored for abnormal conditions. If a
condition is detected that could cause damage, the trans-
axle automatically shifts into second gear. The transaxle
remains in second gear despite the forward gear selected.
Park (P), Reverse (R), and Neutral (N) will continue to
operate. This Reset feature allows the vehicle to be driven
to a dealer for service without damaging the transaxle.
If the problem has been momentary, the transaxle can be
reset to regain all forward gears.
²Stop the vehicle and shift into PARK (P).
²Turn the key to OFF then start the engine.
²Shift into ªDº and resume driving.
NOTE:Even if the transaxle can be reset, we recom-
mend that you visit a dealer at your earliest possible
convenience. Your dealer has diagnostic equipment to
determine if the problem could recur.
If the transaxle cannot be reset, dealer service is required.
AUTOMATIC TRANSAXLE AUTOSTICK
(IF SO EQUIPPED)
Designed for optimum control and equipped with adap-
tive control capabilities, the electronically controlled
transaxle optimally matches gear shifts to almost all
driving and road conditions.
DRIVING UPHILL
The transaxle may not upshift to a higher gear if the
computer determines the current speed cannot be main-
tained once a higher gear is engaged.
For smoother vehicle performance, if you release the
throttle while climbing a steep grade, the transaxle may
not upshift. This is normal, as the computer is controlling
the shifting. After reaching the top of the hill, normal gear
shift function will resume.
DRIVING DOWNHILL
When traveling down steep grades and depressing the
brake pedal, the computer may automatically select a
lower gear. This function assists engine braking efforts,
reducing the need to use the brakes.
158 STARTING AND DRIVING
Page 166 of 388

Transaxle Reset Mode
The transaxle is monitored for abnormal conditions. If a
condition is detected that could cause damage, the trans-
axle automatically shifts into second gear. The transaxle
remains in second gear despite the forward gear selected.
Park (P), Reverse (R), and Neutral (N) will continue to
operate. This Reset feature allows the vehicle to be driven
to a dealer for service without damaging the transaxle.
If the problem has been momentary, the transaxle can be
reset to regain all forward gears.
²Stop the vehicle and shift into PARK (P).
²Turn the key to OFF then start the engine.
²Shift into ªDº and resume driving.
NOTE:Even if the transaxle can be reset, we recom-
mend that you visit a dealer at your earliest possible
convenience. Your dealer has diagnostic equipment to
determine if the problem could recur.
If the transaxle cannot be reset, dealer service is required.
MANUAL TRANSAXLE (IF SO EQUIPPED)
The shift pattern is shown on the gearshift lever. Depress
the clutch pedal fully while shifting gears.
NOTE: During cold weather, shifting may be difficult/
stiff until the transaxle lubricant has warmed up. This is
normal and not a sign of a problem.
I29A0020
166 STARTING AND DRIVING
Page 207 of 388

NTuning.............................226
NBalance............................226
NFade..............................226
NTone Control........................226
NMODE Selection......................226
NPTY (Program Type) Selection.............226
NScan Button.........................226
NTo Set The Pushbutton Memory...........227
NTo Change From Clock To Radio Mode......227
NGeneral Information...................227
NOperating Instructions Ð CD Changer......227
NInserting the Compact Disc..............227
NSeek Button.........................228
NFF /Tune/ RW Button..................228
NRandom Play........................228
NRadio/CD Button.....................228NTime Button.........................228
NScan Button.........................228
NLoading The CD Changer...............228
NPlaying Discs........................229
NRemoving Discs From The CD Changer.....229
mSteering wheel remote control switches (if so
equipped)
...........................229
NHow to adjust the volume...............230
NTo listen to the audio system..............230
NTo listen to the radio...................230
NAutomatic tuning the radio...............230
NTo select the preset memory..............230
NTo listen to a tape.....................231
NTo listen to a CD......................231
NHandling of compact discs...............232
mRadio operation and cellular phones........234
FOR PLEASANT DRIVING 207
6
Page 229 of 388

Playing Discs
The radio display indicates the CD number (the slot
where the CD is loaded), and the current track being
played at the time.
If more than one CD is loaded in the CD changer, it
automatically plays the next CD after playing the last
track of the current CD. If there is only one CD loaded, it
will automatically return to the first track of the CD. To
play any available disc select the desired disc position
button.
Removing Discs from the CD Changer
1. Press the load/eject button then press the desired disc
position button to eject that CD.
2. The display will flash the disc number that is being
ejected.
3. If the disc is not removed from the unit within 15
seconds the disc will automatically re-load.
STEERING WHEEL REMOTE CONTROL
SWITCHES (IF SO EQUIPPED)
These switches can be used when the ignition switch is in
the ªONº position.
1. Seek up / Fast forward APS button / Track up button
2. Volume up button
3. Preset change / Disc up button
4. Mode change button
H12D0070
FOR PLEASANT DRIVING 229
