2004 DODGE STRATUS COUPE wiper fluid

NChanging the setting for warning operation . . . 118
NAutomatic transaxle indicator
(if so equipped).......................119
NTraction Control System warning light
(if so equipped).......................119
NWasher fluid level indicator..............119
mCombination headlights, dimmer and
turn signal lever
.......................120
NHeadlights..........................120
NLight auto-cutout feature
(headlights, fog lights, etc.)...............120
NWhen you want to keep the lights on
(time delay)..........................120
NHeadlight reminder chime...............121
NHeadlight flasher (high/low beam).........121
NDimmer (high/low beam change)..........122
NTurn signals..........................122
mFog light switch (if so equipped)...........123
mHazard warning flasher switch............124
mInstrument panel light dimmer control.......125
mElectric rear window defroster.............125
mWindshield wipers......................126
mIntermittent wipers.....................127
mWindshield washer.....................128
mPrecautions to observe when using wipers
and washers
..........................128
mDome light...........................129
mLights (dome lights, etc.) auto-cutout
function
.............................130
mReading lights.........................131
mRear personal lights.....................132
mHorn switch..........................132
mGarage door opener (if so equipped)........132
NTraining the Universal Transceiver..........133
104 INSTRUMENTS AND CONTROLS

WINDSHIELD WASHER
The windshield washer can be operated by pulling the
lever toward you to spray fluid when the ignition key is
in either the ªONº or ªACCº position.
When washer fluid is sprayed, the wipers will automati-
cally operate several times.
The spraying fluid stops when the lever is released.
PRECAUTIONS TO OBSERVE WHEN USING
WIPERS AND WASHERS
CAUTION!
If the washer is used in cold weather, the washer
fluid sprayed onto the glass might freeze, resulting
in poor visibility. Heat the glass with the defroster
before using the washer.
NOTE
1. Do not use the wipers when the glass is dry; this could
scratch the glass and wear the wiper blades prematurely.
2. Before operating the wipers in cold weather, check to
be sure that the wiper blades are not frozen to the
windshield. Attempting to operate the wipers while the
blades are frozen could damage the wiper motor.
3. If the wipers become blocked by ice or other deposits
on the glass, the motor may be damaged even if the
wiper switch is OFF. If obstruction occurs, park your
E13A1300
128 INSTRUMENTS AND CONTROLS

vehicle in a safe place, turn off the ignition, and clean the
deposits from the glass so that the wipers operate
smoothly.
4. Avoid using the washer for more than 20 seconds at a
time. To avoid pump damage, do not operate the washer
when the fluid reservoir is empty.
5. During cold weather, be sure to add a washer solution
that will not freeze in the washer reservoir. Failure to do
so could result in the loss of windshield washer function
and damage to the system components.
6. Replace wiper blades when they are worn to avoid
loss of visibility when in use. Use the appropriate size
replacement blades; if you have questions, ask your
authorized dealer.DOME LIGHT
The dome/reading light can be operated by moving the
switch as follows:
1. (ON) - The dome light ``ON''.
2. (DOOR) - The dome light goes on when any door is
opened.
3. (OFF) - The dome light stays ``OFF''.
E19A0970
Type 1
INSTRUMENTS AND CONTROLS 129
4

NDisconnection and connection.............325
mAutomatic transaxle.....................327
NTo check the fluid level..................328
NProcedure for checking the fluid level.......328
mManual transaxle.......................329
mDisc brake pads, rear drum brake linings
and rear wheel cylinders.................329
mBrake hoses...........................329
mBall joint, steering linkage seal and drive
shaft boots...........................329
mSupplemental Restraint System (SRS)........329
mDoor hinges, rear hatch hinges, hood lock
release mechanism and safety catch
.........330
mExhaust system........................330
mWindshield wiper blades.................331
NWindshield washers....................331
mParking brake.........................332
mDrive belt (for generator, water pump, power
steering pump)
........................333
mTiming belt...........................334
mTi re s................................334
NTire inflation pressures..................334
NRadial ply tires.......................336
N
Tire pressure for sustained high-speed driving...336
NOversize tires........................336
NTire maintenance......................337
NCargo loads..........................337
NTread wear indicators...................337
NTire rotation.........................338
NTire chains...........................339
NSnow tires...........................339
mRegular Maintenance Schedule.............340
mSevere Maintenance Schedule..............349
310 MAINTENANCE

WINDSHIELD WIPER BLADES
Check the wiper blades occasionally. Periodic cleaning of
the wiper blades is suggested to remove the accumula-
tion of salt and road film. The wiper blade arms and glass
areas should be cleaned with a sponge or cloth and a
mild detergent or non-abrasive cleaner.
If the blades continue to streak or smear, they should be
replaced.
NOTE: Do not operate wipers for long periods on dry
glass; this accelerates deterioration of the rubber and
could scratch the glass.
Windshield washers
The windshield washer reservoir is in the engine com-
partment. Check the fluid level at regular intervals and
replenish the fluid if necessary.
NOTE: When freezing weather is anticipated flush out
the water in the reservoir by operating the pump. Fill the
reservoir with windshield antifreeze (not radiator anti-
freeze) and operate the system for a few seconds to flush
out any residual water.
M31A0730
MAINTENANCE 331
9

Snow tires.......................... 339
Spare tire........................... 266
Tire chains.......................... 339
Tread wear indicators.................. 337
Tools................................ 266
Towing.............................. 284
Trailering........................... 203
Trailer Towing......................... 203
Transaxle
Automatic transaxle................... 153
Autostick........................... 163
Manual transaxle..................... 166
Transmission
Automatic transmission................ 158
Transmitter, Garage Door Opener........... 132
Transporting Pets....................... 102
Trip odometer......................... 106
Trip odometer reset button................ 106
Trunklid .............................. 35
Turbocharger boost gauge................ 106
Turn signal indicators.................107,112
Lever.............................. 122Uniform Tire Quality Grades.............. 379
Universal Transmitter.................... 132
Vanity mirror.......................... 209
Vehicle Identification Number............... 5
Vehicle labeling........................ 364
Vehicle Weights........................ 367
Ventilators............................ 235
Warnings and Cautions.................... 5
Warranty Information.................... 374
Washer fluid level indicator............... 107
Washer
Windshield.......................128,331
Washing.............................. 255
Waxing.............................. 257
Wheel covers.......................... 268
Whip antenna......................... 219
Windshield washers..................128,331
Windshield wiper blades................. 331
Windshield wipers...................... 126
388 INDEX
