2004 CHRYSLER PACIFICA spark plugs replace

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
48,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-10-01 3N.
Maint enance Service Sc hedule ÒBÓ
48,0 00 km
l Ch ange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
lInspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, PT Cruiser, SRT-4, and SX 2.0 only).
l Replace the engine air cleaner filter if required (all models).
l Replace the spark plugs (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0 and 2.4L Minivan only).
l Check and replace, if necessary, the PCV valve.
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only)
l Adjust the generator belt tension (PT Cruiser and SRT-4 only).
l Adjust the generator belt tension (SX 2.0 only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Change the all-wheel drive power transfer unit fluid.*
l Rotate tires a nd check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4 and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is used for trailer tow, taxi, police or other types of
commercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 49

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
lInspect the engine air cleaner filter and replace if necessary(Sebring, Sebring Convertible, PT Cruiser, SRT-4 and SX 2.0 only).
l Replace the engine air cleaner filter if required (all models).
l Replace the spark plugs (PT Cruiser, SRT-4, Sebring, SebringConvertible, SX 2.0 and 2.4L Minivan only).
l Check and replace, if necessary, the PCV valve.
l Inspect and replace, if required, the make-up air filter locatedinside the air cleaner (PT Cruiser and SX 2.0 only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only)
l Adjust the generator belt tension (PT Cruiser and SRT-4 only).
l Adjust the generator belt tension (SX 2.0 only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Change the all-wheel drive power transfer unit fluid.*
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4 and SX 2.0 only)
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if thevehicle is used for trailer tow, taxi, police or other types of commercial service.
Maint enance Service Sc hedule ÒBÓ
48,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 50

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
96,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-20-01 3N.
Maint enance Service Sc hedule ÒBÓ
96,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Replace the engine air cleaner filter, if required (all models).
l Replace the ignition cables (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0, and 2.4L Minivan only).lReplace the spark plugs (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0, and 2.4L Minivan only).
l Check and replace, if necessary, the PCV valve.
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and 3.3L/3.8L Minivan only).
l Replace drive belts (Concorde, Intrepid, and 300M only).
l Adjust the generator belt tension (PT Cruiser and SRT-4 only).
l Replace the drive belts (SX 2.0 only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Replace the accessory drive belts (2.7L Sebring, Sebring Convertible only).
l Replace power steering fluid (Concorde, Intrepid, and 300M only).
l Change the all-wheel-drive power transfer unit fluid.*
l Change the automatic transaxle fluid and filter. **
l Replace the air conditioning filter (Pacifica and Minivan, if equipped).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4, and SX 2.0 only).
l Inspect the front and rear brake linings and components (Sebring, Sebring Convertible, PT Cruiser, and SRT-4 only).
l Inspect the brake hoses.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses, and clamps.
l Inspect the exhaust system.
* All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is used for trailer tow, taxi, police or other types of commercial service.
** Change the automatic transmission fluid and filter every 96,000 km if the vehicle is used for trailer tow, taxi, police orother types of commercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 69

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
Maint enance Service Sc hedule ÒBÓ
96,0 00 kmlChange engine oil and engine oil filter (or every 3 months).lInspect and lubricate, as required, all steering and suspension components. lReplace the engine air cleaner filter, if required (all models). lReplace the ignition cables (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0, and 2.4L Minivan only).
lReplace the spark plugs (PT Cruiser, SRT-4, Sebring, Sebring Convertible,SX 2.0, and 2.4L Minivan only).
lCheck and replace, if necessary, the PCV valve.lInspect and replace, if required, the make-up air filter located inside the aircleaner (PT Cruiser and SX 2.0 only).
lInspect the serpentine drive belt, replace if necessary (Pacifica and3.3L/3.8L Minivan only) .
l
Replace drive belts (Concorde, Intrepid, and 300M only).lAdjust the generator belt tension (PT Cruiser and SRT-4 only).l Replace the drive belts (SX 2.0 only).
lCheck and retention power steering pump belt (2.4L Minivan only).lCheck the generator belt, replace if necessary (2.4L Minivan only).lReplace the accessory drive belts (2.7L Sebring, Sebring Convertible only).lReplace power steering fluid (Concorde, Intrepid, and 300M only).lChange the all-wheel-drive power transfer unit fluid.*lChange the automatic transaxle fluid and filter. **lReplace the air conditioning filter (Pacifica and Minivan, if equipped).lRotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4, and SX 2.0 only).
l Inspect the front and rear brake linings and components (Sebring,Sebring Convertible, PT Cruiser, and SRT-4 only).
l Inspect the brake hoses.
l Check the manual transaxle fluid level and fill plug condition (if equipped).lCheck the coolant level, hoses, and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if thevehicle is used for trailer tow, taxi, police or other types of commercial service.
** Change the automatic transmission fluid and filter every 96,000 km if the vehicle is used for trailer tow, taxi, police or other types of commercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 70

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
120,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-25-01 3N.
Maint enance Service Sc hedule ÒBÓ
120,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, PT Cruiser, SRT-4, and SX 2.0 only).
l Replace the engine air cleaner filter, if required (Pacifica, Minivan, Concorde, Intrepid, and 300M only).
l Replace the ignition cables (3.3L and 3.8L Minivan only).
l Replace the spark plugs (Pacifica and 3.3L/3.8L Minivan only).
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and 3.3L/3.8L Minivan only).
l Adjust the drive belt tension (Concorde, Intrepid, and 300M only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Change the all-wheel-drive power transfer unit fluid.*
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is used for trailer tow, taxi, police or other
types of commercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 79

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary(Sebring, Sebring Convertible, PT Cruiser, SRT-4, and SX 2.0 only).
l Replace the engine air cleaner filter, if required (Pacifica, Minivan, Concorde, Intrepid, and 300M only).
l Replace the ignition cables (3.3L and 3.8L Minivan only).
l Replace the spark plugs (Pacifica and 3.3L /3.8L Minivan only).
l Inspect and replace, if required, the make-up air filter locatedinside the air cleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and 3.3L/3.8L Minivan only).
l Adjust the drive belt tension (Concorde, Intrepid, and 300M only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Change the all-wheel-drive power transfer unit fluid.*
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if thevehicle is used for trailer tow, taxi, police or other types of commercial service.
Maint enance Service Sc hedule ÒBÓ
120,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 80

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
144,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-30-01 3N.
Maint enance Service Sc hedule ÒBÓ
144,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Replace the engine air cleaner filter, if required (all models).
l Replace the spark plugs (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0, and 2.4L Minivan only).
l Check and replace, if necessary, the PCV valve.
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and 3.3L /3.8L Minivan only).
l Adjust the drive belt tension (Concorde, Intrepid, and 300M only).
l Adjust the generator belt tension (PT Cruiser and SRT-4 only).
l Adjust the generator belt tension (SX 2.0 only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Replace the engine timing belt (SX 2.0, SRT-4, 2.4L Minivan, Sebring, Sebring Convertible, and PT Cruiser only).
l Change the all-wheel-drive power transfer unit fluid.*
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4, and SX 2.0 only).
l Inspect the front and rear brake linings and components (Pacifica, Minivan, Concorde, Intrepid, 300M, and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses, and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is used for trailer tow, taxi, police or other types of commercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 89

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Replace the engine air cleaner filter, if required (all models).
l Replace the spark plugs (PT Cruiser, SRT-4, Sebring, SebringConvertible, SX 2.0, and 2.4L Minivan only).
l Check and replace, if necessary, the PCV valve.
l Inspect and replace, if required, the make-up air filter locatedinside the air cleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and 3.3L /3.8L Minivan only).
l Adjust the drive belt tension (Concorde, Intrepid, and 300M only).
l Adjust the generator belt tension (PT Cruiser and SRT-4 only).
l Adjust the generator belt tension (SX 2.0 only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Replace the engine timing belt (SX 2.0, SRT-4, 2.4L Minivan,Sebring, Sebring Convertible, and PT Cruiser only).
l Change the all-wheel-drive power transfer unit fluid.*
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4, and SX 2.0 only).
l Inspect the front and rear brake linings and components (Pacifica, Minivan, Concorde, Intrepid, 300M, and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses, and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if thevehicle is used for trailer tow, taxi, police or other types of commercial service.
Maint enance Service Sc hedule ÒBÓ
144,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 90
