Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
158,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-33-01 3N.
Maint enance Service Sc hedule ÒBÓ
158,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, Concorde, Intrepid, 300M, Pacifica, and Minivan only).
l Replace the spark plugs (2.7L Sebring and Sebring Convertible only).
l Replace the spark plugs (Concorde, Intrepid and 300M only).
l Flush and replace engine coolant at 60 months or 160,000 kilometres.
l Replace the accessory drive belts (2.4L Sebring and Sebring Convertible only).
l Replace the engine timing belt (Concorde, Intrepid and 300M only).
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Pacifica, Minivan, Concorde, Intrepid, 300M, and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 95

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, Concorde, Intrepid, 300M,Pacifica, and Minivan only).
l Replace the spark plugs (2.7L Sebring and Sebring Convertibleonly).
l Replace the spark plugs (Concorde, Intrepid and 300M only).
l Flush and replace engine coolant at 60 months or 160,000 kilometres.
l Replace the accessory drive belts (2.4L Sebring and Sebring Convertible only).
l Replace the engine timing belt (Concorde, Intrepid and 300M only).
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Pacifica, Minivan, Concorde, Intrepid, 300M, and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition(if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
158,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 96

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
192,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-40-01 3N.
Maint enance Service Sc hedule ÒBÓ
1 92,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Replace the engine air cleaner filter, if required (all models).
lReplace the ignition cables (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0, and 2.4L Minivan only).l Replace the spark plugs (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0, and 2.4L Minivan only).
l Check and replace, if necessary, the PCV valve.
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and 3.3L/3.8L Minivan only).lReplace drive belts (Concorde, Intrepid, and 300M only).
l Adjust the generator belt tension (PT Cruiser and SRT-4 only).
l Replace the drive belts (SX 2.0 only).lCheck and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Replace the accessory drive belts (2.7L Sebring, Sebring Convertible only).
l Replace power steering fluid (Concorde, Intrepid, and 300M only).
l Change the all-wheel-drive power transfer unit fluid.
*lChange the automatic transaxle fluid and filter. **lReplace the air conditioning filter (Pacifica and Minivan if equipped).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4, and SX 2.0 only).
l Inspect the front and rear brake linings and components (Sebring, Sebring Convertible, PT Cruiser, and SRT-4 only).
l Inspect the brake hoses.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is used for trailer tow, taxi, police or other types of commercial service.
**Change the manual transmission fluid and filter every 96,000 km if the vehicle is used for trailer tow, taxi, police orother types of commercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 109

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Replace the engine air cleaner filter, if required (all models).
l Replace the ignition cables (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0, and 2.4L Minivan only).
l Replace the spark plugs (PT Cruiser, SRT-4, Sebring, Sebring Convertible,SX 2.0, and 2.4L Minivan only).
l Check and replace, if necessary, the PCV valve.
l Inspect and replace, if required, the make-up air filter located inside the aircleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and3.3L/3.8L Minivan only).
l Replace drive belts (Concorde, Intrepid, and 300M only).
l Adjust the generator belt tension (PT Cruiser and SRT-4 only).
l Replace the drive belts (SX 2.0 only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Replace the accessory drive belts (2.7L Sebring, Sebring Convertible only).
l Replace power steering fluid (Concorde, Intrepid, and 300M only).
l Change the all-wheel-drive power transfer unit fluid. *
l Change the automatic transaxle fluid and filter. **
l Replace the air conditioning filter (Pacifica and Minivan if equipped).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: lInspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4, and SX 2.0 only).
l Inspect the front and rear brake linings and components (Sebring,Sebring Convertible, PT Cruiser, and SRT-4 only).
l Inspect the brake hoses.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluidmust be changed at more frequent intervals than shown in Schedule B if thevehicle is used for trailer tow, taxi, police or other types of commercial service.
** Change the manual transmission fluid and filter every 96,000 km if the vehicle isused for trailer tow, taxi, police or other types of commercial service.
Maint enance Service Sc hedule ÒBÓ
1 92,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 110

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
240,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-50-01 3N.
Maint enance Service Sc hedule ÒBÓ
240,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Replace the engine air cleaner filter, if required (all models).
l Replace the spark plugs (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0, and 2.4L Minivan only).
l Replace the Ignition cables (3.3L and 3.8L Minivan only).
l Replace the spark plugs (Pacifica and 3.3L/3.8L Minivan only).
l Check and replace, if necessary, the PCV valve.
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and 3.3L/3.8L Minivan only).
l Adjust the drive belt tension (Concorde, Intrepid, and 300M only).
l Adjust the generator belt tension (PT Cruiser and SRT-4 only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Change the all-wheel-drive power transfer unit fluid.*
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4, and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses, and clamps.
l Inspect the exhaust system.
* All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in schedule B if the vehicle is used for trailer tow, taxi, police or other types ofcommercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 129

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Replace the engine air cleaner filter, if required (all models).
l Replace the spark plugs (PT Cruiser, SRT-4, Sebring, Sebring Convertible,SX 2.0, and 2.4L Minivan only).
l Replace the ignition cables (3.3L and 3.8L Minivan only).
l Replace the spark plugs (Pacifica and 3.3L/3.8L Minivan only).
l Check and replace, if necessary, the PCV valve.
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and3.3L/3.8L Minivan only).
l Adjust the drive belt tension (Concorde, Intrepid, and 300M only).
l Adjust the generator belt tension (PT Cruiser and SRT-4 only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Change the all-wheel-drive power transfer unit fluid.*
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4, and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses, and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if thevehicle is used for trailer tow, taxi, police or other types of commercial service.
Maint enance Service Sc hedule ÒBÓ
240,0 00 km
