Rocking Your Vehicle To Get It Out
First, turn your steering wheel left and right. That will
clear the area around your front wheels. If your vehicle
has traction control, you should turn the traction
control system off. SeeTraction Control System (TCS)
on page 4-11. Then shift back and forth between
REVERSE (R) and a forward gear (or with a manual
transmission, between FIRST (1) or SECOND (2)
and REVERSE (R)), spinning the wheels as little as
possible. Release the accelerator pedal while you shift,
and press lightly on the accelerator pedal when the
transmission is in gear. By slowly spinning your wheels
in the forward and reverse directions, you will cause
a rocking motion that may free your vehicle. If that does
not get you out after a few tries, you may need to be
towed out. If you do need to be towed out, seeTowing
Your Vehicle on page 4-31.
Using the Tow Hooks
If your vehicle has tow hooks, the hooks are provided at
the front and, on some models, the rear of your
vehicle. You may need to use them if you are stuck
off-road and need to be pulled to some place where you
can continue driving.
4-30

Rear Axle
When to Check and Change Lubricant
Refer to the Maintenance Schedule to determine
how often to check the lubricant and when to change it.
SeeScheduled Maintenance on page 6-5.
How to Check Lubricant
To get an accurate reading, the vehicle should be on a
level surface.
If the level is below the bottom of the filler plug hole,
you’ll need to add some lubricant. Add enough lubricant
to raise the level to the bottom of the filler plug hole.
What to Use
Refer to the Maintenance Schedule to determine what
kind of lubricant to use. SeePart C: Recommended
Fluids and Lubricants on page 6-29.
Rear Axle Shift Motor
When to Check and Change Fluid
If you have an optional air-shift two-speed, controlled
traction, or locking differential type rear axle, a good time
to check the fluid level in the axle shift motor is when
the rear axle lubricant is checked. Use refrigerant
oil (shift motor only).
How to Check Fluid
Remove the plug on the front plate of the axle shift
motor, add enough fluid to raise the level to the bottom
of the filler plug hole, then replace the plug.
What to Use
Refer to your Maintenance Schedule to determine what
kind of lubricant to use. SeePart C: Recommended
Fluids and Lubricants on page 6-29.
5-61

Storage Areas................................................2-41
Center Console Storage Area........................2-42
Stuck in Sand, Mud, Ice or Snow......................4-29
Sun Visors.....................................................2-10
Switchbanks, Instrument Panel..........................3-16
T
Tachometer....................................................3-26
Theft-Deterrent, Radio.....................................3-57
Theft-Deterrent Systems...................................2-10
Tilt Wheel........................................................ 3-7
Tire Inflation Check.........................................6-24
Tires.....................................................5-68, 5-82
Changing a Flat Tire....................................5-76
Dual Tire Operation.....................................5-69
If a Tire Goes Flat.......................................5-75
Inflation - Tire Pressure................................5-68
Rims and Wheels........................................5-69
Tightening the Wheel Nuts............................5-71
Wheel Alignment and Tire Balance.................5-70
Wheel Replacement.....................................5-74
When It Is Time for New Tires......................5-70
To Use the Engine Coolant Heater....................2-24
Top Strap......................................................1-38
Towing
Power Take-Off (PTO)..................................4-36
Your Vehicle...............................................4-31Traction
Control System (TCS)..................................4-11
Tractor Protection (Breakaway) Valve Check.......6-28
Trailer
Connections................................................4-35
Trailer Brake Hand Control Valve........................ 4-9
Trailer Connections
(C7/C8 Models Only)...................................4-36
Transmission
Fluid, Automatic...........................................5-31
Fluid, Manual..............................................5-32
Service Warning Light..................................3-31
Temperature Gage.......................................3-40
Transmission Fluid Capacity.............................5-98
Transmission Operation, Automatic....................2-28
Transmission Operation, Manual........................2-30
Trip Odometer................................................3-25
Turn and Lane-Change Signals.......................... 3-8
Turn Signal/Multifunction Lever........................... 3-7
Two-Speed Rear Axle......................................2-33
Two-Speed Rear Axle Electric Shift Control.........2-26
U
Underbody Flushing Service.............................6-28
Underbody Inspection......................................6-28
Underhood Fuse Block....................................5-91
Understanding Radio Reception........................3-57
