2004.5 Peugeot 307 CC Dag Owner's Manual

88
30-08-2004
89
30-08-2004
YOUR 307 CC IN DETAIL
BOOT
Opening the boot
F Press and hold button B on the
remote control to partially open
the boot, or press button
C on the
boot.
Closing the boot
F Use the interior grab handles to
close the boot.
F Press the centre of the boot with
both hands until it locks.
To protect the boot against theft, but-
ton
C can be disarmed. Turn the lock D a quarter of a turn to the right using
the key.
The boot can only be opened using
the remote control.
If the "automatic central locking" func-
tion is activated (see corresponding
section), the boot locks automatically
when the vehicle is being driven at
6 mph (10 km/h).
To unlock it, press button
A, with the
key in the ignition [speed less than
6 mph (10 km/h)].
Automatic central locking
The doors and the boot lock auto-
matically when driving [speed great-
er than 6 mph (10 km/h)].
Above 6 mph (10 km/h), a brief press
on button
A momentarily unlocks the
doors.
You can activate or disarm this function.
Locking/Unlocking from the
inside
Pressing button A permits:
- locking of the vehicle,
- unlocking of the vehicle (and in par- ticular the boot) if you place the key
in the switch.

90
30-08-2004
91
30-08-2004
YOUR 307 CC IN DETAIL
Activation
Press and hold button A.
Activation of the function is accom-
panied by an audible signal and the
message
"Automatic door locking
activated" on the multi-function dis-
play. The message re-appears each
time the vehicle is started.
Disarming
Press and hold button A.
"Door open" or "boot open"
warnings
With the key in the accessories po-
sition, the ignition on or when the
engine is running [speed less than
3 mph (5 km/h)], if a door or the
boot is not closed correctly, you are
warned by a diagram on the multi-
function display for a few seconds.
In addition, when the vehicle is moving,
the courtesy lights lash.
LOCKING/UNLOCKING WITH
A BATTERY FAILURE
Driver's door
Insert the key in the lock to lock or
unlock the door.
Passenger's door
- to lock, insert the key in the lock (located on the edge of the door)
then turn
an eighth of a turn to the
right.
- to unlock, use the interior door opening control (see correspond-
ing section).
Boot
The boot is locked, contact a PEUGEOT
dealer.
Notes
If one of the doors is open, the au-
tomatic central locking and locking
from the inside do not function.
If the boot is open, the automatic
central locking of the doors is active.

92
30-08-2004
93
30-08-2004
YOUR 307 CC IN DETAIL
THE RETRACTABLE ROOF
Before operating the roof:
F It is advisable to park the vehicle
on horizontal ground, it is possi-
ble to carry out the operation at a
speed below 6 mph (10 km/h).
F Ensure that the screen
1 is hooked
on (no object must be placed on
the screen or on the hinged covers
2; if there is luggage in the boot,
this must not push the screen up-
wards).
F Check that no object has been
placed on the rear parcel shelf.
F Close the boot correctly.
F Turn the ignition switch to the
ac-
cessories or running position
(1st or 2nd notch). It is advisable
to carry out the operation with the
engine running.
Opening the roof:
F Carry out the preparatory opera-
tions, indicated opposite.
F Then,
pull switch 3 until the roof
opening operation is complete,
conirmed by an audible signal. When carrying out this manoeuvre,
the four windows lower, the boot
opens, the hinged covers unfold,
the roof folds up and stores itself in
the boot, the moving shelf positions
itself, then the boot closes.
Notes: if you continue to pull button 3 once the cycle is complete, the four
windows rise again.
The control buttons for the windows
become operational again at the end
of the roof operation.

92
30-08-2004
93
30-08-2004
YOUR 307 CC IN DETAIL
In the case of an electric or hydraulic
malfunction of the roof, it is possible
to close the roof manually.
Please consult the breakdown
procedure described at the end of
this handbook.
Closing the roof:
F Carry out the preparatory opera-
tions, indicated on the previous
page.
F Then,
press button 3 until the roof
closing operation is complete,
conirmed by an audible signal. When carrying out this manoeuvre,
the four windows lower, the boot
opens, the moving shelf and the roof
unfold and position themselves, the
hinged covers fold, then the boot
closes.
Note: if you continue to press button 3 once the cycle is complete, the four
windows rise again.
The control buttons for the windows
become operational again at the end
of the roof operation. During roof opening and
closing operations, to
avoid any risk of injury,
ensure that there is no-
one in the proximity of the moving
parts.
After rain or washing the vehicle, it
is advisable to wait for the roof to
dry before opening it.
Operation of the roof is the sole
responsibility of the driver.
To guarantee correct operation,
do not release button 3 when
the roof is in an intermediate po-
sition (neither completely open
or closed). However, in the event
of danger, release the control
knob and the operation will stop
instantly. Once the danger has
been eliminated, complete the
operation.

90
30-08-2004
91
30-08-2004
YOUR 307 CC IN DETAIL
OPENING THE BONNET
From inside: push the handle on the
left-hand side under the fascia.
From outside: lift the catch and
raise the bonnet.
The engine must be switched off
when illing with fuel.
F Open the fuel iller lap.
F Insert the key then turn it to the left.
F Remove the cap and hang it on
the hook located on the inside of
the lap.
A label afixed to the inside of the fuel
iller lap indicates which type of fuel
to use.
When you ill your tank, do not con-
tinue after the third cut-off of the
pump. This could cause your vehicle
to malfunction.
FILLING WITH FUEL
Low fuel level
Bonnet strut
Secure the strut to hold the bonnet
open.
Before closing the bonnet, replace
the strut in its housing.
To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is properly locked.
When the minimum fuel
level in the tank is reached,
this warning light comes on.
You can still drive approximately
30 miles (50 km).
Flashing of the warning light indicates
a malfunction of the fuel gauge.
Contact a PEUGEOT dealer.
The capacity of the tank is
approximately 60 litres.
F After filling the tank, lock the cap
and close the fuel filler flap.

94
30-08-2004
95
30-08-2004
YOUR 307 CC IN DETAIL
THE LIGHTS STALK
Front and rear lights
Selection is by turning ring A.
Dipped/Main beam change
Pull the stalk towards you.
Note: with the ignition off, if the driv-
er's door is open, a buzzer sounds if
you have left your lights on.
Note: when the lights are switched
off automatically or when the dipped
headlamps are switched off manu-
ally, the front fog lamps, the rear fog
lamp and the side lights will remain
on (turn the ring backwards to switch
off the front fog lamps. The side lights
will then be switched off).
Lights off
Side lights
Dipped/main beam head-
lamps
Automatic switching on
of lights Front fog lamps (1st forwards
turn of the ring).
The front fog lamps operate with the
side lights and dipped headlamps.
When the main beam headlamps are
switched on, the front fog lamps are switched
off. They are switched on again when the
main beam headlamps are switched off.
Front fog lamps and rear fog
lamp
Rotate the ring B forwards to switch
on and backwards to switch off. The
status is conirmed by the light on the
instrument panel.
In good or rainy weather,
both day and night, the
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
Do not forget to switch them off
when they are no longer needed.
Front fog lamps and
rear fog lamp (2nd for-
wards turn of the ring).
Note: to switch off the rear fog lamp
and the front fog lamps, turn the ring
twice backwards.

94
30-08-2004
95
30-08-2004
YOUR 307 CC IN DETAIL
"Follow me home" lighting
In poor light or at night, if you leave
your vehicle, the side lights and
dipped headlamps can be left on for
approximately one minute.
To do this:
- place the key in the
STOP position,
- place the lights stalk in the
0 position,
- lash the headlamps,
- get out of the vehicle and lock it.
AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automati-
cally if the light is poor and when the
windscreen wipers operate continu-
ously and switch off when the light
becomes bright enough or the wind-
screen wipers are switched off.
In foggy weather or in snow, the
brightness sensor can detect sufi-
cient light, the lights will not come
on automatically.
This function is active when the vehi-
cle is supplied to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Place the lights stalk in the
AUTO/0
position,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights.
Operating check
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
Direction indicators (lashers)
Left:
downwards.
Right: upwards.
Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
lighting controls, the function is tem-
porarily disarmed.
If the brightness sensor does not
function correctly, the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Contact a PEUGEOT dealer.

94
30-08-2004
95
30-08-2004
YOUR 307 CC IN DETAIL
"Follow me home" lighting
In poor light or at night, if you leave
your vehicle, the side lights and
dipped headlamps can be left on for
approximately one minute.
To do this:
- place the key in the
STOP position,
- place the lights stalk in the
0 position,
- lash the headlamps,
- get out of the vehicle and lock it.
AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automati-
cally if the light is poor and when the
windscreen wipers operate continu-
ously and switch off when the light
becomes bright enough or the wind-
screen wipers are switched off.
In foggy weather or in snow, the
brightness sensor can detect sufi-
cient light, the lights will not come
on automatically.
This function is active when the vehi-
cle is supplied to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Place the lights stalk in the
AUTO/0
position,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights.
Operating check
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
Direction indicators (lashers)
Left:
downwards.
Right: upwards.
Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
lighting controls, the function is tem-
porarily disarmed.
If the brightness sensor does not
function correctly, the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Contact a PEUGEOT dealer.
