2004.5 PEUGEOT 206 Owners Manual

96 -
31-01-2005
97
-
31-01-2005
THE DOORS
The front doors
The rear doors (206 SW)
Opening the doors from outside Opening the doors from inside
Locking from inside
"Door open" warning
With the engine running
, you are
warned if a door is not shut properly
by an audible signal and a message
or graphic on the multifunction dis-
play, indicating the door in question.
When the vehicle is moving , if
the courtesy light button is in the
"lighting on opening a door" position,
the courtesy light lashes.
Without central locking
To lock, press button A. The button
locks the door in question.
The button on the driver's door locks
the door, the tailgate and the rear
screen (206 SW).
With central locking
To lock, press button A.
Locking one of the front doors locks
the front and rear doors, the tailgate
and the rear screen (206 SW).
On the rear doors, the button only
locks the door in question.
Unlocking from inside
To unlock, pull button A or operate
the handle.
Accesses

98 -
31-01-2005
99
-
31-01-2005
CHILD SAFETY LOCK
On each rear door this prevents
opening of the door from the inside.
Turn switch 1 a quarter turn using the
ignition key.
Locking/Unlocking from the
inside*
Pressing button
A permits locking/
unlocking of the doors. To switch on
Press and hold button
A.
Activation of the function is accompa-
nied by an audible signal and a mes-
sage on the multi-function display.
The message is displayed each time
the vehicle is started.
* According to speciication.
To switch off
Press and hold button
A.
Notes: if one of the doors is open,
locking from the inside and automatic
central locking are not possible.
If the boot is open, automatic central
locking of the doors is active.
Automatic central locking of the
doors
The doors can lock automatically
when you are driving (at a speed of
more than 6 mph (10 km/h)).
Above 6 mph (10 km/h), press button
A briely to unlock the doors tempo-
rarily.
You can activate or deactivate this
function.
Accesses

98 -
31-01-2005
99
-
31-01-2005
LOCKING/UNLOCKING OF
THE TAILGATE (saloon)
Without central locking:
To lock, turn the key from A to C.
To open, turn the key from A to B,
press the handle then lift the tailgate.
LOCKING/UNLOCKING OF
THE TAILGATE AND REAR
SCREEN (206 SW)
It is not possible to open the tail-
gate and the rear screen simulta-
neously.
With central locking
Locking or unlocking of the tailgate is
simultaneous with the doors.
With the rear screen closed, to open
the tailgate , operate the handle A
and lift the tailgate.
With the tailgate closed, to open
the rear screen , press and hold the
remote control unlocking button or
operate the handle B, then lift the
rear screen using the windscreen
wiper arm (location C).
Without central locking
The tailgate and rear screen are
locked or unlocked via the driver's
door lock.
With the rear screen closed, to open
the
tailgate , operate the handle A
and lift the tailgate.
With the tailgate closed, to open the
rear screen , operate the handle B,
then lift the rear screen using the
windcsreen wiper arm (location C).
With central locking:
Locking and unlocking of the tailgate
is simultaneous with the doors.
The lighting is activated on opening
the tailgate.
Accesses

100 -
31-01-2005
101
-
31-01-2005
The lighting is activated on open-
ing the tailgate or the rear screen.
Notes: the tailgate and the rear
screen lock automatically while driving
(above 6 mph (10 km/h)) and unlock
when one of the doors is opened.
When the rear windscreen wiper is
in a wiping position, the rear screen
can only be opened at the end of the
cycle.
Close the rear screen using the wind-
screen wiper arm or by pressing the
centre of the glass.
While driving , if the tailgate
or the rear screen is not
properly closed, the courtesy
light lashes if the button is in
this position.
TAILGATE RELEASE (saloon)
This enables the tailgate to be un-
locked in the event of a central locking
fault:
- Fold back the rear seats to gain access to the boot from inside the
vehicle,
- Pull the tailgate trim to release it,
- Pull the opening catch 1 upwards.
SUNROOF (saloon)
To open
Press part B of the switch. The roof
will open in the intermediate (comfort)
position.
To open the roof completely, press
part B again.
Panoramic sunroof screen
To move it to your chosen position,
press part A or B of the switch.
"Tailgate/rear screen open"
warning
With the engine running
, if the tail-
gate or the rear screen is not properly
closed, you are warned by an audible
signal and a message or a diagram
on the multifunction display.
To close
Press part A of the switch, the roof
will close in the intermediate (comfort)
position.
To close the roof completely, press
part A again.
Accesses

100 -
31-01-2005
101
-
31-01-2005
The lighting is activated on open-
ing the tailgate or the rear screen.
Notes: the tailgate and the rear
screen lock automatically while driving
(above 6 mph (10 km/h)) and unlock
when one of the doors is opened.
When the rear windscreen wiper is
in a wiping position, the rear screen
can only be opened at the end of the
cycle.
Close the rear screen using the wind-
screen wiper arm or by pressing the
centre of the glass.
While driving , if the tailgate
or the rear screen is not
properly closed, the courtesy
light lashes if the button is in
this position.
TAILGATE RELEASE (saloon)
This enables the tailgate to be un-
locked in the event of a central locking
fault:
- Fold back the rear seats to gain access to the boot from inside the
vehicle,
- Pull the tailgate trim to release it,
- Pull the opening catch 1 upwards.
SUNROOF (saloon)
To open
Press part B of the switch. The roof
will open in the intermediate (comfort)
position.
To open the roof completely, press
part B again.
Panoramic sunroof screen
To move it to your chosen position,
press part A or B of the switch.
"Tailgate/rear screen open"
warning
With the engine running
, if the tail-
gate or the rear screen is not properly
closed, you are warned by an audible
signal and a message or a diagram
on the multifunction display.
To close
Press part A of the switch, the roof
will close in the intermediate (comfort)
position.
To close the roof completely, press
part A again.
Accesses

100 -
31-01-2005
101
-
31-01-2005
OPENING THE BONNET
Inside the vehicle: pull the handle on
the left-hand side, under the fascia.
Outside the vehicle: lift the catch
and raise the bonnet.
BONNET STRUT
Secure the strut to hold the bonnet
open.
Before closing the bonnet, replace
the strut in its housing.
Always remove the key
from the ignition when
leaving the vehicle, even
for a short time.
If an obstacle is detected when
operating the roof, you must re-
verse the movement of the roof.
To do this, press the control con-
cerned.
When the driver operates the roof
control, he must ensure that no
one is preventing correct closing
of the roof.
The driver must ensure that pas-
sengers use the sunroof correctly.
Be aware of children when operat-
ing the roof.
FILLING THE FUEL TANK
The tank must be illed with fuel with
the engine switched off .
Insert the key then turn it to the left.
Remove the cap.
A label indicates which type of fuel
to use.
If you ill your tank, do not continue
after the third cut-off of the pump
nozzle. This could result in vehicle
malfunctions.
The capacity of the tank is ap-
proximately 50 litres. To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is locked.
Accesses

100 -
31-01-2005
101
-
31-01-2005
OPENING THE BONNET
Inside the vehicle: pull the handle on
the left-hand side, under the fascia.
Outside the vehicle: lift the catch
and raise the bonnet.
BONNET STRUT
Secure the strut to hold the bonnet
open.
Before closing the bonnet, replace
the strut in its housing.
Always remove the key
from the ignition when
leaving the vehicle, even
for a short time.
If an obstacle is detected when
operating the roof, you must re-
verse the movement of the roof.
To do this, press the control con-
cerned.
When the driver operates the roof
control, he must ensure that no
one is preventing correct closing
of the roof.
The driver must ensure that pas-
sengers use the sunroof correctly.
Be aware of children when operat-
ing the roof.
FILLING THE FUEL TANK
The tank must be illed with fuel with
the engine switched off .
Insert the key then turn it to the left.
Remove the cap.
A label indicates which type of fuel
to use.
If you ill your tank, do not continue
after the third cut-off of the pump
nozzle. This could result in vehicle
malfunctions.
The capacity of the tank is ap-
proximately 50 litres. To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is locked.
Accesses

102 -
31-01-2005
103
-
31-01-2005
THE LIGHTS STALK
Front and rear lights
Selection is by turning ring A. Dipped/Main beam change
Pull the stalk towards you.
Note:
with the ignition off and the
automatic lighting function switched
off, when the driver's door is opened,
a buzzer sounds if you have left your
lights on. Vehicles itted with front fog lamps
and a rear fog lamp (ring C)
Side lights Dipped/Main beam
headlampsAutomatic switching
on of lights Rear fog lamp Front fog lamps (irst rotation
of the ring forwards)
Front and rear fog
lamps (2nd rotation of
the ring forwards).
Note: to switch off
the rear fog lamp and the front fog
lamps, turn the ring backwards twice
in succession.
Note: when the lights are switched
off automatically or when the dipped
headlamps are switched off manu-
ally, the front fog lamps, the rear fog
lamp and the side lights remain on
(turn the ring backwards to switch off
the front fog lamps. The side lights
then switch off).
Vehicles itted with a rear fog lamp
(ring B)
This only operates with the dipped/
main beam headlamps.
Note: when the lights are switched
off automatically, the rear fog lamp
and the dipped headlamps remain
on (turn the ring backwards to switch
off the rear fog lamp. The dipped
headlamps and side lights then
switch off). The front fog lamps operate with
the side lights and the dipped head-
lamps.
When the main beam headlamps are
switched on, the front fog lamps are
switched off. They are switched on
again when the main beam head-
lamps are switched off.
Lights off
Front fog lamps and rear fog
lamp
Rotate the ring forwards to switch on
and backwards to switch off. The sta-
tus is conirmed by the indicator light
on the instrument panel.
Visibility
