2003 YAMAHA MAJESTY 250 maintenance

6-5
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03884
NOTE:
8The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
8Hydraulic brake service
9Regularly check and, if necessary, correct the brake fluid level.
9Every two years replace the internal components of the brake master cylinders and calipers, and change the
brake fluid.
9Replace the brake hoses every four years and if cracked or damaged.
20*Engine oil strainer•Clean.√
21
*Cooling system•Check coolant level and vehicle for coolant leakage.√√√√ √
•Change.Every 3 years
22 Final transmission oil•Check vehicle for oil leakage.√√ √
•Change.√√√
23
*V-belt•Replace.Every 20,000 km
24
*Front and rear brake
switches•Check operation.√√√√√ √
25 Moving parts and cables•Lubricate.√√√√ √
26
*Throttle grip housing
and cable•Check operation and free play.
•Adjust the throttle cable free play if necessary.
•Lubricate the throttle grip housing and cable.√√√√ √
27
*Lights, signals and
switches•Check operation.
•Adjust headlight beam.√√√√√ √ NO. ITEM CHECK OR MAINTENANCE JOBODOMETER READING (× 1,000 km)
ANNUAL
CHECK
1 10203040
5SJ-28199-E1 7/11/02 11:03 AM Page 54

6-6
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03624
Removing and installing the
cowlings and panel
Cowlings and panel, removing and installingThe cowlings and panel shown above
need to be removed to perform some
of the maintenance jobs described in
this chapter. Refer to this section
each time a cowling or the panel
needs to be removed and installed.
1
1. Cowling A
1
1. Cowling C
1
1. Cowling B
5SJ-28199-E1 7/11/02 11:03 AM Page 55

6-7
PERIODIC MAINTENANCE AND MINOR REPAIR
6
1
1. Panel A
2. Remove the cowling screws.
2 11
1. Screw (×4)
2. Cowling A
EAU03615
Cowling ACowling *To remove the cowling
1. Pull up the left floorboard mats
as shown.
1
2
1. Mat A
2. Mat B
5SJ-28199-E1 7/11/02 11:03 AM Page 56

6-8
PERIODIC MAINTENANCE AND MINOR REPAIR
6 3. Pull the cowling down slightly,
and then pull it outward as
shown.
EAU03632
Cowling BCowling *To remove the cowling
1. Pull up the right floorboard mats
as shown.
1
2
1. Mat A
2. Mat B
To install the cowling
1. Insert the tabs on the cowling
into the slots as shown, and then
install the screws.
2. Place the floorboard mats in the
original position.
ECA00067
cC
Take care not to damage the tabs
on the cowling when removing and
or installing it.
1
1. Tab (×10)
5SJ-28199-E1 7/11/02 11:03 AM Page 57

6-9
PERIODIC MAINTENANCE AND MINOR REPAIR
62. Remove the screws.
2 1
1
1. Screw (×4)
2. Cowling B
To install the cowling
1. Insert the tabs on the cowling
into the slots as shown, and then
install the screws.
2. Place the floorboard mats in the
original position.
ECA00067
cC
Take care not to damage the tabs
on the cowling when removing and
or installing it.
1
1. Tab (×10)
3. Pull the cowling down slightly,
and then pull it outward as
shown.
5SJ-28199-E1 7/11/02 11:03 AM Page 58

6-10
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03617
Cowling C
To remove the cowling
1. Remove the cowling screws.
1
1. Screw (×2)
2. Push the cowling in lightly, and
then pull it back as shown.
ECA00067
cC
Take care not to damage the tabs
on the cowling when removing and
or installing it.
aa
a. Push.
5SJ-28199-E1 7/11/02 11:03 AM Page 59

6-11
PERIODIC MAINTENANCE AND MINOR REPAIR
6To install the cowling
1. Insert the tabs on the cowling
into the slots as shown, and then
push the cowling in until it snaps
into place.
2. Install the cowling screws.
1
2
1. Tab (×4)
2. Slot (×4)
EAU03628
Panel APanel *To remove the panel
Remove the bolts, and then pull the
panel out as shown.
1
2
1. Bolt (×2)
2. Panel A
5SJ-28199-E1 7/11/02 11:03 AM Page 60

6-12
PERIODIC MAINTENANCE AND MINOR REPAIR
6 To install the panel
Place the panel in the original posi-
tion, and then install the bolts.
1
1
1. Tab (×4)
To remove the spark plug
1. Remove cowling B. (See page
6-8 for cowling removal and
installation procedures.)
2. Remove the spark plug cap.
1
1. Spark plug cap
EAU03620
Checking the spark plugSpark plug, checkingThe spark plug is an important
engine component, which is easy to
check. Since heat and deposits will
cause any spark plug to slowly erode,
the spark plug should be removed
and checked in accordance with the
periodic maintenance and lubrication
chart. In addition, the condition of the
spark plug can reveal the condition of
the engine.
