2003 SUBARU FORESTER stop start

5-15
Audio
– CONTINUED –
current disc. Fast reverse
Press the “ ” button (17) continuously for more
than 1 second to fast reverse the disc.
Release the button to stop fast reverse.
If you continue fast reverse to the beginning of the
disc, the CD changer will automatically stop fast re-
verse and start playback beginning with the first track
on the current disc. Repeat
Press the “RPT” button (19) while a song is playing to
play the song repeatedly. The “RPT” indicator will
come on and the song will be played continuously. To
cancel the repeat mode, press the button again. Then
the “RPT” indicator goes out, and normal playback
mode is restored. Random playback
Press the “RAND” button (18) while a disc is being
played back to play all songs on the disc in a random
order. The “RAND” indicator will come on and all
songs on the disc will be played in a random order.
To cancel the random mode, press the button again.
Then the “RAND” indicator goes out, and normal play-
back mode is restored.
Scan (a convenient way to become familiar with
adisc)
1. Press the “SCAN” button (20). – The display shows “SCAN” and the track number
being scanned.
– You hear the first 10 seconds of each track.
– The operation is automatically cleared after play-
ing all programs. Then, normal playback starts.
2. Press the “SCAN” button again when you hear a
track you like. – Normal playback resumes.
To stop playback
To stop playback and switch over to the radio mode,
press the “BAND” button.

5-23
Audio
– CONTINUED –
NOTE Only use good quality cassettes (cassettes
longer than C-90 are not recommended). Put cassettes back in their boxes immediately
after use to protect them from dust and dirt and to
prevent the tape from unwinding. Never expose cassettes to heat, direct sunlight
or moisture. Clean the tape head (once or twice a month) us-
ing a wet-type cleaning cassette. To play back a cassette tape
When cassette tape is not in the player
When a cassette is partially inserted, it is automatically
drawn in and starts tape playback. When cassette tape is in the player
When the “TAPE” button (12) is pressed, the display
will show “PLAY” and the player will start playback. Tape travel indicators
These indicate the direction the cassette tape is mov-
ing.
: indicates that the top side of the cassette is being
played back.
: indicates that the bottom side of the cassette is be-
ing played back.
Program switching button (PROG)
When the program switching button “PROG” (16) is
pressed during playback, the tape travel indicators will
switch and the player will begin playing back the oppo-
site side of the tape. The same mechanism is auto-
matically activated when the end of the tape is
reached. This allows the opposite side of the tape to
play, providing continuous playback. Fast-forward button (FF)
To fast-forward the tape, press the “FF” button (15).
The display will show “FF”. To stop fast-forwarding,
press the “FF” or “TAPE” (12) button. Rewind button (REW)
To rewind the tape, press the “REW” button (17). The
display will indicate “REW”. To stop rewinding, press
the “REW” or “TAPE” (12) button. Eject button ( )
When “ ” button (10) is pressed, play back stops and
the cassette tape is ejected.
The ejection function also operates when the ignition
switch is in the “LOCK” position. Always make certain
that you remove the cassette tape.

5-28
Audio
and “TAPE” (12), the player will enter standby mode.
Press the “CD” button to start playback.
Loading all the magazine (Full disc loading mode)
1. If you continue to press the “LOAD” button for more
than 1.5 seconds, the player will produce beep sound
and will enter the full disc loading mode.
2. A “DISC” indicator will blink, and the “IN” will be on
display for a period of 15 seconds. If a disc is success-
fully loaded during this period, the “DISC” indicator will
stop blinking and will steadily light.
3. When the loading of a disc is complete, the next
“DISC” indicator will blink. Then repeat Step 2.
4. When the magazine is filled with discs by repeating
Steps 2 and 3, the player will start playback of the
discs, beginning with the one inserted first.
If you fail to insert any disc during each 15-second in-
terval, the full disc loading mode will be canceled, and
the player will start playback of the disc inserted first. How to play back a CD or make a pause
When there is no CD inserted:
Insert a CD by referring to “How to insert a CD(s)”.
When a CD is loaded, the player will start playback of
the CD, beginning with the first number.
When there are CDs loaded:
Press a desired one of the “DISC SELECT” buttons
(26) the “DISC” indicator of which steadily lights up.
The player will then start playback of the selected CD,
beginning with the first number. Selecting a desired track (TRACK)
: Skipping forward
: Skipping backward
: Fast forwarding
: Fast reversing
Skipping forward
Turn the “TRACK” knob (24) clockwise and release it
HS5015BA

7-1
7
Starting and operating
Fuel ............................................................... 7-2 Fuel requirements ........................................... 7-2
Fuel filler lid and cap ...................................... 7-4
State emission testing (U.S. only) .............. 7-6
Preparing to drive ........................................ 7-8
Starting the engine ...................................... 7-9 Manual transmission vehicle ......................... 7-9
Automatic transmission vehicle .................... 7-9
Starting the engine during cold weather below –4°F (–20 °C) .................................................... 7-10
Starting a flooded engine ............................... 7-10
Stopping the engine .................................... 7-11
Manual transmission ................................... 7-11 Shifting speeds ............................................... 7-12
Driving tips ...................................................... 7-13
Automatic transmission .............................. 7-14 Selector lever for automatic transmission ... 7-15
Shift lock release ............................................ 7-18
Rear viscous limited slip differential (LSD)
(if equipped) ................................................. 7-20
Power steering ............................................. 7-20
Braking ......................................................... 7-21 Braking tips ..................................................... 7-21
Brake system ................................................... 7-21
Disc brake pad wear warning indicators ...... 7-22
ABS (Anti-lock Brake System) ................... 7-22 ABS system self-check .................................. 7-23
ABS warning light ........................................... 7-23 Electronic Brake Force Distribution (EBD)
system (if equipped) .................................... 7-25
Steps to take if EBD system fails .................. 7-25
Parking your vehicle .................................... 7-27 Parking brake .................................................. 7-27
Parking tips ..................................................... 7-27
Hill holder (for manual transmission — if equipped) .................................................. 7-29
Cruise control (if equipped) ........................ 7-31 To set cruise control ...................................... 7-31
To temporarily cancel the cruise control ..... 7-32
To turn off the cruise control ......................... 7-32
To change the cruising speed ....................... 7-32
Self-leveling rear suspension (if equipped) 7-34

7-5
Starting and operating
–CONTINUED –
1) Open
2) Close
2. Remove the fuel filler cap by turning it slowly coun-
terclockwise.
Gasoline vapor is highly flammable. Before
refueling, always first stop the engine and make
sure that there are no lighted cigarettes, open
flames or electrical sparks in the adjacent area. When opening the cap, do not remove the
cap quickly. Fuel may be under pressure and
spray out of the fuel filler neck especially in hot
weather, which may cause injury.
3. Stop filling the tank after the fuel filler pump auto-
matically stops. Do not add any more fuel.
4. Put the cap back on, turn it clockwise until you hear
a clicking noise. Be certain not to catch the tether un-
der the cap while tightening.
5. Close the fuel filler lid completely.
If you spill any fuel on the painted surface, rinse it off
immediately. Otherwise, the painted surface could be
damaged.
NOTE
If the fuel filler cap is not tightened until it clicks or
if the tether is caught under the cap, the CHECK
ENGINE warning light may come on. Refer to the
“Warning and indicator lights” section located in
chapter 3.
Never add any cleaning agents to the fuel
tank. The addition of a cleaning agent may
cause damage to the fuel system. Make sure that the cap is tightened until it
clicks to prevent fuel spillage in the event of an
accident.
1 2
HS7007BB

7-8
Starting and operating
or there is one or more diagnostic trouble codes stored
in vehicle’s computer with the
“CHECK ENGINE”
warning light/MIL illuminated. A state emission inspection may reject (not pass or
fail) a vehicle if the number of OBD system readiness
monitors “Not Ready” is greater than three. Under
this condition, the vehicle operator should be instruct-
ed to drive his/her vehicle for a few days to set the
monitors and return for an emission re-inspection. Owners of rejected or failing vehicles should contact
their Subaru Dealer for service.Preparing to drive
You should perform the following checks and adjust-
ments every day before you start driving.
1. Check that all windows, mirrors, and lights are
clean and unobstructed.
2. Check the appearance and condition of the tires.
Also check tires for proper inflation.
3. Look under the vehicle for any sign of leaks.
4. Check that the hood and rear gate are fully closed.
5. Check the adjustment of the seat.
6. Check the adjustment of the inside and outside mir-
rors.
7. Fasten your seatbelt. Check that your passengers
have fastened their seatbelts.
8. Check the operation of the warning and indicator
lights when the ignition switch is turned to the “ON” po-sition.
9. Check the gauges, indicator and warning lights af-
ter starting the engine.
NOTE
Engine oil, engine coolant, brake fluid, washer flu-
id and other fluid levels should be checked daily,
weekly or at fuel stops.

7-11
Starting and operating
–CONTINUED –
Stopping the engine
The ignition switch should be turned off only when the
engine is idling.
Do not stop the engine when the vehicle is mov-
ing. This will cause loss of power to the power
steering and the brake booster, making steer-
ing and braking more difficult. It could also re-
sult in accidental activation of the “LOCK”
position on the ignition switch, causing the
steering wheel to lock.
Manual transmission
The manual transmission is a fully synchromeshed 5-
forward and 1-reverse speed transmission.
The shift pattern is shown on the shift lever knob.
When shifting from 5th gear to reverse gear, first re-
turn the shift lever to the neutral position then shift into
reverse gear.
To change gears, fully depress the clutch pedal, move
the shift lever, and gradually let up on the clutch pedal.
If it is difficult to shift into gear, put the transmission in
neutral, release the clutch pedal momentarily, and
then try again.
135
24R
N
135
24R
HS7008BA

7-12
Starting and operating
Do not drive the vehicle with the clutch disen-
gaged (i.e., when the clutch pedal is depressed)
or with the shift lever in the neutral position.
Engine braking has no effect in either of these
conditions and the risk of an accident is conse-
quently increased.
Shift into reverse ONLY when the vehicle has
completely stopped. It may cause damage to
the transmission to try shifting into reverse
when the vehicle is moving.
Shifting speeds
Recommended shifting speeds
The best compromise between fuel economy and ve-
hicle performance during normal driving is ensured by
shifting up at the speeds listed in the following table.
Maximum allowable speeds
The following table shows the maximum speeds that
are possible with each different gear.
Never exceed the speed limit below for each gear po-
sition except for brief acceleration in an emergency.
The tachometer’s needle will enter the red area if
these speeds are exceeded. Failure to observe this
precaution can lead to excessive engine wear and
poor fuel economy.
mph (km/h)
Shift up mph (km/h)
1st to 2nd 15 (24)
2nd to 3rd 25 (40)
3rd to 4th 40 (65)4th to 5th 45 (73)
XandXS
1st 30 (49)
2nd 51 (82)
3rd 73 (117)
