2003 SUBARU FORESTER maintenance

11 -6 1
Maintenance and service
–CONTINUED –
7. Pull the bulb out of the socket. Install a new bulb.
8. Set the bulb socket into the headlight assembly and
turn it clockwise until it locks.
9. Reinstall all the removed parts by following the re-
moval sequence in reverse. Front fog light
It may be difficult to replace the bulbs. Have your
SUBARU dealer replace the bulbs if necessary. Rear combination lights
1. Remove the upper and lower screws. Then, slide
the rear combination lamp assembly to the rear and remove it from the vehicle.
HSB080BA
HSB085BA

11 - 6 2
Maintenance and service
1) Tail/stop light
2) Rear turn signal light
3) Backup light
4) Tail/stop light
2. Remove the bulb holder from the rear combination
light assembly by turning it counterclockwise.
3. Pull the bulb from the holder. Install a new bulb.
4. Set the bulb holder into the rear combination light
assembly and turn it clockwise until it locks.
5. Reinstall the rear combination light assembly.
License plate light
0
1. Remove the mounting screws using a phillipsscrewdriver.
2. Remove the cover and lens.
3. Pull the bulb out of the socket. Install a new bulb.
4. Reinstall the lens and cover.
5. Tighten the mounting screws.
3
2
1
4
HSB086BB
HSB087BA

11 -6 3
Maintenance and service
–CONTINUED –
Dome light, map light and cargo area light
1. Remove the lens by prying the edge of the lens with
HSB088BA
HSB089BA
HSB090BA

11 - 6 4
Maintenance and service
a regular screwdriver.
2. Pull the bulb out of the socket. Install a new bulb.
3. Reinstall the lens.
High mount stop light
0
1. Remove the mounting screw covers by prying the
edge with a screwdriver.
2. Remove the mounting screws using a phillips
screwdriver and then remove the high mount stop lightcover.
3. Pull the bulb from the socket. Install a new bulb.
4. Reinstall the cover.
5. Tighten the mounting screws then reinstall the cov- ers.
NOTE
Other bulbs may be difficult to replace. Have your
SUBARU dealer replace these bulbs if necessary.
HSB091BA

14-5
Index
J
Jack and jack handle ...................................... 9-19
Jump starting .................................................. 9-9 K
Key interlock release (AT vehicles) ................ 3-4
Keys ............................................................... 2-2 Key
Number ...................................................... 2-2
Reminder chime ........................................ 3-3
L
Leather seat materials .................................... 10-5
Light control switch ......................................... 3-17
Limited slip differential (LSD) .......................... 7-20
Loading your vehicle ...................................... 8-14
Lower and tether anchorages ......................... 1-35
Low fuel warning light ..................................... 3-14
LSD (limited slip differential) ........................... 7-20
Lumbar support .............................................. 1-5 M
Main fuse ........................................................ 11-53
Maintenance Precautions ................................................ 11-3
Schedule .................................................... 11-3 Seatbelt ..................................................... 1-26
Tools .......................................................... 9-19
Malfunction indicator lamp .............................. 3-10
Manual climate control system ........................ 4-4
Manual transmission ...................................... 7-11 Oil .............................................................. 11-22
Map light ......................................................... 6-3
Maximum load limits ....................................... 8-25
Meters and gears ........................................... 3-5
Mirrors ............................................................ 3-29
Moonroof ................................................ 2-26, 9-18 N
New vehicle break-in driving .......................... 8-2 O
Odometer/Trip meter ...................................... 3-5
Off road driving ............................................... 8-7
Oil pressure warning light ............................... 3-11
Oil filter ........................................................... 11-10
Oil level
Engine ....................................................... 11-9
Manual transmission .................................. 11-22
Rear differential ......................................... 11-27
Outside mirrors ............................................... 3-31
Overhead console .......................................... 6-6

14-6
Index
P
Parking brake ......................................... 7-27, 11-37
Stroke ........................................................ 11-37
Parking light switch ......................................... 3-21
Parking your vehicle ....................................... 7-27
Periodic inspections ....................................... 8-5Power Door locking switches ................................ 2-5
Steering ..................................................... 7-20
Steering fluid level ..................................... 11-29
Windows .................................................... 2-21
R
Rear Combination lights ..................................... 11-61
Differential gear oil level ............................ 11-27
Gate ................................................... 2-24, 9-17
Seats ......................................................... 1-9
Viscous limited slip differential (LSD) ........ 7-20
Rear Window Defogger switch ......................................... 3-27
Wiper and washer switch ........................... 3-25
Remote keyless entry system ........................ 2-6
Replacing Air cleaner element .................................... 11-19
Battery (remote keyless entry) ................... 2-9
Bulbs ......................................................... 11-54 Transmitters ............................................... 2-10
Rocking the vehicle ......................................... 8-13
Roof rail and crossbar ..................................... 8-17 S
Seatbelts ......................................................... 1-12
Seatbelt Maintenance ............................................... 1-26
Pretensioners ............................................. 1-27
Safety tips ................................................... 1-12
Warning light and chime ............................. 3-9
Seats
Fabric ......................................................... 10-5
Heater ......................................................... 1-8
Seat height adjustment (driver’s side) ............. 1-5
Security system ............................................... 2-14
Selector lever (AT vehicles) ............................ 7-15
Self-leveling rear suspension .......................... 7-34
Shift lock release ............................................. 7-18
Shift position indicator ..................................... 3-15
Shopping bag hook ......................................... 6-18
Snow tires ....................................................... 8-12
Snowy and icy roads ....................................... 8-11
Spark plugs ..................................................... 11-20
Specifications .................................................. 12-2
Speedometer ................................................... 3-5
SRS airbags .................................................... 1-39

14-8
Index
Front-wheel drive ....................................... 3-15
Low fuel ..................................................... 3-14
Oil pressure ............................................... 3-11
Seatbelt ..................................................... 3-9
SRS airbag system .................................... 3-10
Warranties and maintenance ......................... 8-25
Washing ......................................................... 10-2
Waxing and polishing ..................................... 10-3
Wear indicators .............................................. 11-41
Wheel Alignment .................................................. 12-5
Aluminum ................................................... 11-44
Balance ..................................................... 11-41
Replacement ............................................. 11-43
Windows ......................................................... 2-21
Windshield Washer fluid ............................................... 11-45
Wiper and washer switches ....................... 3-23
Wiper deicer .............................................. 3-26
Windshield wiper blades Replacement ............................................. 11-46
Winter driving ................................................. 8-9
Wiper and washer .......................................... 3-22
