2003 SUBARU BAJA ECU

9-24
nTowing hook cover removal procedure
HB9067BBHB9068BB
The towing hook cover is secured by tabs that fit into corresponding
slots in the vehicle body.
To remove the cover:
1. Push on the position A while pulling the portion B toward you.
2. Push on the portion C and pull the cover.
n Towing hook cover installation procedure
hB9069BA
To reinstall the towing hook cover, push it in on both sides while push-
ing it back to its original position. Make certain that the tabs at the
end of the cover are securely inserted into the corresponding slots inthe vehicle ’s body.

In case of emergency9-25
–
CONTINUED –
Using a flat-bed truck
HB9072AA
This is the best way to transport your vehicle. Use the following proce-
dures to ensure safe transportation.
1. Shift the selector lever into the “P” position for automatic transmis-
sion vehicles or “1st” for manual transmission vehicles.
2. Pull up the parking brake lever firmly.
3. Secure the vehicle onto the carrier properly with safety chains.
Each safety chain should be equally tightened and care must be tak-en not to pull the chains so tightly that the suspension bottoms out. Towing with all wheels on the ground
WARNING
Never turn the ignition switch to the “LOCK” position while the
vehicle is being towed because the steering wheel and the direc- tion of the wheels will be locked. Remember that the brake booster and power steering do not
function when the engine is not running. Because the engine isturned off, it will take greater effort to operate the brake pedal andsteering wheel.

11-6
HBB003BA
To open the hood:
1. Pull the hood release knob under the instrument panel.
2. Release the secondary hood release located under the front grille by
moving the lever toward the left. Lift up the hood, release the hood prop
from its retainer and put the end of the hood prop into the slot in thehood.
To close the hood:
1. Lift the hood slightly and remove the hood prop from the slot in the
hood and return the prop to its retainer.
2. Lower the hood until it approaches about 6 in. (15 cm) from the
closed position and let it drop.
3. After closing the hood, be sure the hood is securely locked.
If this does not close the hood, release it from a slightly higher position.
Do not push the hood forcibly to close it. It could deform the metal.

Maintenance and service11-9
–
CONTINUED –
Changing the oil and oil filter
Change the oil and oil filter according to the maintenance schedule in the “Warranty and Maintenance Booklet ”.
The engine oil and oil filter must be changed more frequently than
listed in the maintenance schedule when driving on dusty roads,
when short trips are frequently made, or when driving in extremely
cold whether.
1. Warm up the engine by letting the engine idle for about 10 minutes to ease draining the engine oil.
2. Park the vehicle on a level surface and stop the engine.
3. Remove the oil filler cap.
HBB005BB
4. Drain out the engine oil by removing the drain plug while the en-
gine is still warm. The used oil should be drained into an appropriate
container and disposed of properly.
WARNING
Be careful not to burn yourself with hot engine oil.
5. Wipe the seating surface of the drain plug with a clean cloth and
tighten it securely with a new sealing washer after the oil has com-pletely drained out.

11-16
HBB006BB
3. Loosen the radiator cap to drain the coolant from the radiator. Then
drain the coolant from the reserve tank. Tighten the drain plug secure-
ly.
HBB004FB
HBB007CB
4. Slowly pour the coolant and fill to the radiator filler neck and to the
reserve tank ’s “FULL” level mark. Do not pour the coolant too quickly,
as this may lead to insufficient air bleeding and trapped air in the sys-tem.
Coolant capacity (Guideline): MT. 7.2 US qt (6.8 liters, 6.0 Imp qt)
AT. 7.1 US qt (6.7 liters, 5.9 Imp qt)

11-18
Replacing the air cleaner element
Replace the air cleaner element according to the maintenance sched- ule in the “Warranty and Maintenance Booklet ”. Under extremely
dusty conditions, replace it more frequently. It is recommended that
you always use genuine SUBARU parts.
HBB064BB
HBB063BB
1. Remove the bolt securing the rear air cleaner element case.
2. Unsnap the three clamps holding the rear air cleaner elementcase.
3. Separate the rear air cleaner element case from the front air clean-
er element case and remove the air cleaner element.
4. Clean the inside of the front and rear air cleaner element caseswith a damp cloth and install a new air cleaner element.
5. Insert the four projections on the rear air cleaner element case into
the slits on the front air cleaner element case and snap the three
clamps on the rear air cleaner element case and then tighten the bolt.

Maintenance and service11-55
–
CONTINUED –
Low beam light bulbs
HBB042BA
HBB041BB
1. Disconnect the electrical connector for the black cable.
2. Remove the retainer spring.
3. Replace the bulb, then set the retainer spring securely.
4. Reconnect the electrical connector for black cable.
5. Install the headlight bulb cover. High beam light bulbs
HBB044BB
HBB043BA
1. Disconnect the electrical connector from the bulb.
2. Remove the bulb from the headlight assembly by turning it coun-
terclockwise.
3. Replace the bulb with new one.
4. Reconnect the electrical connector. At this time, use care not to
touch the bulb surface.

11-64
HBB048BA
3. Remove the bulb from the socket by pulling it.
4. Install a new bulb in the socket by pushing it.
5. Set the socket into the light assembly and turn it clockwise until itclicks.
6. Mount the light assembly with the mounting screws. Sport activity lights (if equipped)
HBB082AAHBB081BA
1. Remove front lamp screw and remove the lens and reflector.
2. Disconnect the two wires from the lamp electrical connector.
3. Squeeze the bulb retainer spring to remove.
4. Replace the bulb, then reset the retainer spring securely.
5. Reconnect the bulb wire to the electrical connector.
6. Install the lens and reflector in the housing and secure with the screw.
