2003 SUBARU BAJA wheel

v
–
CONTINUED –
deploys could suffer very serious injuries. Because the SRS air- bag needs enough space for deployment, the driver should al-ways sit upright and well back in the seat as far from the steeringwheel as practical while still maintaining full vehicle control and
the front passenger should move the seat as far back as possibleand sit upright and well back in the seat.
Carefully read the sections “Seat, seatbelts and SRS airbag ” in chapter 1
of this owner ’s manual for instructions and precautions concerning the
seatbelt system and SRS airbag system. CHILD SAFETY
WARNING
Never hold a child on your lap or in your arms while the ve-
hicle is moving. The passenger cannot protect the child from in- jury in a collision, because the child will be caught between the
passenger and objects inside the vehicle. While riding in the vehicle, infants and small children should
always be placed in the REAR seat in an infant or child restraint
system which is appropriate for the child ’s age, height and
weight. If a child is too big for a child restraint system, the childshould sit in the REAR seat and be restrained using the seatbelts.According to accident statistics, children are safer when properlyrestrained in the rear seating positions than in the front seatingpositions. Never allow a child to stand up or kneel on the seat. Put children aged 12 and under in the REAR seat properly re-
strained at all times in a child restraint device or in a seatbelt. TheSRS airbag deploys with considerable speed and force and caninjure or even kill children, especially if they are 12 years of ageand under and are not restrained or improperly restrained. Be-
cause children are lighter and weaker than adults, their risk being
injured from deployment is greater. NEVER INSTALL A REARWARD FACING CHILD SAFETY SEAT
IN THE FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR
DEATH TO THE CHILD BY PLACING THE CHILD ’S HEAD TOO

vii
–
CONTINUED –
If at any time you suspect that exhaust fumes are entering the
vehicle, have the problem checked and corrected as soon as pos-
sible. If you must drive under these conditions, drive only with allwindows fully open.
DRINKING AND DRIVING WARNING
Drinking and then driving is very dangerous. Alcohol in the
bloodstream delays your reaction and impairs your perception,judgment and attentiveness. If you drive after drinking – even if
you drink just a little – it will increase the risk of being involved in
a serious or fatal accident, injuring or killing yourself, your pas-sengers and others. In addition, if you are injured in the accident,
alcohol may increase the severity of that injury. Please don ’t drink and drive.
Drunken driving is one of the most frequent causes of accidents. Since
alcohol affects all people differently, you may have consumed too much
alcohol to drive safely even if the level of alcohol in your blood is belowthe legal limit. The safest thing you can do is never drink and drive. How-ever if you have no choice but to drive, stop drinking and sober up com-
pletely before getting behind the wheel. DRUGS AND DRIVING
WARNING
There are some drugs (over the counter and prescription) that can delay your reaction time and impair your perception, judg-ment and attentiveness. If you drive after taking them, it may in-
crease your, your passengers ’ and other persons ’ risk of being
involved in a serious or fatal accident.

x
Refer to the “Tires and wheels ” section in chapter 11 for detailed
information.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State ofCalifornia to cause cancer and birth defects or other reproductiveharm.

xx
Combination meter Overview
HBF054BB
1 SRS airbag system warning light (page 3-10)
2 Brake system warning light (page 3-14)
3 Seatbelt warning light (page 3-10)
4 Turn signal indicator light (page3-16)
5 Door ajar warning light (page 3-15)
6 High beam indicator light (page 3-16)
7 CHECK ENGINE warning light/Malfunction indicator lamp (page 3-11)
8 Charge warning light (page 3-12)
9 OIL pressure warning light (page 3-12)
Q AT OIL temperature warning light(page 3-13)
W Front-wheel drive warning light (page 3-15) E
Temperature gauge (page 3-9)
R Clock setting knob (page 3-17)
T Clock (page 3-17)
Y Outside temperature indicator (page 3-8)
U Tachometer (page 3-8)
I Switchback door indicator (page3-15)
O Security system indicator lamp(page 3-16)
P Shift position indicator (page 3-16)
A Cargo lamp indicator (page 3-16)
S Trip meter A/B selection and trip
meter reset knob (page 3-7)
D Trip meter (page 3-7)
F Odometer (page 3-7)
G Speedometer (page 3-7)
H Low fuel warning light (page 3-15)
J Fuel gauge (page 3-9)
K ABS warning light (page 3-13)

xxi
–
CONTINUED –
Warning and indicator light
Mark
NamePage
Seatbelt warning light3-10
AIRBAGSRS airbag system warning light3-10
CHECK ENGINE warning light/ Malfunction indicator lamp3-11
Charge warning light3-12
Oil pressure warning light3-12
AT OIL temperature warning light (if equipped)3-13
orABS warning light3-13
orBrake system warning light3-14
Door ajar warning light3-15
Low fuel warning light3-15
Front-wheel drive warning light (if equipped)3-15
Switchback door indicator3-15
Security system indicator light (if equipped)3-16
Cargo lamp indicator3-16
Turn signal indicator lights3-16
High beam indicator light3-16

1-2
Front seatsWARNING
Never adjust the seat while driving to avoid the possibility of
loss of vehicle control and of personal injury. Never drive the vehicle with the head restraints removed be-
cause they are designed to reduce the risk of serious neck injury
in the event that the vehicle is struck from the rear. Before adjusting the seat, make sure the hands and feet of rear
seat passengers are clear of the adjusting mechanism. Seatbelts provide maximum restraint when the occupant sits
well back and upright in the seat. To reduce the risk of sliding un-der the seatbelt in a collision, the front seatbacks should be al-ways used in the upright position while the vehicle is running. Ifthe front seatbacks are not used in the upright position in a colli-
sion, the risk of sliding under the lap belt and of the lap belt slid-ing up over the abdomen will increase, and both can result in se-rious internal injury or death. Do not put cushions or any other materials between occupants
and seatbacks or seat cushions. If you do so, the risk of sliding
under the lap belt and of the lap belt sliding up over the abdomen
will increase, and both can result in serious internal injury or death. The SRS airbags deploy with considerable speed and force.
Occupants who are out of proper position when the SRS airbag
deploys could suffer very serious injuries. Because the SRS air-bag needs enough space for deployment, the driver should al-ways sit upright and well back in the seat as far from the steeringwheel as practical while still maintaining full vehicle control and
the front passenger should move the seat as far back as possibleand sit upright and well back in the seat. Put children aged 12 and under in the rear seat properly re-
strained at all times. The SRS airbag deploys with considerable
speed and force and can injure or even kill children, especially if
they are 12 years of age and under and are not restrained or im-
properly restrained. Because children are lighter and weaker than

Seat, seatbelt and SRS airbags1-3
–
CONTINUED –
adults, their risk of being injured from deployment is greater. For
that reason, we strongly recommend that ALL children (including
those in child seats and those that have outgrown child restraint
devices) sit in the REAR seat properly restrained at all times in a
child restraint device or in a seatbelt, whichever is appropriate for
the child’s age, height and weight.
Secure ALL types of child restraint devices (including forward fac-
ing child seat) in the REAR seats at all times.
NEVER INSTALL A REARWARD FACING CHILD SEAT IN THE
FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO
THE CHILD BY PLACING THE CHILD ’S HEAD TOO CLOSE TO THE
SRS AIRBAG.
According to accident statistics, children are safer when properly
restrained in the rear seating positions than in the front seating
positions. For instructions and precautions concerning child re-
straint systems, see the “Child restraint systems ” section in this
chapter.
HB0290
HS0233
Adjust the seatback to upright position. Sit well back and upright.
Move the seat as far from the steering wheel as practical. Adjust the seatback toupright position. Sit well back and upright.Move the seat as far back as possible.

1-18
HS0231
Never place the shoulder belt under the arm or behind the back.
HS0230
Always wear the
seatbelts correctly.
Adjust the seatback to upright position. Sit well back and upright.
CAUTION
Metallic parts of the seatbelt can become very hot in a vehicle that has been closed up in sunny weather; they could burn an oc-cupant. Do not touch such hot parts until they cool.
Front seatbelts
OM-H0044OM-H0043
1. Adjust the seat position:
Driver’ s seat: Adjust the seatback to the upright position. Move the
seatback as far from the steering wheel as practical while still main-
taining full vehicle control.Front passenger ’s seat: Adjust the seatback to the upright position.
Move the seat as far back as possible.
