2003 SUBARU BAJA wheel

Driving tips8-27
–
CONTINUED –
HB8043BA
HB8039BB
To check both GVWR and GAWR and to confirm that the total weight
and weight distribution are within safe driving limits, you should have
your vehicle and trailer weighed at a commercial weighing station.
Be sure that all cargo is firmly secured to prevent a change in weight
distribution while driving. n
Tongue load
WARNING
If the trailer is loaded with more weight in the back of trailer ’s
axle than in the front, the load is taken off the rear axle of the tow- ing vehicle. This may cause the rear wheels to skid, especiallyduring braking or when vehicle speed is reduced during corner-
ing, resulting in over-steer, spin out and/or jackknifing.
Ensure that the trailer tongue load is from 8 to 11 percent of the total
trailer weight and does not exceed the maximum value of 200 lbs (90kg).
The tongue load can be weighed with a bathroom scale as shown in
the illustration below. When weighing the tongue load, be sure to posi-
tion the towing coupler at the height at which it would be during
actual towing, using a jack as shown.

Driving tips8-29
–
CONTINUED –
Trailer hitches
WARNING
Never drill the frame or under-body of your vehicle to install a
commercial trailer hitch. If you do, dangerous exhaust gas, wateror mud may enter the passenger compartment through the drilledhole. Exhaust gas contains carbon monoxide, a colorless andodorless gas which is dangerous, or even lethal, if inhaled. Also,drilling the frame or under-body of your vehicle could cause dete-rioration of strength of your vehicle and cause corrosion aroundthe drilled hole.
CAUTION
Do not modify the vehicle exhaust system, brake system, or
other systems when installing a hitch or other trailer towingequipment. Do not use axle-mounted hitches as they can cause damage to
the axle housing, wheel bearings, wheels or tires.
The use of a genuine SUBARU trailer hitch is recommended. A genu-
ine SUBARU hitch is available from your SUBARU dealer.
If use of a non-genuine hitch is unavoidable, be sure the hitch is
suited to your vehicle and trailer. Consult with a professional hitch
supplier to assist you in choosing an appropriate hitch for your
vehicle. Be sure to follow all of the hitch manufacturer ’s instructions for
installation and use.
Never use a hitch that mounts only to the rear bumper. The bumper isnot designed to handle that type of load.
For all types of hitches, regularly check that the hitch mounting bolts
and nuts are tight.

Driving tips8-33
–
CONTINUED –
nBefore starting out on a trip
Check that the vehicle and vehicle-to-hitch mounting are in good
condition. If any problems are apparent, do not tow the trailer. Check that the vehicle sits horizontally with the trailer attached. If
the vehicle is tipped sharply up at the front and down at the rear,
check the total trailer weight, GVW, GAWs and tongue load again,
then confirm that the load and its distribution are acceptable. Check that the tire pressures are correct.
Check that the vehicle and trailer are connected properly. Confirm
that. – the trailer tongue is connected properly to the hitch ball.
– the trailer lights connector is connected properly and trailer ’s
brake lights illuminate when the vehicle ’s brake pedal is pressed,
and that the trailer ’s turn signal lights flash when the vehicle ’s turn
signal lever is operated.– the safety chains are connected properly.
– all cargo in the trailer is secured safety in position.
– the side mirrors provide a good rearward field of view without a
significant blind spot.
Sufficient time should be taken to learn the “feel” of the vehicle/
trailer combination before starting out on a trip. In an area free of traf-
fic, practice turning, stopping and backing up. n Driving with a trailer
You should allow for considerably more stopping distance when
towing a trailer. Avoid sudden braking because it may result in skid-
ding or jackknifing and loss of control. Avoid abrupt starts and sudden accelerations. If your vehicle has a
manual transmission, always start out in first gear and release the
clutch at moderate engine revolution. Avoid uneven steering, sharp turns and rapid lane changes.
Slow down before turning. Make a longer than normal turning
radius because the trailer wheels will be closer than the vehicle
wheels to the inside of the turn. In a tight turn, the trailer could hit yourvehicle. Crosswinds will adversely affect the handling of your vehicle and

8-34
trailer, causing sway. Crosswinds can be due to weather conditions or
the passing of large trucks or buses. If swaying occurs, firmly grip the
steering wheel and slow down immediately but gradually.When passing other vehicles, considerable distance is required
because of the added weight and length caused by attaching the
trailer to your vehicle. Backing up with a trailer is difficult and takes practice. When back-
ing up with a trailer, never accelerate or steer rapidly. When turning
back, grip the bottom of the steering wheel with one hand and turn it
to the left for a left turn, and turn it to the right for a right turn.
Left turn Right turn
OM-H2791
If the ABS warning light illuminates while the vehicle is in motion,
stop towing the trailer and have repairs performed immediately by the
nearest SUBARU dealer. n Driving on grades
Before going down a steep hill, slow down and shift into lower gear
(if necessary, use 1st gear) in order to utilize the engine braking effect
and prevent overheating of your vehicle ’s brakes. Do not make sud-
den downshifts. When driving uphill in hot weather, the air conditioner may turn off
automatically to protect the engine from overheating. When driving uphill in hot weather, pay attention to the water tem-
perature gauge pointer (for all vehicles) and AT OIL TEMP warning
light (for AT vehicles) since the engine and transmission are relatively
prone to overheating under these conditions. If the water temperature

Driving tips8-35
–
CONTINUED –
gauge pointer approaches the OVERHEAT zone or the AT OIL TEMP
warning light illuminates, immediately switch off the air conditioner
and stop the vehicle at the nearest safe place. Refer to the “Engine
overheat” section in Chapter 9, and “Warning and indicator lights ”
section in Chapter 3. If your vehicle has an automatic transmission, avoid using the
accelerator pedal to stay stationary on an uphill slope instead of usingthe parking brake or foot brake. That may cause the transmission fluidto overheat. Also, if your vehicle is equipped with an automatic trans-mission, avoid driving with the gear selector lever in “D” when towing
a heavy trailer to prevent fluid overheating. A lower gear should beused. n Parking on a grade
Always block the wheels under both vehicle and trailer when parking.
Apply the parking brake firmly. You should not park on a hill or slope.But if parking on a hill or slope cannot be avoided, you should takethe following steps:
1. Apply the brakes and hold the pedal down.
2. Have someone place wheel blocks under both the vehicle and
trailer wheels.
3. When the wheel blocks are in place, release the regular brakes
slowly until the blocks absorb the load.
4. Apply the regular brakes and then apply the parking brake; slowly
release the regular brakes.
5. Shift into 1st or reverse gear (manual transmission) or “P” (auto-
matic transmission) and shut off the engine.

In case of emergency9-3
–
CONTINUED –
Jack and tools
The jack supplied with the vehicle is designed only for changing a tire.
Before using the jack, see the “Flat tire ” section in this chapter for
instructions and precautions.
Location of jack and tools
HB9057BAHBF053BA
The jack and tool bag are located in the left side rear quarter pocket
at the back side of the rear seatback.
HB9073AA
A wheel nut wrench, jack drive tube, tire holding rod, tire holding
retainer, screwdriver and moonroof wrench are included in the toolbag.

9-6
NOTE
Confirm no looseness exists after securing the jack. Looseness may cause a rattle while the vehicle is moving.CAUTION
After the jack and the tool bag have been restored in the rearquarter pocket, make sure that the rear seatback has been
securely locked. When securely locked, the red marks on thelocking knobs are no longer visible.
Spare tire
HB9053BA
The spare tire is stored in the spare tire holder located under the rear of the cargo bed.
The spare tire holder has a hoist mechanism that can lower and raise the
spare tire easily. The spare tire holder is designed to carry only the tem-
porary spare tire that comes with your vehicle.
Before using the temporary spare tire, see the “Temporary spare tire ”
section in this Chapter for instructions and precautions.
Removing the spare tire
1. Take the wheel nut wrench out of the tool bag. Refer to the “Jack
and tools ” section in this Chapter for its storage location.

In case of emergency9-7
–
CONTINUED –
HB9054BA
2. Open the tailgate and remove the rubber cap from the cargo bed. Pull up the “RELEASE” portion of the cap when removing it.
3. Locate the hex-headed hoist shaft end inside the hole.
HB9055BA
4. Turn the hoist shaft end counterclockwise with the wheel nut
wrench until the temporary spare tire is on the ground with enough
cable slack to allow you to pull it out from under the vehicle.
CAUTION
Do not put your fingers into the center hole of the temporaryspare tire while you pulling it out, because they might be pinched
in between the wheel and the retainer.
