2003 SUBARU BAJA ground clearance

Driving tips8-7
–
CONTINUED –
ing. Therefore, when driving down a slope or turning corners, be sure to
reduce your speed and maintain an ample distance from other vehicles.When replacing a tire, make sure you use only the same size, circum-
ference, construction, brand, and load range as the original tires listed on
the tire placard. Using other sizes, circumferences or construction may re-
sult in severe mechanical damage to the drive train of your vehicle and
may affect ride, handling, braking, speedometer/odometer calibration, and
clearance between the body and tires. It also may be dangerous and lead
to loss of vehicle control. If you use a temporary spare tire to replace a flat tire, be sure to use
the original temporary spare tire stored in the vehicle. Using other sizes
may result in severe mechanical damage to the drive train of your vehicle. Always check the cold tire pressure before starting to drive. The rec-
ommended tire pressure is provided on the tire placard, which is locatedunder the door latch on the driver ’s side.
Tire chains should always be placed on the front wheels only.
There are some precautions that you must observe when towing your
vehicle. For detail information, see “Towing” section in Chapter 9.
Off road driving
WARNING
Always maintain a safe driving speed according to the road
and weather conditions in order to avoid having an accident on asharp turn, during sudden braking or under other similar condi-tions. Always use the utmost care in driving – overconfidence
because you are driving an all wheel drive vehicle could easilylead to a serious accident.
Because of the AWD feature and higher ground clearance, your Subaru
can be driven on ordinary roads or off-road. But please keep in mind that
an AWD Subaru is neither a conventional off-road vehicle nor an all-ter-
rain vehicle. If you do take your Subaru off-road, certain common sense
precautions such as the following should be taken:

Maintenance and service11-43
–
CONTINUED –
racy. It also creates incorrect body-to-tire clearances and inappropriately changes the vehicle ’s ground clearance.
All four tires must be the same in terms of manufacturer, brand (tread
pattern), construction, and size. You are advised to replace the tires with
new ones that are identical to those fitted as standard equipment.
For safe vehicle operation, SUBARU recommends replacing all four tires at the same time.
WARNING
All four tires must be the same in terms of manufacturer, brand
(tread pattern), construction, degree of wear, speed symbol, loadindex and size. Mixing tires of different types, sizes or degrees ofwear can result in damage to the vehicle ’s power train. Use of dif-
ferent types or sizes of tires can also dangerously reduce con-trollability and braking performance and can lead to an accident. Use only radial tires. Do not use radial tires together with
belted bias tires and/or bias-ply tires. Doing so can dangerously
reduce controllability, resulting in an accident.
Wheel replacement
When replacing wheels due, for example, to damage, make sure the re-
placement wheels match the specifications of the wheels that are fitted
as standard equipment. Replacement wheels are available from
SUBARU dealers.
WARNING
Use only those wheels that are specified for your vehicle. Wheelsnot meeting specifications could interfere with brake caliper op-eration and may cause the tires to rub against the wheel wellhousing during turns. The resulting loss of vehicle control couldlead to an accident.

12-2
Specifications
These specifications are subject to change without notice. Dimensions
Overall length 199.3 in (4,910 mm)
Overall width 70.1 in (1,780 mm)
Overall height 61.2 in (1,555 mm)
Ground clearance 7.3 in (185 mm)
Front tread 57.9 in (1,470 mm)
Rear tread 57.7 in (1,465 mm)
Wheelbase 104.3 in (2,650 mm)
Engine
Engine model EJ251
Engine type Horizontally opposed, liquid cooled
4 cylinder, 4 stroke gasoline engine
Engine displacement 2,457 cc (150 cu in.)
Bore 3.92 in (99.5 mm)
Stroke 3.11 in (79.0 mm)
Compression ratio 10.0 : 1
Firing order 1 - 3 - 2 - 4
Electrical system
Battery type and capacity
MT: 55D23L
AT: 75D23L
Alternator 12V-90A
Spark plugs type RC10YC4 (Champion) BKR6E-11 (NGK)BKR5E-11 (NGK)
Capacities
Fuel tank 16.9 US gal (64 liters, 14.1 Imp gal)
Engine oil 4.2 US qt (4.0 liters, 3.5 Imp qt)
