2003 SUBARU BAJA coolant

Maintenance and service11-15
–
CONTINUED –
HG0115
Rubber gaskets
3. After refilling the reserve tank and the radiator, reinstall the caps
and check that the rubber gaskets inside the radiator cap are in the
proper position. Changing the coolant
WARNING
Never attempt to remove the radiator cap until the engine has
been shut off and has cooled down completely. Since the coolantis under pressure, you may suffer serious burns from a spray ofboiling hot coolant when the cap is removed.
Change the engine coolant using the following procedures according
to the maintenance schedule in the “Warranty and Maintenance Book-
let”. 1. Remove the under cover.
2. Place a proper container under the drain plug and loosen the drainplug.

11-16
HBB006BB
3. Loosen the radiator cap to drain the coolant from the radiator. Then
drain the coolant from the reserve tank. Tighten the drain plug secure-
ly.
HBB004FB
HBB007CB
4. Slowly pour the coolant and fill to the radiator filler neck and to the
reserve tank ’s “FULL” level mark. Do not pour the coolant too quickly,
as this may lead to insufficient air bleeding and trapped air in the sys-tem.
Coolant capacity (Guideline): MT. 7.2 US qt (6.8 liters, 6.0 Imp qt)
AT. 7.1 US qt (6.7 liters, 5.9 Imp qt)

Maintenance and service11-17
–
CONTINUED –
HG0115
Rubber gaskets
5. Put the radiator cap back on and tighten firmly. At this time, make
sure that the rubber gasket in the radiator cap is correctly in place.
6. Start and run the engine for more than five minutes at 2,000 to
3,000 rpm.
7. Stop the engine and wait until the coolant cools down (122 to140 °F [50 to 60 °C]). If there is any loss of coolant, add coolant to the
radiator’ s filler neck and to the reserve tank ’s “FULL” level.
8. Put the radiator cap and reservoir cap back on and tighten firmly.
Air cleaner element
WARNING
Do not operate the engine with the air cleaner element removed.The air cleaner element not only filters intake air but also stops
flames if the engine backfires. If the air cleaner element is not
installed when the engine backfires, you could be burned.
The air cleaner element functions as a filter screen. When the element is
perforated or removed, engine wear will be excessive and engine life
shortened.
The air cleaner element is a viscous type. It is unnecessary to clean or wash the element.

11-44
Aluminum wheels
Aluminum wheels can be scratched and damaged easily. Handle them
carefully to maintain their appearance, performance, and safety. When any of the wheels is removed and replaced for tire rotation or to
change a flat, always check the tightness of the wheel nuts after driving
approximatly 600 miles (1,000 km). If any nut is loose, tighten it to the
specified torque. Never apply oil to the threaded parts, wheel nuts, or tapered surface
of the wheel. Never let the wheel rub against sharp protrusions or curbs.
Be sure to fit tire chains on uniformly and completely around the tire,
otherwise the chains may scratch the wheel. When wheel nuts, balance weights, or the center cap is replaced, be
sure to replace them with genuine SUBARU parts designed for aluminumwheels.
Windshield washer fluid
CAUTION
Never use engine coolant as washer fluid because it could cause paint damage.
Check the level of the washer fluid at each fuel stop. If the level is low, fill
the fluid up to the neck of the reservoir.Use windshield washer fluid. If windshield washer fluid is unavailable use
clean water.
In areas where water freezes in winter, use an anti-freeze type windshield
washer fluid. SUBARU Windshield Washer Fluid contains 58.5% methyl
alcohol and 41.5% surfactant, by volume. Its freezing temperature varies
according to how much it is diluted, as indicated below.

Specifications12-3
–
CONTINUED –
Transmission oil (MT) 3.7 US qt (3.5 liters, 3.1 Imp qt)
Transmission fluid (AT) 9.8 US qt (9.3 liters, 8.2 Imp qt)
AT differential gear oil 1.3 US qt (1.2 liters, 1.1 Imp qt)
Rear differential gear oil 0.8 US qt (0.8 liters, 0.7 Imp qt)
Power steering gear fluid 0.7 US qt (0.7 liter, 0.6 Imp qt)
Engine coolant MT 7.2 US qt (6.8 liters, 6.0 Imp qt)
AT 7.1 US qt (6.7 liters, 5.9 Imp qt)
Tires
Type Steel belted radial, Tubeless
Size P225/60R16 97H Temporary spare T145/80R16
Pressure
Front Light load 30 psi (210 kPa, 2.1 kg/cm 2
)
Full load 30 psi (210 kpa, 2.1 kg/cm 2
)
Trailer towing 30 psi (210 kPa, 2.1 kg/cm 2
)
Rear Light load 29 psi (200 kPa, 2.0 kg/cm 2
)
Full load 33 psi (230 kpa, 2.3 kg/cm 2
)
Trailer towing 33 psi (230 kPa, 2.3 kg/cm 2
)
Temporary spare 60 psi (420 kPa, 4.2 kg/cm 2
)
Wheel size 16 x 6 1
/2 JJ
Wheel alignment
Toe Front 0 0.12 in (0 3 mm)
Rear 0 0.12 in (0 3 mm)
Camber Front 0 °20’ 30 ’
Rear –0 °10’ 45 ’
