2003 SUBARU BAJA audio

Audio5-9
–
CONTINUED –
Fast forwarding and fast reverse
n Fast forward
Press the “ ” button Q continuously for more than 0.5 second to fast
forward the disc.
Release the button to stop fast forwarding. n Fast reverse
Press the “ ” button W continuously for more than 0.5 second to fast
reverse the disc.
Release the button to stop fast reverse. Repeat playback
Use this to play a certain track repeatedly. During playback, press the
“RPT” button
R and release it in less than 2 seconds. The “RPT” indi-
cator will come on and the song will be played continuously. To can-
cel the repeat mode, press the button again. Then the “RPT” indicator
goes out, and normal playback mode is restored. Random playback
Use this to play the tracks on the disc in random order. During play-
back, press the “RDM” button
E and hold it in for more than 2 se-
conds. The “RDM” indicator will come on and all songs on the disc
will be played in a random order.
To cancel the random mode, press the button again. Then the “RDM”
indicator goes out, and normal playback mode is restored. Scan
Press the “SCAN” button
T and release it in less than 2 seconds, and
you can hear the first 10 seconds of each track to search for the
desired program. To continue listening to the program, press the
“SCAN” button again. After all tracks on the disc has been scanned,
normal playback mode is restored. To eject a disc from the player
When a disc is being played back or when a disc is in the player,
press the eject button “
” 9 . The disc will be ejected.
The disc may be removed even when the ignition switch is in the
“LOCK” position.

5-10
NOTE Avoid driving the vehicle with a CD sticking out, because
vibration might make it fall out. To protect the disc, the disc is automatically loaded if it is left
in the ejected position for more than approximately 15 seconds(Auto Reload). In this case, the disc is not played.
CD changer control (If optional in dash CD changer is connected) An optional CD changer can be connected to this audio unit. See your
SUBARU dealer for more information. For procedures for loading and un-
loading CDs, refer to “In-dash 6 CD auto changer ” in this chapter.
HB5067DB
U CD button
I Track selection buttons
O RAND (Random) button P
RPT (Repeat) button
A SCAN button
To start playback
Press the “CD” button U. The “CD” indicator will come on and the
disc number will appear on the display and the CD changer will start playback.

Audio5-11
–
CONTINUED –
NOTE If the “CD” button is pressed during a radio broadcast, the CD
changer will interrupt the broadcast. At the end of the disc, playback automatically continues with
the next disc. After playback on the last disc finishes, the player will auto-
matically return to the first disc. If you have loaded fewer than 6 discs, any missing disc is
automatically skipped. Selection of a desired disc
Discs cannot be selected using the main audio unit. To select a disc,
press one of the “Disc select ” buttons (these are numbered from 1 to
6) on the CD changer unit. The disc will begin to play. To select a song from its beginning
Briefly press the “ ” button
I to skip to the beginning of the next
track and briefly press the “ ” button to skip to the beginning of the
current track. Fast-forwarding and fast-reverse
Press the “ ” button I continuously for more than a half second to
fast-forward the disc.
Press the “ ” button continuously for more than a half second to fast
reverse the disc.
Release the button to stop fast forwarding or fast reverse. Repeat
Press the “RPT” button
P while a song is playing to play the song
repeatedly. The “RPT” indicator will come on and the song will be
played continuously. To cancel the repeat mode, press the button
again. Then the “RPT” indicator goes out, and normal playback mode
is restored. Random playback
Press the “RAND” button
O while a disc is being played back to play
all songs on the disc in a random order. The “RAND” indicator will
come on and all songs on the disc will be played in a random order.

Audio5-13
–
CONTINUED –
In-dash 6 CD auto changer (if equipped)
HB5040BB
1 Disc slot
2 Disc indicators (disc No.1 to 6) 3
Disc select buttons (disc No.1 to 6)
4 Eject button
CAUTION
Do not attempt to insert two or more discs into the slot at a
time. Doing so can cause mechanical damage to the CD changer. Use only music CDs identified by a
mark.
Do not use CDs listed below which could cause damage to the
CD player.
3-inch (8 cm) compact disc.
Any disc with a peel-off or seal on it.
Any disc with scratches and/or dust.
Bent disc.
Cleaning disc.
CD accessory. (E.g., 3-inch (8 cm) disc adapter)
Do not insert or remove any disc when the automatic transmis-
sion selector lever is in the park position; the selector lever in that position can interfere with disc insertion or removal, causing
scratches on the disc surface (for AT vehicles).

Audio5-15
–
CONTINUED –
To remove all discs at one time
1. Press and hold the “Eject” button 4 until all “Disc” indicators begin
blinking (about 1.5 seconds), and the first disc will be ejected.
2. When the disc is removed, the next one will be ejected, and so on. To replace a playing disc with another
Simply press the desired one of “Disc select ” buttons
3 (numbered
from 1 to 6) or press the “DISC UP ” or “DISC DOWN ” button on the
radio unit to select the desired disc, and the disc will begin to play. Disc indicators
Lit: when the corresponding storage tray is occupied by a disc. Blinking: Disc player is either in loading, eject or changing mode.OFF: No disc is loaded or the ignition switch is in the “LOCK” position.
Function control
Refer to CD player control operating instructions described in the“ AM/FM radio with CD player ” section.

Audio5-17
–
CONTINUED –
HB5061BA

Interior and exterior equipments6-7
–
CONTINUED –
Rear quarter storage box
HB6040BB
The rear quarter storage box is located on the right side of the back
panel behind the rear seatback.
To open the box:
1. Unlock the rear seatback locks by pulling the lock release knob up
and fold the rear seatback forward. Refer to “Rear seats ” section in
Chapter 1 for operating details.
2. Unlock the knob of rear quarter box cover and open the cover.
CAUTION
After returning the seatback to its original position, make sure
that the rear seatback has been securely locked. When securely
locked, the red marks on the locking knobs are no longer visible.
Cup holder
CAUTION
Do not pick up a cup from the cup holder or put a cup in the
holder while you are driving, as this may distract you and lead toan accident. Take care to avoid spills. Beverages, if hot, might burn you or
your passengers. Spilled beverages may also damage upholstery,carpets or audio equipment.
