64 Instruments and controls Check fuse 1 (radiator fan) in the fuse panel
under the hood, see page 230.
If the needle repeatedly enters the red zone,
stop the car as soon as it is safe to do so and
check the coolant level by looking at the
level visible through the plastic tank – do not
remove the cap.
If the coolant level falls below the MIN mark,
the Saab Information Display (SID) will dis-
play the message ”FILL COOLANT FLUID”.
Pressure gaugeThe turbo gauge indicates the air volume for
combustion, which is equivalent to the
engine load.
At low loads, the needle will move within the
white zone. At higher loads and during
heavy acceleration, the needle will enter the
yellow area. At very high loads or under cer-
tain barometric conditions, the needle may
enter the first part of the red zone without
indicating that there is a fault.If the needle repeatedly enters the red zone
and the engine at the same time loses
power, because the monitoring system is
holding the charging pressure down, you
should contact an authorized Saab dealer.
If the speed exceeds 149 mph/240 km/h
(155 mph/250 km/h, 9-5 Aero) the increase
in speed will be limited by the lowering of the
boost pressure. The pressure gauge then
moves towards the middle of the orange
zone, indicating reduced engine output and
thus reduces the speed of the car as well.
NOTICEIf the needle, despite the above action,
enters the red zone, stop the car immedi-
ately, let the engine idle.
If the needle stays in the red zone, stop
the engine.
WARNING
Never open the cap of the expansion tank
completely when the engine is hot, open
with care. The pressure in the cool-
ing-system can cause hot coolant and
steam to be released. Failure to heed this
warning may result in personal injury.
IB344
ProCarManuals.com

184 Starting and drivingTrailer hitch loadThe weight distribution on the trailer makes
a lot of difference to the handling properties
of the car and trailer combination. As
regards single-axle trailers, whenever pos-
sible, concentrate the load over the wheels
and keep it as low as possible.
The trailer should be loaded so that the
maximum load on the towbar ball is 5 % to
7 % of the trailer weight with a maximum
permissible tongue weight of 110–165 lbs.
(50–75 kg).
Note that this load must be added to the total
load for the car. If this now exceeds the
specified load capacity, the load in the lug-gage compartment will have to be reduced
by a corresponding amount.
WARNING
When you connect the trailer be sure to
attach its safety chains to the holes as
illustrated.
IB106
Distribution of load in trailer a Light
b Moderate
cHeavy
Attach the safety chains to the holes as
illustrated.
ProCarManuals.com

259 Specifications
Trailer:

Luggage compartment
Volume (SAE):
9-5 Sedan _______________________ 15.9 cu.ft.
(450 litres)
9-5 Wagon, rear seat upright ________ 31.4 cu. ft.
(890 litres)
9-5 Wagon, rear seat folded _________ 73.0 cu. ft.
(2067 litres)
Luggage compartment, length, 9-5 Sedan:
Rear seat upright _________________ 43.0 in (1092 mm)
Rear seat folded down _____________ 67.5 in (1714 mm)
Luggage compartment, length, 9-5 Wagon:
Rear seat upright _________________ 42.8 in (1087 mm)
Rear seat folded __________________ 61.2 in (1732 mm)
WARNING
 The GVW and maximum axle loads must not be exceeded.
Note that if some accessories (e.g. towbar, CD changer) are
fitted, the available load capacity is reduced by the weight of
these.
 When carrying a load in the luggage compartment, make sure
that it is tied down securely, particularly when part or all of the
rear seat is folded down.
Maximum towing speed, trailer with brakes 60 mph (100 km/h)
Trailer with brakes _________________ Maximum weight:
3500 lbs (1588 kg)
Trailer without brakes ______________ Maximum weight:
1000 lbs (450 kg)
Maximum load on ball hitch __________ 110–165 lbs
(50–75 kg)
The above speed and weight restrictions are those specified by
Saab Automobile AB.
Note that local restrictions may apply to trailer speeds and
weights (see page 181).
ProCarManuals.com

276 IndexSpeed rating
___________________ 232
Speedometer _______________ 62
, 63
Starting in cold weather, ACC
_______ 83
Starting in hot weather, ACC _______ 83
Steering wheel adjustment
________ 124
Steering, technical data
__________ 265
Stone-chip damage, repairing
______ 245
Storage compartments
___________ 136
Sun visors
_____________________ 135
Sunroof
_______________________ 132
Suspension
____________________ 265
Suspension, technical data
________ 265
Switches
_______________________ 71
Symbols _______________________ 10
Systems, adjustment
_____________ 271
TTCS OFF
_______________________ 61
Table of fuses
__________________ 228
Tachometer
_____________________ 62
Tailgate, opening
________________ 46
Tank gauge
_____________________ 63
Technical data __________________ 257
Telematics
_____________________ 111
Temperature control, ACC
_________ 79
Temperature gauge, engine ________ 63
Temperature zones, ACC
__________ 79
Textile carpeting
________________ 243
Through-load hatch ______________ 141
Tie Downs
_____________________ 141
Tightening torque, wheel studs
_____ 237
Tip, driving at night
______________ 186Tip, to avoid theft
________________195
Tire markings
_____________ 232
, 233
Tire pressure
______________ 187
, 232
Tires
____________________ 232
, 267
Tires, winter
____________________266
Tools
_________________________149
Touching-in the paintwork
_________245
Towbar attachment
______________181
Towbar load
___________________184
Towing the car __________________189
Towing, automatics
______________189
Traction
_______________________175
Trailer weights
__________________259
Trionic
________________________201
Trip computer
___________________65
Trip meter
______________________62
Trunk
_________________________139
Trunk lid, opening
________________46
Turbo gauge
____________________64
Turbo, points to note
_____________155
UUnder the hood, 3.0t V6
__________200
Under the hood, 4-cyl
____________199
Upholstery and trim
______________243
Upholstery and trim, care of
_______243
Useful tips, ACC
_________________85
VVanity mirrors
__________________135
Ventilated front seats
_____________15
Viscosity, engine oil
______________260
WWarning labels
___________________ 8
Warning light, AIR BAG
___________ 38
Warning lights
__________________ 56
Washers
_____________________ 212
Washers, windshield
____________ 213
Washing the car
_______________ 244
Waxing and polishing
___________ 245
Wear indicators, tires ____________ 234
Wheel, change
________________ 237
Wheels and tires ___________ 232
, 267
Wheels and tires, sizes
__________ 266
Window glass sensor, car alarm
____ 49
Windshield washers
_____________ 75
Windshield wipers
_______________ 75
Winter tires
___________________ 266
Wiper blades, replacing
__________ 212
Wipers and washers
_________ 75
, 212
