2003 Peugeot 307 SW tow

14-04-2003
YOUR 307 SW IN DETAIL81
This mode permits:
- displaying of the vehicle on the map with the route proposed by the navigation if the guidance isactive,
- zooming in on the map in accor- dance with the eleven presetlevels,
- displaying of the "Navigation -
Guidance" contextual menu.
"Vehicle following on map" mode
From the general menu, the main "Map"
menu offers various options
for guidance management:
- switching to "Selection - Movement on map" mode,
- direction of the map towards the North or in the direction of the vehicle,
- recentering of the map around the vehicle,
- opening of the services selection window visible on the map, suchas hotels, service stations, etc.
- displaying of the window for ente- ring the description for recordingthe current position of the vehiclein a directory file.
Map*The contextual menu associated with
the "Map" application and
with the "Selection - Movement onmap" mode appears as a superim-
posed display, when these are in use
in the main screen window. This menu is limited to the following functions:
- displaying of the information on the location selected on the map,
- selection of a location on the map as a destination,
- storing of the location selected (postal address if available or, if it is not, GPS co-ordinates, so thatthey can be recorded in a directoryfile),
- switching to "Vehicle following on map" mode.
* DT colour screen only.
** During the year.
"Map" contextual menu

14-04-2003
YOUR 307 SW IN DETAIL87
Manual operation
If you wish, you can make a different
choice from that offered by the sys-
tem by changing a setting. The otherfunctions will still be controlled auto-
matically. Pressing the "AUTO"but-
ton returns the system to completelyautomatic operation.
4. Air conditioning
Press this button to switch
off the air conditioning. Thesymbol "ECO" is displayed.Automatic operation of the
air conditioning is resumed when the
button is pressed again. The symbol"A/C" is displayed. Notes It is quite normal that the condensa- tion created by the air conditioningresults in a flow of water under the
vehicle when it is stationary.
To prevent misting inside the vehicle
in cold or wet weather, it is advisableto avoid the "ECO" mode.
5. Air distribution
Pressing this button several times in successionenables the air flow to bedirected in turn towards:
- the windscreen (de-icing or demis- ting), - the windscreen and the footwells,
- the footwells,
- the centre and side vents and the
footwells,
- the centre and side vents.
6. Air flow
The flow of air can be increased or reducedby pressing buttons +
or - respectively.
7. Air intake Press this button for recir-
culation of the interior air.Recirculation, shown on
the display, enables the
passenger compartment to be insu-lated from exterior odours andsmoke.
Avoid prolonged recirculation of
interior air. To do this, press the button again to resume intake of
exterior air. Note
To prevent misting inside the vehicle
in cold or wet weather, it is advisableto avoid the "air recirculation" mode. 8. Switching the system off
The "OFF" button enables
the entire system to be swit-
ched off. A comfortabletemperature will no longer
be guaranteed. Pressing the "OFF", "AUTO" or
"visibility" button again switches
the system on again with the values
selected before it was switched off.
9. Demisting the rear screen and the mirrors
Press this button to demist the rear screen and the mir-
rors. Demisting switches off
automatically. It is possibleto stop operation of the
demisting before it is switched offautomatically by pressing the buttonagain.
Important precaution Operate the air conditioning for 5 to 10 minutes, once or twice a month,
to keep it in good working order. If the system does not produce cold
air, do not use it and contact your
PEUGEOT dealer.

14-04-2003
FRONT SEATS
1 - Forwards/backwards adjust-ment Lift the control and slide the seat forwards or backwards.
2 - Seat back angle adjustment Push the handle towards the
rear.
3 - Driver's or passenger's seat height adjustment Pull the handle upwards or push it downwards as many times asnecessary to obtain the requiredposition.
4 - Armrests These can be folded down andare removable.
To remove them, press the but- ton located between the armrestand the side of the seat and pullit.
YOUR 307 SW IN DETAIL
88

Notes:switching on the front fog
lamps switches the side lights on also. When the main beam headlamps are switched on, the front fog lamps
are switched off.
When the lights are switched off
automatically, the front fog lampsand the side lights will remain on(turn the ring rearwards to switch the
fog lamps off).
THE LIGHTS STALK Front and rear lights Selection is by turning ring A.
Lights off Side lights Dipped / main beam headlamps Automatic switching on of lights Dipped / Main beam change Pull the stalk towards you. Note:
with the ignition off, when the
driver's door is opened, a buzzer sounds if you have left your lights on. Front fog lamps and rear fog lamp Rotate the ring forwards to switch on
and backwards to switch off. The sta-tus is confirmed by the indicator lighton the instrument panel.
Vehicles fitted with a rear fog lamp (ring B)
Rear fog lamp
This only operates with the dipped /main beam headlamps.
Vehicles fitted with front fog lamps and a rear fog lamp (ring C)
Front fog lamps (first rota-tion of the ring forwards)
These operate with the side lightsand the dipped headlamps. Front and rear foglamps (2nd rotation ofthe ring forwards)
Note: to switch off the rear fog lamp
and the front fog lamps, turn the ringbackwards twice in succession. "Follow-me-home" lighting In poor light or at night, if you leave your vehicle, the side lights and dip-ped headlamps can be left on forapproximately one minute.
To do this:- place the key in the STOPposition,
- place the lights stalk in position 0,
- "flash" the headlamps,- get out of the vehicle and lock it.
YOUR 307 SW IN DETAIL
110
14-04-2003

14-04-2003
WINDSCREEN
WIPER STALK Front windscreen wiper with intermittent wipe 2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
I Intermittent wipe.
0 Off.
Single wipe (press downwards).
In the Intermittent position, the
wiping speed is in proportion to thevehicle speed. Front windscreen wiper withautomatic wipe
2 Fast wipe (heavy rain).
1 ormal wipe (moderate rain).
AUTO Automatic wipe.
0 Off.
Single wipe (press downwards).
In the AUTOposition, the wiping
speed is in proportion to the intensityof the rainfall. After the ignition has been swit-ched off, if the stalk was in a wipeposition, you must reactivate thisfunction:
- move the stalk to any position,
- then move it back to the required
position.
Special position of the front windscreen wiper
In the minute following switching off of the ignition, any action on the stalkpositions the wipers in the centre ofthe windscreen. This action enables you to position the wiper blades for winter parking,cleaning or replacement (See sec-tion "Practical information -Changing a wiper blade").
To park the wipers after this has been done, switch on the ignitionand operate the stalk.
Windscreen wash Pull the wipers stalk towards you. The windscreen wash, then the windscreen wipers, operate for afixed period.
YOUR 307 SW IN DETAIL
112

14-04-2003
YOUR 307 SW IN DETAIL125
BOOT LAYOUT
1. Grab handles and coat hooks
2. High load retaining net fastenings The high load retaining net can be fitted in the 2nd or
3rd row. Open the covers of the corresponding upper faste- nings. Fit the ends of the metal bar in these fastenings.Secure the two opaque material strap hooks in the sto-
wing rings on the floor. The rings are located directly below the corresponding upper fastenings. Pull the two straps taut.Secure the two hooks on the elastic parts of the opaque material in these rings. Note: the net must be positioned so that the label can
be seen from the boot. This ensures that the central
seat belt is routed correctly.
3. 12V Socket for accessories This is a 12 volt socket (lighter type), installed on theload space cover left support.
It is supplied with the ignition off.
4. Rear armrests with grab handle
5. Storage nets One of them contains the luggage retaining net.
6. Load space cover To install it:
Ð position one end of the cover roller in the 2nd row, Ð compress the opposite end of the roller and position
it,
Ð release it to allow it to engage,
Ð unroll the cover as far as the boot pillars,
Ð insert the cover guides in the rails in the pillars. To remove it:
Ð remove the cover guides from the pillar rails,
Ð return the cover into its roller,
Ð compress it and remove it from its support at the 2nd row,
To store it, pull it back and place it with the two storage nets, already lowered. Note: the roller has two hooks for securing the lugga-
ge retaining net depending on where it is installed.
7. Luggage retaining net Secure the net's seven hooks in the stowing rings and
the fastenings on the floor.
8. Luggage retaining net fastenings ("hammock" version) in the tailgate Fold the net in two. Secure the two centre hooks in the stowing rings on the
floor. Secure the net's remaining four hooks on the boot pillars.
See configuration of the nets (next page)

14-04-2003
Unlocking Pull on the handle and press the but- ton to release the handbrake. Illumination of this warninglight and of the STOPwar-
ning light, accompanied byan audible signal (while thevehicle is being driven) and
the message "handbrake on" on
the multi-function display, indicatesthat the handbrake is still on or hasnot been properly released.
Operating abnormality Any operating abnormality is indica- ted by an audible signal, accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation the gearbox operates in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when changing from Pto R
and from Nto R(this will not cause
any damage to the gearbox). Do not exceed 60 mph (100 km/h), keeping within the limit of localspeed restrictions.
Contact a PEUGEOT dealer as soon as possible. HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake.
YOUR 307 SW IN DETAIL 129
If the battery is flat and the lever is in position P, it
will be impossible tochange to another posi-tion.
ANTI-LOCK BRAKING SYSTEM
(ABS) AND THE ELECTRONICBRAKE FORCE DISTRIBUTION(EBFD)
The ABS, in conjunction with the electronic brake force distribution,increases the stability and manoe-vrability of your vehicle, particularlyon poor or slippery road surfaces. Note: when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
When this warning lightcomes on, accompanied bya buzzer and the message"ABS fault" , it indicates
that there is a malfunction of
the ABS, which can cause a loss ofcontrol of the vehicle when braking.
When this warning lightcomes on, connected to the
STOPand ABS warning
lights, accompanied by abuzzer and the message
"Braking fault" , it indicates that
there is a malfunction of the electro-nic brake force distribution, whichcan cause a loss of control of thevehicle when braking.

14-04-2003
Unlocking Pull on the handle and press the but- ton to release the handbrake. Illumination of this warninglight and of the STOPwar-
ning light, accompanied byan audible signal (while thevehicle is being driven) and
the message "handbrake on" on
the multi-function display, indicatesthat the handbrake is still on or hasnot been properly released.
Operating abnormality Any operating abnormality is indica- ted by an audible signal, accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation the gearbox operates in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when changing from Pto R
and from Nto R(this will not cause
any damage to the gearbox). Do not exceed 60 mph (100 km/h), keeping within the limit of localspeed restrictions.
Contact a PEUGEOT dealer as soon as possible. HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake.
YOUR 307 SW IN DETAIL 129
If the battery is flat and the lever is in position P, it
will be impossible tochange to another posi-tion.
ANTI-LOCK BRAKING SYSTEM
(ABS) AND THE ELECTRONICBRAKE FORCE DISTRIBUTION(EBFD)
The ABS, in conjunction with the electronic brake force distribution,increases the stability and manoe-vrability of your vehicle, particularlyon poor or slippery road surfaces. Note: when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
When this warning lightcomes on, accompanied bya buzzer and the message"ABS fault" , it indicates
that there is a malfunction of
the ABS, which can cause a loss ofcontrol of the vehicle when braking.
When this warning lightcomes on, connected to the
STOPand ABS warning
lights, accompanied by abuzzer and the message
"Braking fault" , it indicates that
there is a malfunction of the electro-nic brake force distribution, whichcan cause a loss of control of thevehicle when braking.
