2003 Peugeot 307 SW height

14-04-2003
3YOUR 307 SW AT A GLANCE
1 -Speaker (tweeter) location.
2 - Side window demisting vent.
3 - Windscreen demistingvents.
4 - Passenger air bag
5 - Multi-function display.
6 - Alarm button.
7 - Central locking button.
8 - Hazard warning lights switch.
9 - Lights and direction indicators stalk.
10 - Instrument dials.
11 - Steering wheel adjustmentcontrol.
12 - Windscreen wash-wipestalk.
Trip computer stalk.
13 - Driver's air bag.Horn.
14 - Audio remote control stalk. 15 -
Headlamp height adjustment.
16 - Electric mirror controls.Window controls.Rear window lockingcontrol.
17 - Steering lock and ignition.
18 - Cruise control switch.
19 - 12 V accessories socket.
20 - Passenger air bag disarming switch*.
21 - Rubbish container.
22 - Panoramic roof shutter switch.
23 - Can holder.
24 - Handbrake.
25 - Rear footwell heating vent.
26 - Gear lever.
27 - Front ashtray.
28 - Ventilation / air conditioningcontrols. 29 -
CD changer.
30 - RB3, RD3 or RT3 audio equipment.
31 - Central adjustable ventilation and air flowregulation vents.
32 - Side adjustable ventilationand air flow regulation vent.
33 - Fuse box.
34 - Glove box.
35 - Bonnet opening control.
* According to destination

14-04-2003
6YOUR 307 SW AT A GLANCE
FRONT SEATS 1- Forwards/backwards adjust- ment.
2- Seat back angle adjustment.
3- Driver or passenger seatheight adjustment.
4- Front removable armrest.
5- Head restraint height andangle adjustment
To raise or lower the headrestraint, pull it forwards, sliding it at the same time.
Never drive with thehead restraints removed.
6- Storage drawer.
7- ÒAviationÓ style table.
88

14-04-2003
Moving an additional seat:
- seat back angle adjustment (1),
- head restraint height adjust- ment (2),
- folding down (3),
- removal, refitting (4).
7YOUR 307 SW AT A GLANCE
REAR SEATS Moving a side seat:
- forwards/backwards adjust-
ment (1),
- seat back angle adjustment (2),
- head restraint height adjust- ment (3),
- folding down (4),
- removal, refitting (5). Moving the centre seat:
- forwards/backwards adjust-
ment (1),
- seat back angle adjustment, table position (2),
- head restraint height adjust- ment (3),
- folding down (4),
- removal, refitting (5).
90

14-04-2003
Safety auto-reverse: When the window is closing and meets an obstacle, it stops and lowers again.
ELECTRIC MIRRORS
10YOUR 307 SW AT A GLANCE
ELECTRIC WINDOWS
1 - Driver"s electric window
2 - Passenger"s electric window.
3 - Rear right electric window.
4 - Rear left electric window.
5 - Disarming the rear window switches. STEERING WHEEL HEIGHT
AND DEPTH ADJUSTMENT When stationary, pull handle A
to unlock the steering wheel.
 Adjust the height and depth of the steering wheel.
 Lock it by pushing handle Ain
fully.
Manual operation:  Press or pull the switch lightly.
The window stops as soon as the switch is released. Automatic operation:
Press or pull the switch firmly.
One touch completely opens or
closes the window.
11 7
 Slide switch 6to the right or
left to select the correspon-
ding mirror.
 Then move button 7in all four
directions to adjust.
 Return switch 6to the centre
position. When parking the vehicle, themirrors can be folded back
manually, electrically bypulling switch
6rearwards
or automatically on lockingthe vehicle.
11 8120

14-04-2003
FRONT SEATS
1 - Forwards/backwards adjust-ment Lift the control and slide the seat forwards or backwards.
2 - Seat back angle adjustment Push the handle towards the
rear.
3 - Driver's or passenger's seat height adjustment Pull the handle upwards or push it downwards as many times asnecessary to obtain the requiredposition.
4 - Armrests These can be folded down andare removable.
To remove them, press the but- ton located between the armrestand the side of the seat and pullit.
YOUR 307 SW IN DETAIL
88

14-04-2003
Never drive with the head restraints removed; theyshould be in place andcorrectly adjusted.
5 - Head restraint height andangle adjustment
To raise or lower the restraint, pull it forwards, sliding it at thesame time.
To remove the head restraint, place it in the top position, lift thelug using a coin and pull it for-wards and upwards at the sametime.
To put it back in position, locate the stems of the restraint in theholes, taking care to keep themin line with the seat back. Active seat back
(front seat)
This possesses a device to prevent"whiplash". When there is an impact from the
rear, the action of the body on theseat back forces the head restraintforwards and upwards, preventingthe head being thrown backwards.
6 - Storage drawers There is a storage drawer under each front seat.
- To open it, lift it and pull.
- To take it out, open it to its full extent, press the ends of the slides and lift it, then remove it complete-
ly.
Do not place heavy objects in thedrawers. Under the front passenger seat, the layout of the floor allows for storageof a first aid kit and a warning triangle(small version).
7 - "Aviation" style table There is an "aviation" style table, fit-
ted with a can holder, at the rear ofeach front seat. REAR HEAD RESTRAINTS These have a high position for when they are in use and a low position forwhen they are stored. The head restraints are also remo- vable.
To remove them, pull upwards as far as the stop, then press the lug (sideseat) or on the two lugs (centreseat).
YOUR 307 SW IN DETAIL
89
The adjustment is correct when the upper edge of thehead restraint is level withthe top of the head.

14-04-2003
Never drive with the head restraints removed; theyshould be in place andcorrectly adjusted.
5 - Head restraint height andangle adjustment
To raise or lower the restraint, pull it forwards, sliding it at thesame time.
To remove the head restraint, place it in the top position, lift thelug using a coin and pull it for-wards and upwards at the sametime.
To put it back in position, locate the stems of the restraint in theholes, taking care to keep themin line with the seat back. Active seat back
(front seat)
This possesses a device to prevent"whiplash". When there is an impact from the
rear, the action of the body on theseat back forces the head restraintforwards and upwards, preventingthe head being thrown backwards.
6 - Storage drawers There is a storage drawer under each front seat.
- To open it, lift it and pull.
- To take it out, open it to its full extent, press the ends of the slides and lift it, then remove it complete-
ly.
Do not place heavy objects in thedrawers. Under the front passenger seat, the layout of the floor allows for storageof a first aid kit and a warning triangle(small version).
7 - "Aviation" style table There is an "aviation" style table, fit-
ted with a can holder, at the rear ofeach front seat. REAR HEAD RESTRAINTS These have a high position for when they are in use and a low position forwhen they are stored. The head restraints are also remo- vable.
To remove them, pull upwards as far as the stop, then press the lug (sideseat) or on the two lugs (centreseat).
YOUR 307 SW IN DETAIL
89
The adjustment is correct when the upper edge of thehead restraint is level withthe top of the head.

14-04-2003
YOUR 307 SW IN DETAIL
96
Never leave one or more children alone and unsu-pervised in a vehicle.
Never leave a child or an animal ina vehicle which is exposed to thesun and has the windows closed.
To protect your young children from the sun, fit blinds on the rearwindows. Never leave the keys within reach
of children inside the car. Disarm the passenger air bag when installing a "rearwardsfacing" child seat on the front pas-senger seat. Otherwise, the childwould risk being killed or seriouslyinjured were the air bag to inflate. Observe strictly the recommenda- tions for assembling and securingthe child seat as shown in thechild seat instructions.
To prevent the doors from opening
accidentally, use the child lock*. Also, do not open the rear win- dows more than a third*.
* According to model.
Groups 2 and 3: from 15 to 36 kg
L4 - ''Recaro Start'': installed in the rear with a three-point seat belt. The height and width of the seat back and length of the seat cushion must be adjusted according to the age and build of your child.
L5- "Klippan Optima": installed in the rear with a three-point seat belt. From the age of 6 years (approximately 22 kg), the booster is used on itsown.
Refer to the "Summary table for the installation of child seats".
