2003 OLDSMOBILE AURORA Owners Manual

b
The following steps will tell you how to use the jack and
change a tire.
Removing the Spare Tire and Tools
The equipment you’ll need is in the trunk.
Instructions for changing your tires are on the inside of
the tire cover. You can rest the cover near you for
easy reference while you change the tire.
1. Lift the tire cover to gain access to the compact
spare tire and jacking equipment. See
Compact
Spare Tire on page 5-81 for more information.
5-72
ProCarManuals.com

2. Remove the wheel wrench and jack from the jack
3. Remove the compact spare tire from the trunk.
container.
A
The tools you’ll
be using include the jack (A) and wheel
wrench
(B).
Removing the Wheel Covers
insert the hooked end of the wheel wrench in one of the
two small notches in the center cover and pry the
cover
off. Do not drop the cover or lay it face down, as
it could be scratched or damaged.
5-73
ProCarManuals.com

Removing the Flat Tire and Installing
the Spare Tire
1. Position the wheel wrench securely over the wheel
nuts and turn the wrench counterclockwise to
loosen the wheel nuts, but don't remove them.
3. Turn the wheel wrench counterclockwise by hand to
lower the jack head until it fits under the vehicle.
2. Attach the wheel wrench to the bolt on the end of
the jack to create a jack handle.
5-74
ProCarManuals.com

I I
4. Near each wheel well is a notch in the frame to
position the jack head. Position the jack under
the vehicle and raise the jack head until it fits firmly
against the sheet metal.
Do not raise the vehicle
yet. Put the compact spare tire near you.
.
Getting u..-er a vehicle when it is ja,..ed up is
dangerous. If the vehicle slips
off the jack you
could be badly injured or killed. Never get
under
a vehicle when it is supported only by
a jack. Raising
, -ur vehic-- ____ h the jack imk.
Jpe..,
positioned can damage the vehicle and even
make the vehicle fall.
To help avoid personal
injury and vehicle damage, be sure to
fit the
jack
lift head into the proper location before
raising the vehicle.
5. Raise the vehicle by turning the wheel wrench
clockwise on the jack. Raise the vehicle far
enough
off the ground so there’s enough room for
the compact spare tire to fit underneath the
wheel well.
6. Remove all the wheel nuts and take off the flat tire.
5-75
ProCarManuals.com

7. Remove any rust or dirt
from the wheel bolts,
mounting surfaces
and spare wheel.
Rust or dirt on the wheel, or on the parts to
which
it is fastened, can make the wheel nuts
become loose after a time. The wheel could
come
off and cause an accident. When you
change a wheel, remove any rust or
dirt from
the places where the wheel attaches to the vehicle.
In an emergency, you can use a cloth
or a paper towel to do this; but be sure to use
a scraper or wire brush later, if you need to, to
get all the
rust or dirt off.
Never use oil or grease on studs or nuts. If
you do, the nuts might come loose. Your wheel
could fall
off, causing a serious accident.
I I
8. Place the compact spare tire on the wheel-mounting
surface.
5-76
ProCarManuals.com

9. Put the wheel nuts
back on with the
rounded end
of the
nuts toward the wheel.
Tighten each nut by
hand until the wheel
is held against
the hub.
If a nut cannot be tightened by hand, use the wheel
wrench, and see your dealer right away.
10. Lower the vehicle by turning the wheel wrench
counterclockwise. Lower the jack completely.
5-77
ProCarManuals.com

11. Using the wheel
wrench, tighten the
wheel nuts firmly in a
crisscross sequence as
shown.
Incorrect wheel nuts or improperly tightened
wheel nuts can cause the wheel to come loose
and even come
off. This could lead to an
accident. Be sure to use the correct wheel
nuts. If you have to replace them, be sure to
get new GM original equipment wheel nuts.
Stop somewhere as soon as you can and have
the nuts tightened with a torque wrench to the
proper torque specification. See ”Capacities
and Specifications”
in the Index for wheel nut
torque specification.
Nofice: Improperly tightened wheel nuts can lead
to brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten
the wheel
nuts in the proper sequence and to the proper
torque specification. See “Capacities and
Specifications”
in the index for the wheel nut torque
specification.
12. When the flat tire has been repaired or replaced,
reinstall the wheel cover. Be sure to position the
alignment pin on the cover with the notch in
the wheel. Apply pressure around the edge
of the
cap to snap it in place.
Do not use a hammer
or mallet to reinstall the cover.
Store the wheel cover in the trunk until you have
replaced the compact spare tire with
a regular tire.
Notice: Wheel covers won’t fit on your compact
spare. If you try to put a wheel cover on your
compact spare, you could damage the cover or the
spare.
5-78
ProCarManuals.com
