LT-222
INTERIOR ROOM LAMP

When the map lamp, personal lamp and ignition keyhole illumination are turned ON by the interior room lamp
timer, power is supplied

through 10A fuse [No. 21, located in fuse block (J/B)]

to map lamp terminal 3

to personal lamp RH and LH terminals 2, and

to ignition keyhole illumination terminal 1.
Ground is supplied

to map lamp terminal 2

to personal lamp RH and LH terminals 1, and

to ignition keyhole illumination terminal 2

through BCM terminal 48
With power and ground supplied, the map lamp, personal lamp and ignition keyhole illumination illuminate.
Timer Operation Condition

When BCM detects driver door is unlocked, the key is not inserted in the ignition key cylinder (key switch
OFF), and ignition knob switch is OFF (with Intelligent Key system), it determines that conditions for inte-
rior room lamp timer operation are met, and turns the room lamp ON for 30 seconds.

When BCM detects key is removed from ignition key cylinder (key switch OFF), it determines that condi-
tions for interior room lamp timer operation are met, and turns the room lamp ON for 30 seconds.

When BCM detects driver door is closed, and the key is not inserted in the ignition key cylinder (key switch
OFF), and ignition knob switch is OFF (with Intelligent Key system), it determines that conditions for inte-
rior room lamp timer operation are met, and turns the room lamp ON for 30 seconds.

When ignition knob turns to OFF from ON, Intelligent Key unit sends ignition knob switch signal
(ON→OFF) through CAN communication. When BCM detect ignition knob switch is turned to OFF by igni-
tion knob switch signal (ON→OFF), and the key is not inserted in the ignition key cylinder (key switch
OFF), it determines that conditions for interior room lamp timer operation are met, and turns the room
lamp ON for 30 seconds.
BCM does not activate the timer even a door other than the driver door is opened.
*: Setting can be changed by CONSULT-II. Refer to LT- 2 3 3 , "
WORK SUPPORT (INT LAMP)" .
Conditions for Canceling Timer
Timer operation is cancelled in any of the following conditions.

Driver door is locked.

Driver door is opened.

Ignition key switch or ignition knob is ON.
INTERIOR ROOM LAMP BATTERY SAVER CONTROL
If the interior room lamp switch is in DOOR position and the lamps left illuminated due to incompletely closed
door, BCM turns OFF the room lamp and ignition keyhole illumination in 30 or 60 minutes to prevent run down
of the battery. (Timer setting can be changed by CONSULT-II. Refer to LT- 2 3 4 , "
WORK SUPPORT (BATTERY
SAVER)" .)

When the ignition key switch or ignition knob is turned from ON to OFF, the timer is activated.

When any of the following door switch signal condition is changed with the ignition key switch in OFF posi-
tion, the timer is activated when the change is occurred.
Door switch signals: front door switch (driver side and passenger side) signal, rear door switch (LH and RH)
signal, front door lock assembly signal, key switch signal, ignition knob switch signal, central door unlock
switch signal and remote control unlock signal.

LT-230
INTERIOR ROOM LAMP

Terminals and Reference Values for BCMBKS001R8
Te r -
minal
No.Wire
colorSignal nameMeasuring condition
Reference value
Ignition
switchOperation or condition
7 LG/R Door lock status signal OFF Door unlock sensorUNLOCK posi-
tionApprox. 0 V
Other
Approx. 8.5 - 9.0
12 R/LFront door switch (pas-
senger side) signalOFFFront door switch
(passenger side)ON (open) Approx. 0 V
OFF (closed)
Approx. 7.5 - 8.0
13 R/BRear door switch RH sig-
nalOFF Rear door switch RHON (open) Approx. 0 V
OFF (closed)
Approx. 7.5 - 8.0
37B/R
*1
BR*2Key switch signal OFFVehicle key is removed. Approx. 0 V
Vehicle key is inserted. Battery voltage
38 R Ignition switch (ON) ON — Battery voltage
39 L CAN−H— — —
40 P CAN−L— — —
42 Y/RBattery power
supplyOFF — Battery voltage
47 R/W Step lamp output signal OFFFront door switch (driver side)
or front door switch (passenger
side)ON
(open)Battery voltage
OFF
(close)Approx. 0 V
48 Y Room lamp output signalOFF
Interior
room lamp
switch:
DOOR
positionVehicle
key is
insertedAny
door
switchON
(open)Approx. 0 V
OFF
(closed)Battery voltage
—Vehicle
key is
removedAfter the
inserted key is
removedApprox. 0 V
Ignition key is
ONBattery voltage
PKIC4868J
PKIB4960J
PKIB4960J

INTERIOR ROOM LAMP
LT-231
C
D
E
F
G
H
I
J
L
MA
B
LT

NOTE:
*1:WIth Intelligent Key
*2:Without Intelligent Key
How to Perform With Trouble DiagnosesBKS001R9
1. Confirm the symptom or customer complaint.
2. Understand operation description and function description. Refer to LT- 2 1 9 , "
System Description" .
3. Perform the Preliminary Check. Refer to LT- 2 3 2 , "
Preliminary Check" .
4. Check symptom and repair or replace the cause of malfunction.
5. Does the interior room lamp operate normally? If YES, GO TO 6. If NO, GO TO 4.
6. INSPECTION END
52 B Ground ON — Approx. 0 V
55 W/BBattery power
supplyOFF
— Battery voltage
57 V/W Trunk switch signal OFFTrunk room lamp
switchON (open) Approx. 0 V
OFF (close) Battery voltage
62 SBFront door switch (driver
side) signalOFFFront door switch
(driver side)ON (open) Approx. 0 V
OFF (closed)
Approx. 7.5 - 8.0
63 R/WRear door switch LH sig-
nalOFF Rear door switch LHON (open) Approx. 0 V
OFF (closed)
Approx. 7.5 - 8.0
64 BR/W Trunk lamp output signal OFFTrunk room lamp
switchON (open) Approx. 12 V
OFF (close) Approx. 0 V Te r -
minal
No.Wire
colorSignal nameMeasuring condition
Reference value
Ignition
switchOperation or condition
PKIB4960J
PKIB4960J

INTERIOR ROOM LAMP
LT-233
C
D
E
F
G
H
I
J
L
MA
B
LT

CONSULT-II Functions (BCM)BKS001RB
CONSULT-II can display each diagnostic item using the diagnostic test mode shown following.
CONSULT-II BASIC OPERATION
Refer to GI-34, "CONSULT-II Start Procedure" .
WORK SUPPORT (INT LAMP)
Operation Procedure
1. Touch “INT LAMP” on “SELECT TEST ITEM” screen.
2. Touch “WORK SUPPORT” on “SELECT DIAG MODE” screen.
3. Touch “SET I/L D−UNLCK INTCON” on “SELECT WORK ITEM” screen.
4. Touch “START”.
5. Touch “CHANGE SETT”.
6. The setting will be changed and “CUSTOMIZING COMPLETED ” will be displayed.
7. Touch “END”.
Display Item List
Reference between “MODE” and “TIME” for “TURN ON/OFF”
DATA MONITOR (INT LAMP)
Operation Procedure
1. Touch “INT LAMP” on “SELECT TEST ITEM” screen.
2. Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.
3. Touch either “ALL SIGNALS” or “SELECTION FROM MENU” on “SELECT MONITOR ITEM” screen.
4. When “SELECTION FROM MENU” is selected, touch individual items to be monitored. When “ALL SIG-
NALS” is selected, all the items will be monitored.
5. Touch “START”.
6. Touch “RECORD” while monitoring, then the status of the monitored item can be recorded. To stop
recording, touch “STOP”.
BCM diagnosis part Diagnosis mode Description
INT LAMPWORK SUPPORT Changes the setting for each function.
DATA MONITOR Displays BCM input data in real time.
ACTIVE TEST Operation of electrical loads can be checked by sending driving signal to them.
BATTERY SAVERWORK SUPPORT Changes the setting for each function.
DATA MONITOR Displays BCM input data in real time.
BCMSELF-DIAG RESULTS BCM performs self-diagnosis of CAN communication.
CAN DIAG SUPPORT MNTR The result of transmit/ receive diagnosis of CAN communication can be read.
Item Description CONSULT-II
SET I/L D−UNLCK INTCONThe 30 seconds glowing function the interior room lamps and the ignition keyhole
illumination can be selected.ON/OFF
ROOM LAMP ON TIM SETThe time to brighten illumination can be adjusted when the interior room lamps
and the ignition keyhole illumination is turned on.MODE 1 - 7
ROOM LAMP OFF TIM SETThe time to diminish illumination can be adjusted when the interior room lamps
and the ignition keyhole illumination is turned off.MODE 1 - 7
MODE 1 2 3 4 5 6 7
Time (sec.) 0.5 1 2 3 4 5 0
ALL SIGNALS Monitors all the items.
SELECTION FROM MENU Selects items and monitor them.

LT-234
INTERIOR ROOM LAMP

Display Item List
NOTE:
1. Vehicle with Intelligent Key system displays this item.
2. Vehicle with remote keyless entry system displays this item.
ACTIVE TEST
Operation Procedure
1. Touch “INT LAMP” on “SELECT TEST ITEM” screen.
2. Touch “ACTIVE TEST” on “SELECT DIAG MODE” screen.
3. Touch item to be tested and check operation of the selected item.
4. During the operation check, touching “OFF” deactivates the operation.
Display Item List
WORK SUPPORT (BATTERY SAVER)
Operation procedure
1. Select “BATTERY SAVER” on “SELECT TEST ITEM” screen.
2. Select “WORK SUPPORT” on “SELECT DIAG MODE” screen.
3. Select “ROOM LAMP BAT SAV SET” on “SELECT WORK ITEM” screen.
4. Touch “START”.
5. Touch “MODE1” or “MODE2” (ROOM LAMP TIMER SET)
6. Touch “CHANGE SETT”.
7. The setting will be changed and “CUSTOMIZING COMPLETED” will be displayed.
8. Touch “END”.
Monitor item Contents
IGN ON SW “ON/OFF” Displays “IGN position (ON)/OFF, ACC position (OFF)” judged from the ignition switch signal.
KEY ON SW “ON/OFF” Displays “Key inserted (ON)/key removed (OFF)” status judged from the key switch signal.
DOOR SW - DR “ON/OFF”Displays status of the driver door as judged from the driver door switch signal. (Door is open:
ON/Door is closed: OFF)
DOOR SW - AS “ON/OFF”Displays “Door open (ON)/Door closed (OFF)” status, determined from passenger door
switch signal.
DOOR SW - RR “ON/OFF”Displays “Door open (ON)/Door closed (OFF)” status, determined from rear door switch RH
signal.
DOOR SW - RL “ON/OFF”Displays “Door open (ON)/Door closed (OFF) ” status, determined from rear door switch LH
signal.
LOCK STATUS “ON/OFF”Displays “Door unlocked (ON) /Door locked (OFF) status, determined from door unlock sen-
sor signal.
CDL LOCK SW “ON/OFF”Displays “Door locked (ON)/Door unlocked (OFF) status, determined from central door lock
switch LOCK signal.
CDL UNLOCK SW “ON/OFF”Displays “Door unlocked (OFF)” status, determined from central door lock switch UNLOCK
signal.
I − KEY LOCK
NOTE 1“ON/OFF” Displays “Locked (ON)/other (OFF)” status, determined from lock signal.
I − KEY UNLOCK
NOTE 1“ON/OFF” Displays “Unlocked (ON)/other (OFF)” status, determined from unlock signal.
KEYLESS LOCK
NOTE2“ON/OFF” Displays “Locked (ON)/other (OFF)” status, determined from lock signal.
KEYLESS UNLOCK
NOTE2“ON/OFF” Displays “Unlocked (ON)/other (OFF)” status, determined from unlock signal.
CONSULT-II screen
displayTest item Description
INT LAMPMap lamp, personal lamp and
ignition key hole illumination
operationMap lamp, personal lamp and ignition keyhole illumination is operated by
switching operation ON-OFF when map lamp switch and personal switch is in
DOOR position.

INTERIOR ROOM LAMP
LT-235
C
D
E
F
G
H
I
J
L
MA
B
LT

Display Item List
DATA MONITOR (BATTERY SAVER)
Operation Procedure
1. Touch “BATTERY SAVER” on “SELECT TEST ITEM” screen.
2. Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.
3. Touch either “ALL SIGNALS” or “SELECTION FROM MENU” on “SELECT MONITOR ITEM” screen.
4. When “ALL SIGNALS” is selected, all the items will be monitored. When “SELECTION FROM MENU” is
selected, touch individual items to be monitored.
5. Touch “START”.
6. Touch “RECORD” while monitoring, then the status of the monitored item can be recorded. To stop
recording, touch “STOP”.
Display Item List
NOTE:
1. Vehicle with Intelligent Key system displays this item.
2. Vehicle with remote keyless entry system displays this item.Item Description CONSULT-II
ROOM LAMP TIMER SET Interior room lamp battery saver timer setting can be changed.MODE 1: 30 min.
MODE 2: 60 min.
ROOM LAMP BAT SAV SETInterior room lamp battery saver control mode can be changed in this mode.
Select interior room lamp battery saver control mode between ON and OFF.ON/OFF
ALL SIGNALS Monitors all the items.
SELECTION FROM MENU Selects items and monitor them.
Monitor item Contents
IGN ON SW “ON/OFF”Displays “IGN position (ON)/OFF, ACC position (OFF)” judged from the ignition switch sig-
nal.
KEY ON SW “ON/OFF” Displays “Key inserted (ON)/key removed (OFF)” status judged from the key switch signal.
DOOR SW - DR “ON/OFF”Displays status of the driver door as judged from the driver door switch signal. (Door is open:
ON/Door is closed: OFF)
DOOR SW - AS “ON/OFF”Displays “Door open (ON)/Door closed (OFF)” status, determined from passenger door
switch signal.
DOOR SW - RR “ON/OFF”Displays “Door open (ON)/Door closed (OFF)” status, determined from rear door switch RH
signal.
DOOR SW - RL “ON/OFF”Displays “Door open (ON)/Door closed (OFF) ” status, determined from rear door switch LH
signal.
LOCK STATUS “ON/OFF”Displays “Door unlocked (ON)/Door locked (OFF) status, determined from door unlock sen-
sor signal.
CDL LOCK SW “ON/OFF”Displays “Door locked (ON)/Door unlocked (OFF) status, determined from central door lock
switch LOCK signal.
CDL UNLOCK SW “ON/OFF”Displays “Door unlocked (OFF)” status, determined from central door lock switch UNLOCK
signal.
I − KEY LOCK
NOTE 1“ON/OFF” Displays “Locked (ON)/other (OFF)” status, determined from lock signal.
I − KEY UNLOCK
NOTE 1“ON/OFF” Displays “Unlocked (ON)/other (OFF)” status, determined from unlock signal.
KEYLESS LOCK
NOTE2“ON/OFF” Displays “Locked (ON)/other (OFF)” status, determined from lock signal.
KEYLESS UNLOCK
NOTE2“ON/OFF” Displays “Unlocked (ON)/other (OFF)” status, determined from unlock signal.

LT-238
INTERIOR ROOM LAMP

4. CHECK CIRCUIT BETWEEN BCM AND INTERIOR ROOM LAMPS
1. Disconnect map lamp connector, personal lamp (RH and LH) connector and ignition keyhole illumination
connector.
2. Check continuity between BCM harness connector (A) and map
lamp harness connector (B).
3. Check continuity between BCM harness connector (A) and per-
sonal lamp (RH and LH) harness connector (B).
4. Check continuity between BCM harness connector (A) and igni-
tion keyhole illumination connector (B).
5. Check continuity between BCM harness connector (A) and
ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
AB
Continuity
Connector Terminal Connector Terminal
M4 48 R8 2 Yes
PKID0115E
AB
Continuity
Connector Terminal Connector Terminal
M4 48RH R6
1Yes
LH R4
PKID0116E
AB
Continuity
Connector Terminal Connector Terminal
M4 48 M23 2 Yes
A
GroundContinuity
Connector Terminal
M4 48 No
PKID0117E

INTERIOR ROOM LAMP
LT-239
C
D
E
F
G
H
I
J
L
MA
B
LT

5. CHECK INTERIOR ROOM LAMPS POWER SUPPLY CIRCUIT
1. Connect map lamp connector, personal lamp (RH and LH) connector and ignition keyhole illumination
connector.
2. Check voltage between map lamp harness connector and
ground.
3. Check voltage between personal lamp (RH and LH) harness
connector and ground.
4. Check voltage between ignition keyhole illumination connector
and ground.
OK or NG
OK >> Replace bulb.
NG >> Repair harness or connector.
Terminals
Voltage
(Approx.) (+)
(-)
Map lamp connector Terminal
R8 3 Ground Battery voltage
PKID0114E
Terminals
Voltage
(Approx.) (+)
(-)
Personal lamp Connector Terminal
RH R6
2 Ground Battery voltage
LH R4
PKID0119E
Terminals
Voltage
(Approx.) (+)
(-)
Ignition keyhole
illumination connectorTerminal
M4 48 Ground Battery voltage
PKID0120E
