MA-10
PERIODIC MAINTENANCE

MAINTENANCE UNDER SEVERE DRIVING CONDITIONS
(Annual Mileage <30,000 Km [18,000 miles]/year)
The maintenance intervals shown on the preceding pages are for normal operating conditions. If the vehicle is
mainly operated under severe driving conditions as shown below, more frequent maintenance must be per-
formed on the following items as shown in the table.
Severe driving conditions
A — Driving in dusty conditions
B — Repeatedly driving short distances
C — Towing a trailer or caravan
D — Extensive idling
E — Driving in extremely adverse weather conditions or in areas where ambient temperatures are either
extremely low or extremely high
F — Driving in high humidity or mountainous areas
G — Driving in areas using salt or other corrosive materials
H — Driving on rough and/or muddy roads or in the desert
I — Driving with frequent use of braking or in mountainous areas
J — For models without EURO-OBD system
Driving condition Maintenance itemMainte-
nance
operationMaintenance intervalReference
page
A.........Air cleaner filter ReplaceEvery 30,000 km (18,000 miles)
or 24 monthsMA-20
,
MA-30
ABCD......Engine oil & engine oil
filter ReplaceEvery 7,500 km (4,500 miles) or
6 monthsMA-20
, MA-
21 , MA-30 ,
MA-31
......... JHeated oxygen sensor InspectEvery 30,000 km (18,000 miles)
or 24 monthsEC-150
, EC-
143 , EC-496
, EC-486
.....F....Brake fluid ReplaceEvery 15,000 km (9,000 miles)
or 12 monthsMA-40
. . C . . . . H . . Automatic transaxle fluid ReplaceEvery 30,000 km (18,000 miles)
or 24 monthsMA-36
......GH..Steering gear & linkage,
axle & suspension parts,
propeller shaft, front
drive shafts & exhaust
systemInspectEvery 15,000 km (9,000 miles)
or 12 monthsMA-41
, MA-
42 , MA-43
,MA-35
A.C...GHI.Brake pads, rotors &
other brake componentsInspectEvery 7,500 km (4,500 miles) or
6 monthsMA-41, MA-
41 , MA-41
A.........Air conditioner filter ReplaceEvery 15,000 km (9,000 miles)
or 12monthsAT C - 11 8

HARNESS
PG-63
C
D
E
F
G
H
I
J
L
MA
B
PG

Wiring Diagram Codes (Cell Codes) BKS002FS
Use the chart below to find out what each wiring diagram code stands for.
Refer to the wiring diagram code in the alphabetical index to find the location (page number) of each wiring
diagram.
Code Section Wiring Diagram Name
A/C ATC Air Conditioner
ABS BRC Anti-Lock Brake System
AFS LT Adaptive Front Lighting System
APPS1 EC Accelerator Pedal Position Sensor
APPS2 EC Accelerator Pedal Position Sensor
APPS3 EC Accelerator Pedal Position Sensor
ASC/BS EC Automatic Speed Control Device (ASCD) Brake Switch
ASC/SW EC Automatic Speed Control Device (ASCD) Steering Switch
ASCBOF EC Automatic Speed Control Device (ASCD) Brake Switch
ASCIND EC Automatic Speed Control Device (ASCD) Indicator
AT/IND DI A/T Indicator Lamp
AUDIO AV Audio
AUT/DP SE Automatic Drive Positioner
AUTO/L LT Auto Light Control
BA/FTS AT A/T Fluid Temperature Sensor and TCM Power Supply
BACK/L LT Back-Up Lamp
BRK/SW EC Brake Switch
CAN AT CAN Communication Line
CAN CVT CAN Communication Line
CAN EC CAN Communication Line
CAN LAN CAN System
CHARGE SC Charging System
CHIME DI Warning Chime
CIGAR WW Cigarette Lighter
COMBSW LT Combination Switch
COMM AV Audio Visual Communication Line
COOL/F EC Cooling Fan Control
CVTIND DI CVT Indicator Lamp
D/LOCK BL Power Door Lock
DEF GW Rear Window Defogger
ECM/PW EC ECM Power Supply for Back-Up
ECTS EC Engine Coolant Temperature Sensor
EMNT EC Electronic Controlled Engine Mount
ENGSS AT Engine Speed Signal
ETC1 EC Electric Throttle Control Function
ETC2 EC Electric Throttle Control Motor Relay
ETC3 EC Electric Throttle Control Motor
F/FOG LT Front Fog Lamp
F/LID BL Fuel Lid Opener
F/PUMP EC Fuel Pump
FRO2 EC Heated Oxygen Sensor 1 Heater

PG-64
HARNESS

FRO2B1 EC Heated Oxygen Sensor 1 Heater Bank 1
FRO2B2 EC Heated Oxygen Sensor 1 Heater Bank 2
FTS CVT CVT Fluid Temperature Sensor Circuit
H/AIM LT Headlamp Aiming Control System
H/LAMP LT Headlamp
HLC WW Headlamp Washer
HORN WW Horn
HO2S1 EC Heated Oxygen Sensor 1
HSEAT SE Heated Seat
I/KEY BL Intelligent Key System
IATSEN EC Intake Air Temperature Sensor
IGNSYS EC Ignition System
ILL LT Illumination
INF/D AV Vehicle Information and Integrated Switch System
INJECT EC Injector
INT/L LT Vanity Mirror Lamp
IVC EC Intake Valve Timing Control Solenoid Valve
IVCB1 EC Intake Valve Timing Control Solenoid Valve Bank 1
IVCB2 EC Intake Valve Timing Control Solenoid Valve Bank 2
KEYLES BL Remote Keyless Entry System
KS EC Knock Sensor
L/USSV CVT Lock-Up Select Solenoid Valve
LPSV AT Line Pressure Solenoid Valve
LPSV CVT Line Pressure Solenoid Valve
M/SEAT SE Air Massage Seat
MAFS EC Mass Air Flow Sensor
MAIN AT Main Power Supply and Ground Circuit
MAIN EC Main Power Supply and Ground Circuit
METER DI Speedometer, Tachometer, Temp. and Fuel Gauges
MIL/DL EC MIL & Data Link Connector
MIRROR GW Power Door Mirror
MMSW CVT Manual Mode Switch
NATS BL Nissan Anti-Theft System
NONDTC AT Non-Detective Items
NONDTC CVT Non-Detective Items
O2S1B1 EC Heated Oxygen Sensor 1 Bank 1
O2S1B2 EC Heated Oxygen Sensor 1 Bank 2
OVRCSV AT Overrun Clutch Solenoid Valve
PHASE EC Camshaft Position Sensor (PHASE)
PHSB1 EC Camshaft Position Sensor (PHASE) (Bank1)
PHSB2 EC Camshaft Position Sensor (PHASE) (Bank2)
PNP/SW CVT Park/Neutral Position Switch
PNP/SW EC Park/Neutral Position Switch
POS EC Crankshaft Position Sensor (CKPS) (POS) Code Section Wiring Diagram Name
