2003 MERCEDES-BENZ E-CLASS start stop button

301 Practical hints
What to do if …
P
Gear selector lever in P
You have turned off the engine with the
KEYLESS-GO* start/stop button* and
opened the driver’s door.

Place the selector lever in position P.
Cruise control
Visit workshop!
Cruise control or Distronic* is malfunction-
ing.

Have the cruise control or Distronic*
checked by an authorized
Mercedes-Benz Center.
1
Restraint system
malfunction
Visit workshop!
The system is malfunctioning.

Drive with added caution to the near-
est authorized Mercedes-Benz Cen-
ter.
@
Vehicle rising!
Your vehicle is adjusting to your level selec-
tion.
Level selec. canceled
The "Raised" level setting is canceled at ve-
hicle speeds of over 75 mph (120 km/h).

Reactivate the "Raised" level setting.
Display
Possible cause
Suggested solution
Warning!
G
In the event a malfunction of the SRS is indi-
cated as outlined above, the SRS may not be
operational. For your safety, we strongly
recommend that you visit an authorized
Mercedes-Benz Center immediately to have
the system checked; otherwise the
SRS may not be activated when needed in
an accident, which could result in serious or
fatal injury, or it might deploy unexpectedly
and unnecessarily which could also result in
injury.
ProCarManuals.com

309 Practical hints
What to do if …
Display
Possible cause
Suggested solution
F
Key
Check battery!
The batteries in the KEYLESS-GO*
key are discharged.

Change the batteries (
page 328).
Key
not recognized!
The KEYLESS-GO* key is not recog-
nized while the engine is running be-
cause

the card is not in the vehicle


there is strong radio-frequency
interference

Stop the vehicle as soon as it is safe to do
so.

Search for the card or continue to operate
the vehicle with the key.
Otherwise the vehicle cannot be centrally
locked nor can the engine be started again
after the engine is stopped.
The KEYLESS-GO* key is momen-
tarily not recognized.

Change the position of the card in the vehi-
cle.

Operate the vehicle with the key if neces-
sary.
ì
Function
Not available!
This display appears if button ì
or í on the multifunction steer-
ing wheel is pressed and the vehicle
is not equipped with a telephone.
ProCarManuals.com

327 Practical hints
Unlocking/locking in an emergency
Unlocking/locking in an emergency
Unlocking the vehicle
In case of a malfunction in the central lock-
ing system, you can unlock the trunk sepa-
rately (
page 88).
Unlocking the driver’s door
If you are unable to unlock the driver’s
door using the SmartKey, open the door
using the mechanical key.
1Mechanical key locking tab
2Mechanical key

Move locking tab1 in the direction of
the arrow and slide mechanical key2
out of the housing.
3Unlocking
4Locking

Unlock the door with the mechanical
key. To do so, push the mechanical key
in the lock until it stops and turn it to
the left4.
iUnlocking your vehicle with the me-
chanical key will trigger the anti-theft
alarm system. To cancel the alarm, do
one of the following:

Press button Œor ‹on the
SmartKey.


Insert the key in the starter switch.
ProCarManuals.com

350 Practical hintsTowing the vehicle
Installing towing eye bolt
Front of vehicle
1Cover on right side of front bumperTo remove cover:

Press mark on cover in direction of ar-
row.

Lift cover off to reveal threaded hole for
towing eye bolt.
The towing eye bolt is supplied with the
tool kit (located in the storage compart-
ment under the trunk floor).

Screw towing eye bolt in to its stop and
tighten with lug wrench.
To reinstall cover:

Fit cover and snap into place.
!When towing the vehicle with all wheels
on the ground, please note the follow-
ing:
With the automatic central locking acti-
vated and the key in starter switch
position2, or KEYLESS-GO* start/stop
button (if so equipped) in position2,
the vehicle doors lock if the left front
wheel as well as the right rear wheel
are turning at vehicle speeds of approx.
9 mph (15 km / h) or more.
To prevent the vehicle door locks from
locking, deactivate the automatic cen-
tral locking (
page 99).
Towing of the vehicle should only be
done using the properly installed tow-
ing eye bolt. Never attach tow cable,
tow rope or tow rod to the vehicle chas-
sis, frame or suspension parts.
iThe selector lever will remain locked in
positionP and the key will not turn in
the starter switch if the battery is dis-
connected or discharged. See notes on
the battery (
page 343) or on jump
starting (
page 346).
ProCarManuals.com

381 Index
A
ABS 73, 375
Malfunction indicator lamp 289
Messages in display 296
Warning lamp 289
Accelerator position, automatic
transmission 156
Accident
In case of 49
Activating
Air conditioning (cooling) 170, 181
Air recirculation mode 168, 178
Anti-theft alarm system 82
Automatic climate control 174
Central locking (control system) 142
Charcoal filter 180
Climate control 164
Defrost 167
Distance warning function* 206
Distronic* 202
Easy-entry/exit feature* 143
ESP 77
Exterior headlamps 46
Exterior lamps 113
Hazard warning flasher 115
Headlamps 46High beams 115
Ignition 31
Ignition with KEYLESS-GO* start/stop
button 33
Immobilizer 52, 81
Rear fog lamp 113
Rear window defroster 169, 180
Residual heat 171, 182
Tow-away alarm 83
Windshield wipers 47
Adjustable air outlets, rear passenger
compartment 182
Adjusting 34
Air distribution 166, 177
Air volume 166, 177
Backrest tilt 36
Exterior rear view mirror 39
Head restraint height 36
Head restraint tilt 36
Inside rear view mirror 38
Instrument cluster illumination 118
Mirrors 38
Multicontour seat* 104
Seat cushion depth 105
Seat cushion tilt 36
Seat fore and aft adjustment 35Seat height 35
Seats 34
Steering column height 38
Steering column length 38
Steering wheel 37
Air conditioner (cooling)
Turning off 170, 181
Turning on 170, 181
Air distribution
Adjusting 166, 177
Air outlets, rear passenger compartment
Adjustable 182
Air recirculation mode 167, 178
Activating 168, 178
Deactivating 168, 179
Air volume
Adjusting 166, 177
Airbags 57
BabySmart
TM airbag deactivation
system 67, 375
Children 58
Front 60
Passenger 60
Safety guidelines 59
Side impact 61
Window curtain 61
