2003 MERCEDES-BENZ E-CLASS trip computer

ContentsControls in detail............................... 85
Locking and unlocking ......................... 86
Keys ............................................... 86
SmartKey with KEYLESS-GO*......... 89
Opening the doors from the inside . 93
Opening the trunk from the inside.. 94
Opening the trunk .......................... 96
Closing the trunk ............................ 96
Trunk lid emergency release .......... 97
Separately locking the trunk .......... 98
Separately unlocking the trunk ...... 99
Automatic central locking .............. 99
Locking and unlocking from
the inside ..................................... 100
Seats.................................................. 102
Easy-entry/exit feature* .............. 102
Head restraints............................. 103
Multicontour seat* ....................... 104
Dynamic driving seat* .................. 105
Heated seats* .............................. 107
Seat ventilation* .......................... 108
Memory function................................ 109
Storing positions into memory ..... 110
Recalling positions from memory . 110
Storing parking position ............... 111Lighting.............................................. 112
Exterior lamp switch..................... 112
Combination switch ..................... 115
Hazard warning flasher ................ 115
Interior lighting............................. 116
Door entry lamps ......................... 117
Trunk lamp ................................... 117
Instrument cluster ............................. 118
Instrument cluster illumination .... 118
Coolant temperature display ........ 119
Trip odometer .............................. 119
Tachometer .................................. 120
Outside temperature indicator ..... 120
Control system .................................. 121
Multifunction display .................... 121
Multifunction steering wheel ........ 122
Menus .......................................... 124
Standard display menu ................ 126
AUDIO menu ................................ 126
NAVI* ........................................... 128
Distronic* menu........................... 128
Malfunction memory menu .......... 129
Settings menu .............................. 130
Trip computer menu ..................... 145
TEL menu* ................................... 147
Automatic transmission ..................... 151One-touch gearshifting ................ 152
Gear ranges ................................. 153
Gear selector lever position ......... 154
Program mode selector switch .... 155
Accelerator position ..................... 156
Emergency operation
(Limp home mode) ....................... 156
Good visibility .................................... 157
Rear view mirror .......................... 157
Headlamp cleaning system* ........ 158
Sun visors .................................... 158
Rear window sunshade* .............. 160
Roller sunblind* in the rear doors 161
Climate control .................................. 162
Setting the temperature............... 165
Adjusting air distribution .............. 166
Adjusting air volume .................... 166
Defrosting .................................... 167
Air recirculation mode.................. 167
Rear window defroster ................. 169
Deactivating the climate
control system ............................. 170
Air conditioner ............................. 170
Residual heat and ventilation* ..... 171
Automatic climate control* ............... 172
Setting the temperature............... 176
ProCarManuals.com

125 Controls in detail
Control system
Menus, submenus and functions
Menu 1
Menu 2
Menu 3
Menu 4
Menu 5
Menu 6
Menu 7
Menu 8
Commands/submenusStandard dis-
play
AUDIO
NAVI*
Distronic*
Malfunction
memory
Settings
Trip computer
Telephone
Digital speed-
ometer
Select radio
station
Activate
route guid-
ance
Call up set-
tings
Call up malfunc-
tion messages
Reset to factory
settings
Fuel consumption
statistics after
start
Load phone
book
Call up FSS
PLUS
Operate CD
player*
Instrument clus-
ter submenu
Fuel consumption
statistics since
the last reset
Search for
name in
phone book
Check tire pres-
sure*
Operate cas-
sette player
Time/Date sub-
menu
Call up range
Check engine oil
level
Lighting sub-
menuVehicle sub-
menuConvenience
submenuDynamic driving
seat* submenu
ProCarManuals.com

145 Controls in detail
Control system

Move the selection marker with
theæ orç button to
the
Convenience
submenu.

Press buttonj ork repeatedly
until you see this message in the dis-
play:
Mirror adjustment parking aid
.
The selection marker is on the current
setting.

Pressæ orç to switch function on or
off
.
Dynamic seat* submenu
Access the Dynamic Seat
submenu via the
Settings
menu. Use the
Dynamic Seat

submenu to change the settings for the dy-
namic seats. The following functions are
available:Adjusting the dynamic seat
The function dynamic seat adjustment lets
you determine the way the seat adjusts
while driving.

Move the selection marker with
theæ orç button to the Dynamic Seat
submenu.

Press buttonj ork repeatedly
until you see this message in the dis-
play:
Dyn. Multi-cont. Seat, driver
for the driver seat or Dyn. Multi-cont. Seat, fr. pass. for the passenger seat.
The selection marker is on the current
setting.

Pressæ orç to switch function Level 1
or
Level 2
.
Trip computer menu
Use the trip computer menu to call up sta-
tistical data on your vehicle. The following
information is available:
Function
Page
Adjust driver seat
141
Adjust passenger seat
141
Function
Page
Fuel consumption statistics after
start
see
below
Fuel consumption statistics
since last reset
146
Call up range (distance to empty)
147
ProCarManuals.com

146 Controls in detailControl systemFuel consumption statistics after start
Press buttonÿ orè repeatedly
until you see the first function of the
Trip computer menu.

Press buttonj ork repeatedly
until you see this message in the left
display:
After start
.
1Distance driven since start
2Time elapsed since start
3Average speed since start
4Average fuel consumption since startFuel consumption since last reset

Press buttonÿ orè repeatedly
until you see the first function of the
Trip computer menu.

Press buttonj ork repeatedly
until you see this message in the dis-
play:
After reset
.
1Distance driven since last reset
2Time elapsed since last reset
3Average speed since last reset
4Average fuel consumption since last re-
set
iAll statistics stored since the last en-
gine start will be reset approximately
four hours after the key in the starter
switch is turned to position0 or re-
moved from the starter switch.
Resetting will not occur if you turn the
key back to position1 or2 within this
time period.
ProCarManuals.com

147 Controls in detail
Control system
Resetting fuel consumption statistics
Press buttonÿ orè repeatedly
until you see the first function of the
Trip computer menu.

Press buttonj ork repeatedly
until you see the reading that you want
to reset in the display.

Press and hold the reset knob in the in-
strument cluster (
page 22) until the
value is reset to
0.Call up range (distance to empty)

Press buttonÿ orè repeatedly
until you see the first function of the
Trip computer menu.

Press buttonj ork repeatedly
until you see this message in the dis-
play:
Range:
In the display you will see the calculat-
ed range based on the current fuel tank
level.
TEL menu*Warning!
G
A driver’s attention to the road must always
be his/her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call. If you choose to use the tele-
phone while driving, please use the
hands-free device and only use the tele-
phone when road and traffic conditions per-
mit.
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a ve-
hicle.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of approximately
44 feet (approximately 13.5 m) every sec-
ond.
ProCarManuals.com

384 IndexClock 137
Closing
Glove box 226
Side windows 184
Side windows with KEYLESS-GO* 92
Sliding/pop-up roof* 187
Sliding/pop-up roof* with
KEYLESS-GO* 92
Sliding/pop-up roof* with
SmartKey 188, 192
Trunk lid 96
Windows 184
Windows with SmartKey 185
Cockpit 20, 375
COMAND* see separate operating instruc-
tions
Combination switch 115
High beam flasher 47
Turn signals 46
Windshield wipers 47
Consumer information 373
Control system 121, 376
AUDIO menu 126
Convenience submenu 143
Display digital speedometer 126
Distronic* menu 128Functions 125
Instrument cluster submenu 134,
136
Lighting submenu 138
Malfunction memory menu 129
Menus 124, 125, 378
Multifunction display 121
Multifunction steering wheel 122
Selecting radio system 127
Settings menu 130
Standard display menu 126
Submenus 123, 125
TEL* menu 147
Trip computer menu 145
Vehicle submenu 142
Convenience submenu 143
Activating easy-entry/exit
feature* 143
Setting key dependency 144
Setting parking position for exterior
rear view mirror 144
Coolant
Messages in display 311, 312
Temperature display 119
Warning lamp 292, 311
Cruise control 194, 376Canceling 195
Driving downhill 195
Driving uphill 195
Fine adjustment 196
Lever 201
Saving current speed 195
Setting speeds 196
Cruise control lever 194
Customer Assistance Center (CAC) 375
D
Daytime running lamp mode 114
Setting 139
Deactivating
Air conditioner 170
Air recirculation mode 168, 179, 180
Alarm 82
Anti-theft alarm system 82
Automatic climate control 169, 174
Central locking (control system) 142
Climate control 164
Cruise control 195
Defrost 167, 178
Distance warning function* 206
Distronic* 204
Engine with KEYLESS-GO* 53
Engine with the key 52
ProCarManuals.com

390 Index
Instruments 118, 119
Interior 116
Locator lighting 114
Low beam 112
Manual headlamp mode 113
Night security illumination 114
Parking lamps 112
Rear fog lamp 114
Settings (control system) 138
Trunk lamp 117
Limiting the gear range 153
Limp Home Mode 156
Loading 216
Cargo tie-down rings 225
Instructions 224
Roof rack 216
Ski sack* 216
Split rear bench seat 219
Locator lighting 114
Setting 139
Lock button 377
Door handle (KEYLESS-GO*) 53
Locking 50, 86
Automatic while driving 99
Centrally from inside 100
Fuel filler flap 259Global with KEYLESS-GO* 91
Global, SmartKey 87
Separately the trunk 98
Vehicle with KEYLESS-GO* 92
Loss of keys 89, 93
Low beam headlamps 332
Messages in display 313
M
Main Dimensions 364
Maintenance 12
Malfunction
Displaying 130
Malfunction memory 129
Calling up 129
Clearing 130
Manual headlamp mode 113
Manual operations
Interior lighting control 116
Locking the trunk 98
Unlocking the driver’s door 327
MB Tex upholstery
Cleaning 285
Mechanical key 327
Memory function 109, 377
Recalling positions from
memory 110Storing exterior rear view mirror park-
ing positions 111
Storing key dependent settings 110
Menus 124
AUDIO 126
Control system 378
Distronic* 128, 200
In control system 124, 125
Malfunction memory 129
Settings menu 130
Standard display 126
Submenus 123
TEL* 147
Trip computer 145
Miles/kilometers in speedometer
Setting 134
Mirrors
Adjusting 38
Automatic antiglare for rear view
mirror 157
Automatic antiglare* for inside
mirror 157
Exterior rear view mirror 39
Exterior rear view mirror parking
positions 144, 158
Inside rear view mirror 38
ProCarManuals.com

397 Index
Dialing a number from the phone
book 149
Ending a call 149
Loading phone book* 149
Messages in display 309
Operating 147
Redialing 149
Temperature
Display mode 134
Sensor 27
Setting interior temperature 165,
176
Setting units in display 134
Tie-down rings (trunk) 225
Tightening torque 342, 379
Time
Setting hours 137
Setting minutes 137, 138
Tire inflation pressure
Setting units 136
Tire speed rating 379
Tires 373
Tools 326
Tow-away alarm 82
Arming 82
Disarming 82Disarming for transport 82
Towing eye bolt (vehicle tool kit)
Installing 350
Towing the vehicle 348
Tracking services
For stolen vehicle 242
Traction 155, 379
Trip computer 145
Trip odometer
Resetting 119
Trunk
Closing the lid 96
Lamp 117
Lock button, KEYLESS-GO* 92
Message in display 310
Opening 88, 96
Opening from inside vehicle 94
Separately locking 98
Tie-down rings 225
Trunk lid emergency release 97
Unlocking with KEYLESS-GO* 92
Trunk lid
Closing 96
Turn signals 46
Additional in mirrors 332
Front bulbs 332Turning off
Engine 51
U
Units
Setting speedometer units 134
Setting temperature units 134
Setting tire inflation pressure
units 136
Unlocking 30, 86, 327
Centrally from inside 100
Driver’s door in an emergency 327
Fuel filler flap 259
Global 87
Global with KEYLESS-GO* 91
Selective settings 87
Trunk lid with KEYLESS-GO* 92
Vehicle in an emergency 241
With KEYLESS-GO* 32
With the SmartKey 30
Upgrade signals
Tele Aid* 240
Uphill driving
Cruise control 195
Upshifting 152
Useful features 226
Ashtrays 231
ProCarManuals.com
