2003 Hyundai Grandeur light

1- 58 FEATURES OF YOUR HYUNDAI
B460A01Y-AAT SUNROOF (If installed) Sun Shade Your HYUNDAI is equipped with a sliding sunshade which you can manu- ally adjust to let in light with the sunroof closed, or to block sunlight. B460A01L
CAUTION:
Place the drink holder in its closedposition when not in use.
WARNING:
Do not place anything except drinksin the drink holder. Such objects can be thrown out, possibly injur- ing persons in the vehicle duringsudden braking or in the event of an accident.
!
!
WARNING:
Never adjust the sunshade while driving.
!
B460B01Y-AAT Opening the Sunroof System
The sunroof can be electrically opened or closed with the ignition key in the "ON" position. To open or to close,press and hold the button located in the front of the roof panel. Release the button when the sunroof reaches thedesired position. HXGS232

FEATURES OF YOUR HYUNDAI 1- 59
B460D02Y-AAT Manual Operation of Sunroof
If the sunroof does not electrically op- erate:
1. Remove the rectangular plastic in- terior light lens in the front of the roof panel. HXGS234
WARNING:
o Do not close a sunroof if anyone's hands, arms or body are between the sliding glass and the sunroof sash, as this could result in in- jury.
o Do not place your head or arms out of the sunroof opened at anytime. B460C01Y-AAT Tilting the Sunroof System
The sunroof can be tilted and closed with the ignition key in the "ON" posi- tion. Release the button when the sunroof reaches the desired position. NOTE: After washing the car or after there is rain, be sure to wipe off any water that is on the sunroof before oper-ating it. HXGS233!
CAUTION:
o Do not open the sunroof in se- verely cold temperature or when it is covered with ice or snow.
o Periodically remove any dirt that may have accumulated on theguide rails.!

1- 60 FEATURES OF YOUR HYUNDAI
2. Remove the front overhead light
and switch panel, using a phillips screwdriver. HXGS235
HXGS236
3. Insert the hexagonal head wrench provided with the vehicle into the socket. This wrench can be found inthe vehicle's trunk or glove box.
4. Turn the wrench clockwise to open
or counterclockwise to close thesunroof.
B480A01L-GAT FRONT MAP LIGHT
(With sunroof) The two map light switches are located on both sides of the interior light. Pushin the map light switch to turn the light on or off. HXG602J

FEATURES OF YOUR HYUNDAI 1- 61
o OFF In the "OFF" position, the light stays off at all times even though a door is open.
B490C01L-AAT Rear room light
The interior courtesy light has three buttons. The three buttons are: o DOOR In the "DOOR" position, the interiorcourtesy light comes on when any door is opened regardless of the igni- tion key position. The light goes outgradually 6 seconds after the door is closed. HSM045
B490A01L-AAT INTERIOR LIGHT Front overhead console light
The interior courtesy light has three buttons. The three buttons are: o DOOR In the "DOOR" position, the interior courtesy light comes on when anydoor is opened regardless of the igni- tion key position. The light goes out gradually 6 seconds after the door isclosed. o ON In the "ON" position, the light stays on at all times. HXG602J-1
With Sunroof
B480B01L
B480B01Y-AAT FRONT MAP LIGHT (Without Sunroof)
Push in the map light switch to turn the light on or off. This light produces aspot beam for convenient use as a map light at night or as a personal light for the driver and the passenger. Without spectacle case
With spectacle case

1- 62 FEATURES OF YOUR HYUNDAI
B490B01L-GAT Personal Light
B490B01L
The personal light are located on the both of the rear pillar. Push the per- sonal light switch to turn the light on or off.
B491A02F-GAT SPECTACLE CASE (If Installed)
HXG303
The spectacle case is located on the front overhead console. Push the end of the cover to open the spectacle case.o ON In the "ON" position, the light stays on at all times. o OFF In the "OFF" position, the light stays offat all times even though a door is open.
WARNING:
Do not open the spectacle casewhile the vehicle is moving. Therear view mirror of the vehicle can be blocked by an open spectacle case.
!
B500A01Y-AAT GLOVE BOX
WARNING:
To avoid the possibility of injury in case of an accident or a suddenstop, the glove box door should be kept closed when the car is in mo- tion.
o To open the glove box, pull on the glove box release lever.
o The glove box door can be locked with the key. HXG513
!

1- 64 FEATURES OF YOUR HYUNDAI
B510C01A-AAT FOLDING THE OUTSIDE REAR VIEW MIRRORS To fold the outside rear view mirrors, push them toward the rear. The outside rear view mirrors can befolded rearward for parking in narrow areas. B510C01LB520A01A-AAT DAY/NIGHT INSIDE REARVIEW MIRROR Your Hyundai is equipped with a day/ night inside rearview mirror. The "night" position is selected by flipping the tabat the bottom of the mirror toward you. In the "night" position, the glare of headlights of cars behind you is re-duced. HXG514J
!WARNING:
Do not adjust or fold the outside rear view mirrors while the vehicle is moving. This could result in loss of control, and an accident whichcould cause death, serious injury or property damage.
B520B01O-GAT DAY/NIGHT INSIDE REARVIEW MIRROR (Electric type)(If installed) The electric type day/night inside rear- view mirror controls automatically the glare of headlights of the car behindyou. Adjust the rearview mirror to the desired position. HXG514J-1

FEATURES OF YOUR HYUNDAI 1- 65
B540A01S-GAT TRUNK LID Remote Trunk Lid Release
To open the trunk lid without using the key, pull up the lid release lever lo-cated on the driver's door panel. To close, lower the trunk lid, then press down on it until it locks. To besure the trunk lid is securely fastened, always check by trying to pull it up again. HXGS231B530B01L-GAT PARKING BRAKE (Foot type)
o To engage the foot type parking
brake, depress the parking brake pedal beneath the left side of the lower instrument panel.
o To release the parking brake, pull up the parking brake release leverat the left side of the instrumentpanel. HXGS325
Always engage the parking brake be- fore leaving the car. This also turns on the parking brake indicator light when the key is in the "ON" or "START"position. Before driving away, be sure that the parking brake is fully released and the indicator light is off.
o To engage the parking brake, pull
the lever up as far as possible.
o To release the parking brake, pull up the lever and press the thumb button. Then, while holding the but-ton in, lower the brake lever.
B530A01A-AAT PARKING BRAKE
HXGS324

FEATURES OF YOUR HYUNDAI 1- 67
B550A02Y-AAT HIGH-MOUNTED REAR STOP
LIGHT (If Installed) In addition to the lower-mounted rear stoplights on either side of the car, thehigh mounted rear stoplight in the cen- ter of the rear window also lights when the brakes are applied. B550A03L
To open the trunk lid, insert the key and turn it clockwise to unlock. The trunk compartment light illuminates when the trunk lid is opened.
WARNING:
o If a person is locked in the trunk, pull the emergency trunk releaselever on the driver's side of theinside panel of the trunk to open the trunk lid.
o Hyundai recommends that cars be kept locked and keys be keptout of the reach of children, and that parents teach their childrenabout the dangers of playing in trunks.
o Parents should teach children about the emergency trunk re-lease lever in their vehicle and how to open the trunk lid if theyare accidentally locked in the trunk. B540C01Y-AAT To unlock using the key
B540C03L
!
