2003 Hyundai Coupe Owner's Manual

FEATURES OF YOUR HYUNDAI 1- 49
o During cruise-control driving with a manual
transaxle vehicle, do not shift into neutral without depressing the clutch pedal, or theengine will be overrevved. If this happens,depress the clutch pedal or release themain switch.
o With the cruise control engaged, when the brake pedal is applied, it is normal to hearthe cruise control system deactivate. Thisis an indication of normal system opera-tion.
o During normal cruise control operation, when the "SET(COAST)" is activated orreactivated after applying the brakes, thecruise control will energize after approxi-mately 3 seconds. This delay is normal.
B660F01E-AAT To Reset at a Slower Speed
B660B01GK
1. Push the control switch downward to "SET (COAST)" and hold it. The vehicle will decel- erate.
2. When the desired speed is obtained, release the control switch. While the control switch ispushed, the vehicle speed will gradually de-crease.
WARNING:
o Keep the main switch off when not using the cruise control.
o Do not use the cruise control when it may not be safe to keep the car at a constant speed, for instance, driving in heavy orvarying traffic, or on slippery (rainy, icy orsnow-covered) or winding roads or over6% up-hill or down-hill roads.
o Pay particular attention to the driving con- ditions whenever using the cruise controlsystem.

FEATURES OF YOUR HYUNDAI
1- 50
B710A01GK-GAT HEATING AND COOLING CONTROL
1. Side defrost nozzle
2. Side Ventilator
3. Center Ventilator
4. Windshield Defrost Ventilator
HGK001
1
2
31
2B710A01S-AAT VENTILATIONTo operate the ventilation system:
o Set the air intake control to "Fresh" mode
( ).
o To direct all intake air to the dashboard vents, set the airflow control to "Face".
o Adjust the fan speed control to the desired speed.
o Set the temperature control between "Cool" and "Warm".
B710C01S-AAT SIDE VENTILATORThe side ventilators are located on each side of the dashboard. To change the direction of the airflow, move the knob in the center of the vent up-and-down and side-to-side. The side vent knobscontrol the amount of outside air entering thevehicle through the side vents. The vents areopened when the vent knob is moved to the upposition. The vents are closed when the ventknob is moved to the down position. Keep thesevents clear of any obstructions.
B710B01S-AAT CENTER VENTILATOR The center ventilators are located in the middle of the dashboard. The direction of air flow from thevents in the center of the dashboard is adjust-able.To control the direction of the air flow, move theknob in the center of the vent up-and-down andside-to-side.
4

FEATURES OF YOUR HYUNDAI 1- 51
HGK002
B670A01GK-GAT ROTARY TYPE
This control is used to adjust the degree of heating or cooling desired.B670E02A-AAT Temperature ControlCool
Warm
B670B01A-AAT Fan Speed Control (Blower Control)HGK006
This is used to turn the blower fan on or off and to select the fan speed.This blower fan speed, and therefore the volumeof air delivered from the system, may be con-trolled manually by setting the blower controlbetween the "1" and "4" positions.
123
456
1. Air Conditioning switch
2. Air intake control switch
3. Rear window defroster switch
4. Air flow control switch
5. Fan speed control switch
6. Temperature control switch HGK007

FEATURES OF YOUR HYUNDAI
1- 52
HGK016 B670D01GK-AAT Air Flow Control This is used to direct the flow of air. Air can be directed to the floor, dashboard outlets, or wind-shield. Five symbols are used to represent Face,Bi-Level, Floor, Floor-Defrost and Defrost airposition.HGK005
B670C01FC-AAT Air Intake Control This is used to select fresh outside air or recircu- lating inside air.To change the air intake control mode, (Freshmode, Recirculation mode) push the control but-ton. FRESH MODE ( ) : The indicator light on the button goes off when the air intake control is freshmode. RECIRCULATION MODE ( ): The indicator light on the button is illuminated when the airintake control is recirculation mode. With the "Fresh" mode selected, air enters the vehicle from
the outside and is heated or cooled
according to the function selected. With the "Recirculation" mode selected, air fromwithin the passenger compartment
will be drawn
through the heating system and heated or cooledaccording to the function selected. NOTE:
o It should be noted that prolonged opera- tion of the heating in "Recirculation" modewill give rise to fogging of the windshieldand side windows and the air within thepassenger compartment will become stale.In addition, prolonged use of the air con-ditioning with the "Recirculation" modeselected may result in the air within thepassenger compartment becoming exces-sively dry.
o When the ignition switch is turned "ON" the air intake control will change to " "mode (regardless of switch position). Thisis normal operation.

FEATURES OF YOUR HYUNDAI 1- 53
HGK023
HGK024
Floor-Level
Air is discharged through the floor vents, wind- shield defroster nozzle, side defroster nozzle,side ventilator.
Floor-Defrost Level
Air is discharged through the windshield de-froster nozzle, the floor vents, side defrosternozzle, side ventilator.
HGK025
Face-Level
Selecting the "Face" mode will cause air to be discharged through the face level vents.
HGK022
Bi-Level
Air is discharged through the face vents and the floor vents. This makes it possible to have coolerair from the dashboard vents and warmer air fromthe floor outlets at the same time.
HGK021
If the "Floor-Defrost" mode is selected, the A/C will turn on automatically and "Fresh" mode willbe activated.
Defrost-Level
Air is discharged through the windshield de-froster nozzle, side defroster nozzle, side venti-lator.If the "Defrost" mode is selected, the A/C will turnon automatically and "Fresh" mode will be acti-vated.

FEATURES OF YOUR HYUNDAI
1- 54
B690A01S-AAT HEATING CONTROLSFor normal heating operation, set the air intake control to the "Fresh" position and the air flowcontrol to "Floor". For faster heating, the air intake control should be in the "Recirculation" position. If the windows fog up, move the air flow control to the "Def" (defroster) position. (The A/C will turnon automatically and "Fresh" mode will be acti-vated.) For maximum heat, move the temperature con- trol to "Warm".
B730A01FC-AAT Operation Tips
o To keep dust or unpleasant fumes from enter-
ing the car through the ventilation system, temporarily set the air intake control to "Recir-culation". Be sure to return the control to"Fresh" when the irritation has passed tokeep fresh air in the vehicle. This will helpkeep the driver alert and comfortable.
o Air for the heating/cooling system is drawn in through the grilles just ahead of the wind-shield. Care should be taken that these arenot blocked by leaves, snow, ice or otherobstructions.
o To prevent interior fog on the windshield, set the air intake control to the fresh air ( )position, turn on the air conditioning system,and adjust temperature control to desiredtemperature fan speed to the desired posi-tion.
o Set the temperature control to warm.
o Set the fan speed control to position "3" or "4". NOTE: When the A/C is operated continuously onthe floor-defrost level ( ) or defrost level( ), it may cause fog to form on the exteriorwindshield. If this occurs, set the air flowcontrol to the face level position ( ) and fanspeed control to the low position.
Use the heating/ventilation system to defrost ordefog the windshield: To remove interior fog on the wind- shield:
o Set the air flow control to the defrost (
)
position. (The A/C will turn on automatically and "Fresh" mode will be activated.)
o Set the temperature control to the desired position.
o Set the fan speed control between "1" and "4" position.
To remove frost or exterior fog on the windshield:
o Set the air flow control to the defrost (
)
position. (The A/C will turn on automatically and "Fresh" mode will be activated.)
B720A02FC-GAT DEFROSTING/DEFOGGING
HGK002

FEATURES OF YOUR HYUNDAI 1- 55
B740A01S-AAT AIR CONDITIONING SYSTEM (If installed)Air Conditioning Switch
HGK018
The air conditioning is turned on or off by pushing the A/C button on the heating/air conditioningcontrol panel.
HGK002
B740B01S-AAT Air Conditioning Operation Cooling
To use the air conditioning to cool the interior:
o Set the side vent control to "OFF", to shut off outside air entry.
o Turn on the fan control switch.
o Turn on the air conditioning switch by pushing in on the switch. The air conditioning indicatorlight should come on at the same time.
o Set the air intake control to "Fresh" mode ( ).
o Set the temperature control to "Cool". ("Cool" provides maximum cooling. The temperaturemay be moderated by moving the controltoward "Warm".)
o Adjust the fan control to the desired speed. For greater cooling, turn the fan control toone of the higher speeds or temporarilyselect the "Recirculation" position on the airintake control.
B740C01S-AAT Dehumidified HeatingFor dehumidified heating:
o Turn on the fan control switch.
o Turn on the air conditioning switch. The airconditioning indicator light should come on atthe same time.
o Set the air intake control to "Fresh" mode ( ).
o Set the air flow control to "Face".
o Adjust the fan control to the desired speed.
o For more rapid action, set the fan at one of the higher speeds.
o Adjust the temperature control to provide the desired amount of warmth.

FEATURES OF YOUR HYUNDAI
1- 56
B740D01A-AAT Operation Tips
o If the interior of the car is hot when you first
get in, open the windows for a few minutes to expel the hot air.
o When you are using the air conditioning sys- tem, keep all windows closed to keep hot airout.
o When moving slowly, as in heavy traffic, shift to a lower gear. This increases engine speed,which in turn increases the speed of the airconditioning compressor.
o On steep grades, turn the air conditioner off to avoid the possibility of the engine over-heating.
o During winter months or in periods when the air conditioner is not used regularly, run theair conditioner once every month for a fewminutes. This will help circulate the lubricantsand keep your system in peak operatingcondition.
