2003 FORD MUSTANG torque

SPECIFICATIONS
SECTION 502-
00: Frame and Body Mounting 2003 Mustang Workshop Manual Torque Specifications
Description Nm lb-
ft Engine mount nuts (3.8L engine) 115 85
Engine mount nuts (4.6L engine) 150 111
Front subframe lower bolts 90 66
Front subframe upper bolts 115 85
Front subframe brace bolts 41 30
Front subframe support, front and rear outboard bolts (convertible vehicles only) 63 46
Front subframe support, rear inboard bolts (convertible vehicles only) 30 22
HEGO connector bracket nut 47 35
Rear subframe bolts 103 76
Transmission support insulator to transmission extension housing bolts 70 52
Transmission support insulator-
to-rear engine support nut 70 52
Transmission support crossmember to transmission support member through bolts and
nuts 63 46 Klj . 1 ba
12003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

REMOVAL AND INSTALLATION
Rear Subframe
Removal and Installation
CAUTION: Suspension fasteners are critical parts because they affect performance of vital
components and systems and their failure can result in major service expense. A new part with
the same part number must be installed if installation becomes necessary. Torque values must
be used as specified during reassembly.
1. Remove the rear coil springs. For additional information, refer to Section 204 - 02 .
2. Using the special tool, raise the rear subframe.
3. Remove and discard the rear subframe front bolts.
4. Using the special tool, lower and remove the rear subframe.
5. NOTE: Discard the old bolts and nuts. Do not reuse, install new bolts and nuts.
To install, reverse the removal procedure.
SECTION 502-
00: Frame and Body Mounting 2003 Mustang Workshop Manual Klj . 1 ba
22003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

SIR Coil Assembly (Clockspring)Air Bag Restraint System
Slip Ring (Clockspring)Air Bag Restraint System; Steering Column Switches
SRS Control ModuleAir Bag Restraint System
Starter MotorStarters
Starter Interrupt RelayStarters
Starter SolenoidStarters
Starter RelayStarters
Steering Wheel Position SensorAnti-Lock Brakes
StoplightsExterior Lights
Stoplight SwitchEngine Performance; Cruise Control Systems;
Anti-Lock Brakes
Sun Roof ECUPower Sun Roof
Sun Roof MotorPower Sun Roof
Sun Roof Position SensorPower Sun Roof
TaillightsExterior Lights
Throttle Position (TP) SensorEngine Performance
Torque Converter Clutch Solenoid/SwitchEngine Performance
Traction Control SwitchAnti-Lock Brakes
Trailer Tow ConnectorExterior Lights
Trailer Tow RelayExterior Lights
Transmission/TransaxleEngine Performance
Transmission Control Module (TCM)Engine Performance; Starters
Transmission Range SensorStarters; Back-Up Lights; Engine Performance
Transmission Range SwitchBack-Up Lights; Engine Performance; Anti-Theft
System
Turn Signal FlasherExterior Lights
Turn Signal LightsExterior Lights
Twilight Sentinel SwitchHeadlight Systems; Daytime Running Lights
Vapor Canister Le ak Detection PumpEngine Performance
Vehicle Control Module (VCM)Engine Performance
Vehicle Dynamic ModuleElectronic Suspension
Vehicle Speed Control ServoCruise Control Systems
Vehicle Speed SensorData Link Connectors; Analog Instrument Panels;
Cruise Control Systems; Electronic Suspension
Voltage RegulatorGenerators & Regulators
Water-In-Fuel SensorEngine Performance; Analog Instrument Panels
Wheel Speed SensorsAnti-Lock Brakes
Window Timer ModulePower Convertible Top
Windshield Intermittent Wiper RelayWiper/Washer Systems
Windshield Washer MotorWiper/Washer Systems
Wiper MotorWiper/Washer Systems
