2003 DAEWOO MATIZ suspension

FRONT SUSPENSION 2C–23
DAEWOO M-150 BL2
SPECIFICATIONS
GENERAL SPECIFICATIONS
Application Unit Description
Suspension Type – Mcpherson (Strut)
Maximum Length mm (in.) 475–481 (18.7–18.94) Shock Absorber Minimum Length mm (in.) 321–327 (12.64–12.87)
Stroke

mm (in.)

154 (6.06)
Stabilizer Shaft Diammeter

mm (in.)

24 (0.94)
Coil Spring Height (No Load) mm (in.) 374 (14.72 )
Grease Type (Front Wheel Bearing and Hub) – M–8143 ANTIF BRG GREASE
FASTENER TIGHTENING SPECIFICATIONS
Application Nm Lb-Ft Lb-In
Strut Assembly–to–Body Nuts 18 – 28 13 – 21 –
Strut Closure Nut 50 – 60 36 – 44 – Strut Assembly–to–Knuckle Bolts 70 – 90 52 – 66 –
Control Arm Mounting Bolt

55 – 70

41 – 52

–
Control Arm Ball Stud Bolt

50 – 70

36 – 52

–
Stabilizer Shaft Castellated Nut 40 – 50 30 – 36 –
Stabilizer Shaft Mounting Bolt 30 – 50 22 – 36 –
Front Under Longitudinal Frame Bolts 10 – 14 – 89 – 124
Front Under Longitudinal Frame Nut 65 – 80 48 – 59 – Drive Axle–to–Hub Caulking Nut 210 155 – Crossmember Bolt 17 – 27 13 – 20 –
Strut Bar Bolts

35 – 55

25 – 41

–
ABS Front Speed Sensor Retaining Bolt 18 – 28 13 – 21 –
Wheel Hub–to–Brake Disc Bolt 55 – 75 41 – 55 –

2C –24 FRONT SUSPENSION
DAEWOO M-150 BL2
SPECIAL TOOLS AND EQUIPMENT
SPECIAL TOOLS TABLE
D13B112A
DW 220–020A–01
Differential Bearing
Puller
D13B113A
DW 220–020A–04
Differential Bearing
Plate Adapter
D16B101A
DW 340–010
Front Wheel Hub
Remover
D106B102
DW 340–020
Front Wheel Bearing
Race Installer
D106B103
DW 340–030
Front Wheel Bearing
Installer
D105B101
KM 507–B
Ball Joint Remover
D106B104
09940–71430
Front Spring
Compressor

DAEWOO M-150 BL2

SECTION 2D
REAR SUSPENSION
TABLE OF CONTENTS
Description and Operation 2D-2. . . . . . . . . . . . . . . . . .
Rear Suspension 2D-2. . . . . . . . . . . . . . . . . . . . . . . . . .
Component Locator 2D-3. . . . . . . . . . . . . . . . . . . . . . . .
Rear Suspension 2D-3. . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Information and Procedures 2D-4. . . . .
Rear Suspension 2D-4. . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the Rear Wheel Bearing
End Play 2D-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Wheel Bearing Free Load 2D-5. . . . . . . . . . . . . .
Repair Instructions 2D-6. . . . . . . . . . . . . . . . . . . . . . . . .
On-Vehicle Service 2D-6. . . . . . . . . . . . . . . . . . . . . . . . . . Shock Absorber 2D-6. . . . . . . . . . . . . . . . . . . . . . . . . . .
Lateral Rod 2D-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trailing Arm 2D-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Axle Assembly 2D-9. . . . . . . . . . . . . . . . . . . . . . .
Unit Repair 2D-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hub and Bearing Assembly 2D-12. . . . . . . . . . . . . . . .
Specifications 2D-15. . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications 2D-15. . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 2D-15. . . . . . . . . .
Special Tools and Equipment 2D-16. . . . . . . . . . . . . .
Special Tools Table 2D-16. . . . . . . . . . . . . . . . . . . . . . .

2D – 2 REAR SUSPENSION
DAEWOO M-150 BL2
DESCRIPTION AND OPERATION
REAR SUSPENSION
The rear suspension consists of an axle with trailing
arms and a lateral rod, two coil springs, two shock ab-
sorbers, two upper spring seats, and two bump stop-pers. The axle structure maintains the relationship of the
wheels to the body.
Each coil spring is retained between a seat in the under-
body and a seat welded to the top of the rear axle.

REAR SUSPENSION 2D–3
DAEWOO M-150 BL2
COMPONENT LOCATOR
REAR SUSPENSION
D106C401
1. Shock Absorber
2. Bumper Stopper
3. Coil Spring Upper Seat
4. Coil Spring
5. Washer
6. Bushing
7. Lateral Rod
8. Rear Axle9. Oil Seal
10. Wheel Bearing Inner
11. ABS Wheel Speed Ring
12. Wheel Bearing Outer
13. Cotter Pin
14. Castellated Nut
15. Spindle Cap
16. Trailing Arm

2D –4 REAR SUSPENSION
DAEWOO M-150 BL2
DIAGNOSTIC INFORMATION AND PROCEDURES
REAR SUSPENSION

Condition

Probable cause

Correction
Noise
The loosened joints.
Tighten the joints.

Wheel bearing is worn or damaged.
Replace the wheel bearing.

Faulty shock absorber.
Replace the shock absorber.
Uncomfortable
Faulty shock absorber.
Replace the shock absorber.

Faulty coil spring.
Replace the coil spring.

Lateral rod bushing is worn or
damaged.
Replace the lateral rod bushing.

Trailing arm bushing is worn or
damaged.
Replace the trailing arm bushing.
Vehicle Leans Toward
Rear axle deformation.
Replace the rear axle.
the Side
Lateral rod deformation.
Replace the lateral rod.

Trailing arm deformation.
Replace the trailing arm.

Faulty coil spring.
Replace the coil spring.

Lateral rod bushing is worn or
damaged.
Replace the lateral rod bushing.

Trailing arm bushing is worn or
damaged.
Replace the trailing arm bushing.

REAR SUSPENSION 2D–5
DAEWOO M-150 BL2
CHECKING THE REAR WHEEL
BEARING END PLAY
1. Release the parking brake.
2. Raise the vehicle.
3. Check the wheel bearing play by moving the top and
the down of the tire in an in–and–out motion.
D106C301

Rear Wheel Bearing Play

0 mm (0 in.)
4. If the bearing play is high, tighten the castellated nut.
5. If the bearing play is high after tightening, replace the
wheel bearing.
REAR WHEEL BEARING FREE LOAD
1. Release the parking brake.
2. Raise the vehicle and rotate the wheel.
3. Remove the wheels.
4. Check the torque when the hub moves by a spring
scale.

Standard (No Load)

0.137 – 0.422 Nm
(0.9 – 3.7 lb-in)
D106C302
5. If the checked torque exceeds the specification, tight-
en the castellated nut.
6. If the checked torque exceeds the specification after
tightening, replace the wheel bearing.

2D –6 REAR SUSPENSION
DAEWOO M-150 BL2
REPAIR INSTRUCTIONS
ON–VEHICLE SERVICE
D106C501
SHOCK ABSORBER
Removal Procedure
1. Support the rear axle with adjustable jack stands.

Raise the vehicle and support the rear axle assem-
bly (1, 2).
D106C502
2. Remove the shock absorber.

Remove the bolt (1).

Remove the nut (2).
D16C503B
Installation Procedure
1. Install the shock absorber.

Install the shock absorber–to–rear axle bolt (1).
Tighten
Tighten the bolt to 45–70 Nm (33–52 lb-ft).

Install the shock absorber–to–body bracket nut (2).
Tighten
Tighten the shock absorber nut to 45–70 Nm (33–52
lb-ft).
2. Remove the jack stand and lower the vehicle.
