WATERLEAKS 9I–7
DAEWOO M-150 BL2
SPECIFICATIONS
RECOMMENDED MATERIALS FOR WATERLEAK REPAIRS
Leak Areas
Repair Materials
Windshield, back window
Urethane adhesive, caulking kit, or the equivalent
Metal joints
Brushable seam sealer which can be painted
Ventilation ducts
3MTM Auto Bedding and Glazing Compound or the
equivalent
Small cracks and pin holes 3MTM Drip-Check Sealer or the equivalent Large holes 3MTM Automotive Joint and Seam Sealer Weatherstrips 3MTM 08011 Weatherstrip Adhesive or the equivalent Bolts, studs, and screws Strip caulk
WATERTEST STAND SPECIFICATIONS
Application Description
Nozzle Type
Full jet spray nozzle #1/2 GG-25 or equivalent with a
60° included angle
Nozzle Height Approximately 1,600 mm (63.0 in.) from the floor
Volume of Flow 14L (3.7 gal) per minute
Pressure 155 kPa (22.5 psi) measured at the nozzle
Windshield and A-Pillar Test Stand Position
Approximately 30° down, 45° toward the rear, and
aimed at the corner of the windshield
B-Pillar Test Stand Position Approximately 30° down, 45° toward the rear, and
aimed at the center of the rear door
Back Window and tailgate Test Stand Position
Approximately 30° down, 45° toward the front and
aimed approximately 610 mm (24.0 in.) from the
corner of the back window
