2003 CHRYSLER VOYAGER cam sensor

(3) Remove camshaft position sensor mounting
screws. Remove sensor.
(4) Loosen screw attaching target magnet to rear
of camshaft and remove magnet (Fig. 4).
REMOVAL - 3.3/3.8L
(1) Disconnect the negative battery cable.
(2) Remove the air box cover and inlet tube (Fig.
5).
(3) Disconnect camshaft position sensor electrical
connector from the wiring harness connector (Fig. 6).
(4) Remove bolt holding sensor.(5) Rotate sensor away from block.
(6) Pull sensor up out of the chain case cover.Do
not pull on the sensor wiring.There is an O-ring
on the body of the sensor. The O-ring may make
removal difficult. A light tap to top of sensor prior to
removal may reduce force needed for removal.
INSTALLATION
INSTALLATION - 2.4L
The target magnet has locating dowels that fit into
machined locating holes in the end of the camshaft
(Fig. 7).
Fig. 4 Target Magnet Removal/Installation
1 - TARGET MAGNET
2 - MOUNTING BOLT
3 - REAR OF CYLINDER HEAD
Fig. 5 AIR BOX COVER
Fig. 6 CAMSHAFT POSITION SENSOR
Fig. 7 Target Magnet Installation
1 - LOCATING DOWELS
2 - LOCATING HOLES (2)
RSIGNITION CONTROL8I-5
CAMSHAFT POSITION SENSOR (Continued)
ProCarManuals.com

(1) Install target magnet in end of camshaft.
Tighten mounting screw to 3 N´m (30 in. lbs.) torque.
Over torqueing could cause cracks in magnet. If mag-
net cracks replace it.
(2) Install camshaft position sensor. Tighten sensor
mounting screws to 12.9 N´m (115 in. lbs.) torque.
(3) Carefully attach electrical connector to cam-
shaft position sensor.
(4) Connect the negative battery cable.
INSTALLATION - 3.3/3.8L
If the removed sensor is reinstalled, clean off
the old spacer on the sensor face. A NEW
SPACER must be attached to the face before
installation.Inspect O-ring for damage, replace if
necessary. If the sensor is being replaced, confirm
that the paper spacer is attached to the face and
O-ring is positioned in groove of the new sensor (Fig.
8).
(1) Apply a couple drops of clean engine oil to the
O-ring prior to installation.
(2) Install sensor in the chain case cover and
rotate into position.
(3) Push sensor down until contact is made with
the camshaft gear. While holding the sensor in this
position, install and tighten the retaining bolt 14
N´m (125 in. lbs.) torque.
(4) Connect camshaft position sensor electrical
connector to harness connector.
(5) Install the air box cover and inlet hose (Fig. 5).
(6) Connect the negative battery cable.
IGNITION COIL
DESCRIPTION
The ignition coil assembly consists of 2 or 3 inde-
pendent coils molded together (Fig. 9) or (Fig. 10).
The coil assembly for the 3.3/3.8L is mounted on the
intake manifold. The coil assembly for the 2.4L is
mounted on the cylinder head cover. Spark plug
cables route to each cylinder from the coil.
OPERATION
The coil fires two spark plugs every power stroke.
One plug is the cylinder under compression, the
other cylinder fires on the exhaust stroke. The Pow-
ertrain Control Module (PCM) determines which of
the coils to charge and fire at the correct time.
The Auto Shutdown (ASD) relay provides battery
voltage to the ignition coil. The PCM provides a
ground contact (circuit) for energizing the coil. When
the PCM breaks the contact, the magnetic energy in
the coil transfers to the secondary causing the spark.
The PCM will de-energize the ASD relay if it does
not receive the crankshaft position sensor and cam-
shaft position sensor inputs. Refer to Auto Shutdown
(ASD) RelayÐPCM Output, in this section for relay
operation.
Fig. 8 Camshaft Position Sensor and Spacer
1 - ELECTRICAL CONNECTOR
2 - O-RING
3 - PAPER SPACER
Fig. 9 IGNITION COIL - 2.4L
8I - 6 IGNITION CONTROLRS
CAMSHAFT POSITION SENSOR (Continued)
ProCarManuals.com

8W-02 COMPONENT INDEX
Component Page
A/C Compressor Clutch Relay............. 8W-42
A/C Compressor Clutch.................. 8W-42
A/C-Heater Control..................... 8W-42
A/C Pressure Sensor.................... 8W-42
Accelerator Pedal Position Sensor.......... 8W-30
Accessory Relay........................ 8W-10
Adjustable Pedals Module................ 8W-30
Adjustable Pedals Relay................. 8W-30
Adjustable Pedals Switch................. 8W-30
Airbag Control Module.................. 8W-43
Ambient Temperature Sensor.............. 8W-49
Antenna............................. 8W-47
ATC Remote Sensor..................... 8W-42
Auto Shut Down Relay.................. 8W-30
Auto Temp Control..................... 8W-42
Automatic Day/Night Mirror.............. 8W-49
Back-Up Lamp Switch................... 8W-51
Battery Temperature Sensor.............. 8W-20
Battery.............................. 8W-20
Blend Door Actuators................... 8W-42
Blower Motor Resistor................... 8W-42
Body Control Module.................... 8W-45
Boost Pressure Sensor................... 8W-30
B-Pillar Switches....................... 8W-61
Brake Fluid Level Switch................ 8W-40
Brake Lamp Switch.................. 8W-30, 51
Brake Transmission Shift Interlock Solenoid . . 8W-31
Cabin Heater Assist..................... 8W-30
Camshaft Position Sensor................ 8W-30
CD Changer.......................... 8W-47
Center Dome Lamp..................... 8W-44
Center High Mounted Stop Lamp........... 8W-51
Cinch/Release Motors................... 8W-61
Clockspring................ 8W-30, 33, 41, 43, 47
Clutch Pedal Interlock Switch.......... 8W-10, 30
Clutch Pedal Upstop Switch............... 8W-30
Combination Relays..................... 8W-54
Controller Antilock Brake................ 8W-35
Crank Case Ventilation Heater............ 8W-30
Crankshaft Position Sensor............... 8W-30
Cylinder Lock Switches.................. 8W-39
Data Link Connector.................... 8W-18
Defogger Relay........................ 8W-48
Door Ajar Switches..................... 8W-39
Door Lock Motor/Ajar Switches............ 8W-61
Door Courtesy Lamps................... 8W-44
Door Lock Switches..................... 8W-61
Dosing Pump......................... 8W-30
Driver Airbag Squibs.................... 8W-43
Driver Seat Belt Switch.................. 8W-43
DVD Screen.......................... 8W-47
DVD/CD Changer...................... 8W-47
ECM/PCM Relay....................... 8W-30
EGR Solenoid......................... 8W-30
Electronic Control Unit.................. 8W-64
Engine Control Module.................. 8W-30
Component Page
Engine Coolant Temp Sensor.............. 8W-30
Engine Oil Pressure Sensor............... 8W-30
Engine Oil Pressure Switch............... 8W-30
EVAP/Purge Solenoid.................... 8W-30
Evaporator Temperature Sensor............ 8W-42
Floor Console Lamp..................... 8W-44
Floor Console Power Outlet............... 8W-41
Fog Lamps........................... 8W-50
Front Blower Module.................... 8W-42
Front Blower Motor Relay................ 8W-42
Front Blower Motor..................... 8W-42
Front Cigar Lighter..................... 8W-41
Front Control Module................... 8W-10
Front Fog Lamp Relay................... 8W-50
Front Intrusion Sensor.................. 8W-39
Front Reading Lamps/Switch.............. 8W-44
Front Washer Pump Motor............... 8W-53
Front Wiper High/Low Relay.............. 8W-53
Front Wiper On/Off Relay................ 8W-53
Fuel Heater Relay...................... 8W-30
Fuel Heater.......................... 8W-30
Fuel Injectors......................... 8W-30
Fuel Pressure Sensor.................... 8W-30
Fuel Pressure Solenoid.................. 8W-30
Fuel Pump Module..................... 8W-30
Fuel Pump Relay....................... 8W-30
Full Open Switches..................... 8W-61
Fuses............................... 8W-10
Fuselink............................. 8W-10
Grounds............................. 8W-15
Generator............................ 8W-20
Glow Plugs........................... 8W-30
Glow Plug Relay....................... 8W-30
Headlamp Leveling Motors............... 8W-50
Headlamp Switch...................... 8W-50
Headlamp Washer Pump Motor............ 8W-53
Headlamp Washer Relay................. 8W-53
Headlamps........................... 8W-50
Heated Seat Backs..................... 8W-63
Heated Seat Cushions................... 8W-63
Heated Seat Modules.................... 8W-63
High Beam Lamps...................... 8W-50
Hood Ajar Switch...................... 8W-39
Horn Relay........................... 8W-41
Horn Switch.......................... 8W-41
Horns............................... 8W-41
Idle Air Control Motor................... 8W-30
Ignition Coil.......................... 8W-30
Ignition Switch........................ 8W-10
Inlet Air Temperature Sensor.............. 8W-30
Input Speed Sensor..................... 8W-31
Instrument Cluster..................... 8W-40
Instrument Panel Switch Bank.... 8W-44, 52, 53, 63
Integrated Power Module................. 8W-10
Knock Sensor......................... 8W-30
Lamp Assemblies...................... 8W-51
RS8W-02 COMPONENT INDEX8W-02-1
ProCarManuals.com

8W-10 POWER DISTRIBUTION
Component Page
A/C Compressor Clutch . . . 8W-10-22, 24, 47, 48, 51
A/C Compressor Clutch
Relay............ 8W-10-22, 24, 46, 47, 48, 51
Accessory Relay............... 8W-10-16, 31, 68
Adjustable Pedals Relay.............. 8W-10-50
Airbag Control Module............ 8W-10-67, 72
Ambient Temperature Sensor.......... 8W-10-65
Auto Shut Down Relay......... 8W-10-21, 42, 43
Auto Temp Control.................. 8W-10-41
Back-Up Lamp Switch............... 8W-10-69
Battery............ 8W-10-13, 14, 15, 42, 43, 51
Blower Motor Resistor............ 8W-10-19, 39
Body Control Module.... 8W-10-25, 41, 47, 48, 52,
53, 55, 57, 58, 59, 60, 72
Brake Fluid Level Switch............. 8W-10-68
Brake Lamp Switch........... 8W-10-26, 55, 70
Brake Transmission Shift Interlock
Solenoid........................ 8W-10-66
Cabin Heater Assist........... 8W-10-23, 45, 63
Camshaft Position Sensor............. 8W-10-46
Center High Mounted Stop Lamp....... 8W-10-70
Clockspring........................ 8W-10-64
Clutch Pedal Interlock
Switch.............. 8W-10-18, 38, 57, 58, 64
Controller Antilock
Brake...... 8W-10-18, 25, 37, 38, 53, 59, 65, 70
Crank Case Ventilation Heater......... 8W-10-52
Data Link Connector........... 8W-10-36, 65, 72
Defogger Relay............ 8W-10-19, 20, 40, 67
Driver Door Lock Switch........ 8W-10-33, 34, 35
Driver Heated Seat Module........... 8W-10-53
Driver Power Seat Switch............ 8W-10-53
Driver Power Window Switch....... 8W-10-34, 35
DVD/DV Changer................... 8W-10-41
ECM/PCM Relay................. 8W-10-23, 45
EGR Solenoid................... 8W-10-46, 50
Engine Control
Module . . 8W-10-18, 23, 24, 38, 45, 46, 51, 65, 70
Floor Console Lamp................. 8W-10-32
Floor Console Power Outlet........ 8W-10-32, 36
Front Blower Module................ 8W-10-19
Front Blower Module................ 8W-10-39
Front Blower Motor Relay.... 8W-10-18, 19, 39, 67
Front Cigar Lighter.............. 8W-10-16, 32
Front Control Module....... 8W-10-15, 16, 17, 18,
19, 20, 22, 24, 26, 27,
28, 29, 30, 31, 36, 40,
47, 48, 50, 51, 56, 57,
58, 61, 62, 63, 64, 65,
66, 67, 68, 69, 70, 72
Front Fog Lamp Relay......... 8W-10-15, 27, 67
Front Washer Pump Motor...... 8W-10-16, 31, 72Component Page
Front Wiper High/Low Relay.... 8W-10-16, 30, 68
Front Wiper On/Off Relay....... 8W-10-16, 30, 63
Fuel Heater....................... 8W-10-52
Fuel Heater Relay............. 8W-10-24, 51, 68
Fuel Injector No. 1.................. 8W-10-44
Fuel Injector No. 2.................. 8W-10-44
Fuel Injector No. 3.................. 8W-10-44
Fuel Injector No. 4.................. 8W-10-44
Fuel Injector No. 5.................. 8W-10-44
Fuel Injector No. 6.................. 8W-10-44
Fuel Pressure Solenoid............... 8W-10-46
Fuel Pump Module............ 8W-10-22, 47, 48
Fuel Pump Relay........... 8W-10-22, 47, 48, 68
Fuse 1...................... 8W-10-15, 16, 27
Fuse 2...................... 8W-10-15, 28, 29
Fuse 3...................... 8W-10-15, 28, 29
Fuse 4................... 8W-10-15, 16, 17, 30
Fuse 5......................... 8W-10-16, 31
Fuse 6......................... 8W-10-16, 31
Fuse 8......................... 8W-10-17, 36
Fuse 9................ 8W-10-17, 18, 19, 37, 38
Fuse 10........................ 8W-10-19, 39
Fuse 11........................ 8W-10-16, 31
Fuse 12........................ 8W-10-19, 39
Fuse 13........................ 8W-10-20, 40
Fuse 14............... 8W-10-20, 21, 23, 40, 63
Fuse 15...... 8W-10-20, 21, 22, 23, 24, 42, 43, 45
Fuse 16............... 8W-10-21, 23, 42, 43, 45
Fuse 17......... 8W-10-21, 22, 23, 24, 47, 48, 51
Fuse 18............ 8W-10-22, 24, 25, 47, 48, 51
Fuse 19.................. 8W-10-22, 24, 26, 53
Fuse 20........................ 8W-10-25, 53
Fuse 21........................ 8W-10-25, 53
Fuse 22........................ 8W-10-25, 53
Fuse 23..................... 8W-10-25, 57, 58
Fuse 24........................ 8W-10-25, 55
Fuse 26..................... 8W-10-25, 26, 55
Fuse 27........................ 8W-10-26, 55
Fuse 28........................ 8W-10-16, 31
Fuse 30........................ 8W-10-26, 56
Fuse 31........................ 8W-10-26, 56
Fuse 32........................ 8W-10-26, 56
Fuse 33........................ 8W-10-16, 31
Fuselink....................... 8W-10-13, 14
G100............................. 8W-10-59
G101....................... 8W-10-42, 43, 51
G103............................. 8W-10-72
G300.......................... 8W-10-61, 62
Generator................ 8W-10-13, 14, 44, 46
Glow Plug Relay................. 8W-10-13, 46
Headlamp Switch................ 8W-10-29, 66
Headlamp Washer Pump Motor..... 8W-10-26, 56
RS8W-10 POWER DISTRIBUTION8W-10-1
ProCarManuals.com

8W-30 FUEL/IGNITION SYSTEM
Component Page
A/C Compressor Clutch................ 8W-30-28
A/C Compressor Clutch Relay...... 8W-30-4, 18, 28
A/C Pressure Sensor............. 8W-30-11, 25, 35
Accelerator Pedal Position Sensor........ 8W-30-42
Adjustable Pedals Module.............. 8W-30-27
Adjustable Pedals Relay............... 8W-30-27
Adjustable Pedals Switch.............. 8W-30-27
Ambient Temperature Sensor............ 8W-30-9
Auto Shut Down Relay . 8W-30-4, 8, 13, 17, 20, 22, 23
Battery................ 8W-30-2, 6, 14, 17, 28, 36
Battery Temperature Sensor.......... 8W-30-9, 35
Body Control Module............. 8W-30-5, 19, 29
Boost Pressure Sensor................. 8W-30-35
Brake Lamp Switch........... 8W-30-7, 21, 31, 41
Cabin Heater Assist.................. 8W-30-32
Camshaft Position Sensor......... 8W-30-9, 23, 34
Clockspring................. 8W-30-5, 18, 33, 40
Clutch Pedal Interlock Switch............ 8W-30-4
Clutch Pedal Upstop Switch............ 8W-30-40
Controller Antilock Brake.............. 8W-30-19
Crank Case Ventilation Heater.......... 8W-30-29
Crankshaft Position Sensor....... 8W-30-10, 23, 34
Data Link Connector............. 8W-30-3, 19, 32
Dosing Pump....................... 8W-30-32
ECM/PCM Relay.......... 8W-30-28, 30, 34, 36, 38
EGR Solenoid.................... 8W-30-20, 38
Engine Control Module . . 8W-30-28, 29, 30, 31, 32, 33,
34, 35, 36, 37, 38, 39, 40, 41, 42
Engine Coolant Temp Sensor...... 8W-30-11, 25, 35
Engine Oil Pressure Sensor............. 8W-30-31
Engine Oil Pressure Switch........... 8W-30-7, 21
EVAP/Purge Solenoid............... 8W-30-4, 18
Front Control Module.......... 8W-30-2, 5, 18, 19,
20, 26, 32, 40, 27
Fuel Heater........................ 8W-30-39
Fuel Heater Relay................. 8W-30-29, 39
Fuel Injector No. 1.............. 8W-30-13, 22, 37
Fuel Injector No. 2.............. 8W-30-13, 22, 37
Fuel Injector No. 3.............. 8W-30-13, 22, 37
Fuel Injector No. 4.............. 8W-30-13, 22, 37
Fuel Injector No. 5................... 8W-30-22
Fuel Injector No. 6................... 8W-30-22
Fuel Pressure Sensor................. 8W-30-41
Fuel Pressure Solenoid................ 8W-30-30
Fuel Pump Module.............. 8W-30-5, 19, 29
Fuel Pump Relay.................. 8W-30-5, 19
Fuse 15...................... 8W-30-14, 32, 39
Fuse 16............... 8W-30-4, 8, 13, 17, 20, 22,
23, 28, 30, 34, 36, 38
Fuse 17............... 8W-30-2, 5, 17, 19, 29, 39
Fuse 18......................... 8W-30-28, 27
Fuse 26........................... 8W-30-41
Fuselink........................... 8W-30-36
Component Page
G100....................... 8W-30-2, 6, 14, 17
G101.................... 8W-30-2, 6, 14, 17, 28
G103.............. 8W-30-7, 16, 20, 21, 28, 29, 32
G200............................. 8W-30-27
G300.................... 8W-30-4, 7, 21, 31, 40
G302...................... 8W-30-5, 19, 29, 39
Generator..................... 8W-30-4, 17, 29
Glow Plug No. 1..................... 8W-30-36
Glow Plug No. 2..................... 8W-30-36
Glow Plug No. 3..................... 8W-30-36
Glow Plug No. 4..................... 8W-30-36
Glow Plug Relay..................... 8W-30-36
Idle Air Control Motor.............. 8W-30-12, 24
Ignition Coil...................... 8W-30-8, 23
Ignition Switch................... 8W-30-16, 26
Inlet Air Temperature Sensor......... 8W-30-10, 24
Input Speed Sensor................... 8W-30-14
Integrated Power Module..... 8W-30-2, 3, 4, 5, 8, 13,
14, 16, 17, 18, 19, 20, 22,
23, 26, 28, 29, 30, 32, 34,
36, 38, 39, 40, 41, 27
Knock Sensor.................... 8W-30-12, 25
Leak Detection Pump................. 8W-30-26
Left Speed Control Switch......... 8W-30-5, 18, 33
Lift Pump Motor..................... 8W-30-39
Lift Pump Relay..................... 8W-30-39
Manifold Absolute Pressure Sensor..... 8W-30-11, 25
Mass Air Flow Sensor................. 8W-30-30
Natural Vacuum Leak Detection Assembly . . 8W-30-16
Output Speed Sensor................. 8W-30-14
Oxygen Sensor 1/1 Upstream.......... 8W-30-6, 20
Oxygen Sensor 1/2 Downstream........ 8W-30-6, 20
Power Mirror Switch.................. 8W-30-27
Powertrain Control Module . . 8W-30-2, 3, 4, 5, 6, 7, 8,
9, 10, 11, 12, 13, 14, 15, 16,
17, 19, 21, 22, 23, 24, 25, 26
Powertrain Control Module............. 8W-30-18
Powertrain Control Module............. 8W-30-20
Radiator Fan Relay................. 8W-30-8, 18
Radiator Fan Relay No. 1.............. 8W-30-41
Radiator Fan Relay No. 2.............. 8W-30-41
Radiator Fan Relay No. 3.............. 8W-30-41
Right Speed Control Switch........ 8W-30-5, 18, 33
Solenoid/Pressure Switch Assy........ 8W-30-14, 15
Speed Control Servo................ 8W-30-7, 21
Starter Motor Relay.............. 8W-30-5, 19, 29
Throttle Position Sensor............ 8W-30-10, 24
Transmission Control Module........... 8W-30-24
Transmission Control Relay............. 8W-30-14
Transmission Range Sensor.......... 8W-30-15, 24
Vehicle Speed Sensor............... 8W-30-12, 38
Water In Fuel Sensor................. 8W-30-40
RS8W-30 FUEL/IGNITION SYSTEM8W-30-1
ProCarManuals.com

Component Page
C313 (Rear Console)................. 8W-80-39
C313 (Rear Console)................. 8W-80-39
C314 (Highline).................... 8W-80-40
C314 (Highline).................... 8W-80-40
C315 (Highline).................... 8W-80-41
C315 (Highline).................... 8W-80-41
C316 (Power Sliding Door)............ 8W-80-41
C316 (Power Sliding Door)............ 8W-80-42
C317 (Power Sliding Door)............ 8W-80-42
C317 (Power Sliding Door)............ 8W-80-42
C318 (Trailer Tow).................. 8W-80-43
C318 (Trailer Tow).................. 8W-80-43
C319 (Lowline)..................... 8W-80-43
C319 (Lowline)..................... 8W-80-44
C320............................. 8W-80-44
C320............................. 8W-80-44
C321............................. 8W-80-44
C321............................. 8W-80-45
C322 (Memory)..................... 8W-80-45
C322 (Memory)..................... 8W-80-45
C324 (Manual Sliding Door)........... 8W-80-46
C324 (Manual Sliding Door)........... 8W-80-46
C325 (Manual Sliding Door)........... 8W-80-46
C325 (Manual Sliding Door)........... 8W-80-46
C326............................. 8W-80-46
C326............................. 8W-80-47
C327............................. 8W-80-47
C327............................. 8W-80-47
C328 (Sunroof)..................... 8W-80-47
C328 (Sunroof)..................... 8W-80-47
C329 (Diesel)...................... 8W-80-48
C329 (Diesel)...................... 8W-80-48
C330 (Diesel)...................... 8W-80-48
C330 (Diesel)...................... 8W-80-48
C331 (Diesel)...................... 8W-80-48
C331 (Diesel)...................... 8W-80-49
C332 (3 Zone ATC).................. 8W-80-49
C332 (3 Zone ATC).................. 8W-80-49
Cabin Heater Assist C1 (Diesel)........ 8W-80-50
Cabin Heater Assist C2 (Diesel)........ 8W-80-50
Camshaft Position Sensor (Diesel)...... 8W-80-50
Camshaft Position Sensor (Gas)........ 8W-80-50
CD Changer....................... 8W-80-51
Center Dome Lamp (Base/Highline)..... 8W-80-51
Center High Mounted Stop Lamp....... 8W-80-51
Clockspring C1..................... 8W-80-51
Clockspring C2..................... 8W-80-52
Clockspring C3..................... 8W-80-52
Clockspring C4..................... 8W-80-52
Clutch Pedal Interlock Switch (MTX).... 8W-80-52
Clutch Pedal Upstop Switch (Diesel).... 8W-80-52
Controller Antilock Brake............. 8W-80-53
Crank Case Ventilation Heater (Diesel) . . 8W-80-53
Crankshaft Position Sensor (Diesel)..... 8W-80-53Component Page
Crankshaft Position Sensor (Gas)....... 8W-80-54
Data Link Connector................ 8W-80-54
Dosing Pump (Diesel)................ 8W-80-54
Driver Airbag Squib 1................ 8W-80-55
Driver Airbag Squib 2................ 8W-80-55
Driver Blend Door Actuator (ATC)...... 8W-80-55
Driver Blend Door Actuator (MTC)...... 8W-80-55
Driver Door Courtesy Lamp........... 8W-80-56
Driver Door Lock Switch............. 8W-80-56
Driver Heated Seat Back............. 8W-80-56
Driver Heated Seat Cushion........... 8W-80-56
Driver Heated Seat Module C1......... 8W-80-56
Driver Heated Seat Module C2......... 8W-80-57
Driver Heated Seat Module C3......... 8W-80-57
Driver Power Seat Front Riser Motor.... 8W-80-57
Driver Power Seat Front Riser Position
Sensor......................... 8W-80-57
Driver Power Seat Horizontal Motor.... 8W-80-58
Driver Power Seat Horizontal Position
Sensor......................... 8W-80-58
Driver Power Seat Rear Riser Motor.... 8W-80-58
Driver Power Seat Rear Riser Position
Sensor......................... 8W-80-58
Driver Power Seat Recliner Motor...... 8W-80-58
Driver Power Seat Recliner Position
Sensor......................... 8W-80-59
Driver Power Seat Switch............ 8W-80-59
Driver Power Window Motor.......... 8W-80-59
Driver Power Window Switch
(LHD Except Lowline)............. 8W-80-60
Driver Power Window Switch (LHD
Lowline)........................ 8W-80-60
Driver Power Window Switch (RHD).... 8W-80-60
Driver Seat Belt Switch.............. 8W-80-61
Driver Seat Belt Tensioner............ 8W-80-61
DVD Screen....................... 8W-80-61
DVD/CD Changer C1................ 8W-80-61
DVD/CD Changer C2................ 8W-80-62
DVD/CD Changer C3................ 8W-80-62
EGR Solenoid (3.3L/3.8L Export)....... 8W-80-62
EGR Solenoid (Diesel)............... 8W-80-62
Engine Control Module C1 (Diesel)..... 8W-80-63
Engine Control Module C2 (Diesel)..... 8W-80-64
Engine Coolant Temp Sensor (Diesel).... 8W-80-65
Engine Coolant Temp Sensor (Gas)..... 8W-80-65
Engine Oil Pressure Sensor (Diesel)..... 8W-80-66
Engine Oil Pressure Switch (Gas)...... 8W-80-66
EVAP/Purge Solenoid (Gas)........... 8W-80-66
Evaporator Temperature Sensor........ 8W-80-66
Floor Console Lamp................. 8W-80-67
Floor Console Power Outlet........... 8W-80-67
Front Blower Module C1 (ATC)........ 8W-80-67
Front Blower Module C2 (ATC)........ 8W-80-67
Front Cigar Lighter................. 8W-80-68
8W - 80 - 2 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com

CABIN HEATER ASSIST C1 (DIESEL) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 D21 20WT/DB SCI TRANSMIT
3- -
4- -
5 C41 20DB/OR CABIN HEATER ASSIST CONTROL
6 18RD DOSING PUMP CONTROL
CABIN HEATER ASSIST C2 (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A119 14RD/OR FUSED B(+)
2 Z149 14BK/DB GROUND
CAMSHAFT POSITION SENSOR (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K944 20BK/GY CAMSHAFT POSITION SENSOR GROUND
2 K44 20DB/GY CAMSHAFT POSITION SENSOR SIGNAL
3 K342 16BR/WT ECM/PCM RELAY OUTPUT
CAMSHAFT POSITION SENSOR (GAS) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 F855 20PK/YL (2.4L) 5 VOLT SUPPLY
1 F888 18BR/PK (3.3L/3.8L) 8 VOLT SUPPLY
2 K900 20DB/DG SENSOR GROUND
3 K44 18DB/GY (3.3L/3.8L) CAMSHAFT POSITION SENSOR SIGNAL
3 K44 18DB/GY (2.4L) CMP SIGNAL
8W - 80 - 50 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com

ENGINE CONTROL MODULE C1 (DIESEL) - BLACK 81 WAY - 81 WAY
CAV CIRCUIT FUNCTION
1 Z130 14BK/BR GROUND
2 Z131 14BK/DG GROUND
3 K20 14BR/GY GENERATOR FIELD CONTROL
4 K342 14BR/WT ECM/PCM RELAY OUTPUT
5 K342 14BR/WT ECM/PCM RELAY OUTPUT
6- -
7 D25 20WT/VT PCI BUS
8 K944 20BK/GY CAMSHAFT POSITION SENSOR SHIELD GROUND
9 K44 20DB/GY CAMSHAFT POSITION SENSOR SIGNAL
10 - -
11 K37 20DB/YL BOOST PRESSURE SENSOR SIGNAL
12 K55 20DB/OR MASS AIR FLOW SENSOR SIGNAL
13 K78 20GY FUEL PRESSURE SENSOR SIGNAL
14 - -
15 K22 20OR/DB ACCELERATOR PEDAL POSITION SENSOR SIGNAL
16 K80 20DB/TN FUEL PRESSURE SENSOR GROUND
17 - -
18 - -
19 K342 20BR/WT ECM/PCM RELAY OUTPUT
20 Z138 20BK/OR GROUND
21 K900 20DB/DG SENSOR GROUND
22 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
23 F851 20LB/PK SENSOR REFERENCE VOLTAGE B
24 K3 20BR/OR CRANKSHAFT POSITION SENSOR SIGNAL NO. 1
25 - -
26 - -
27 - -
28 - -
29 - -
30 G6 20VT/GY ENGINE OIL PRESSURE SENSOR SIGNAL
31 F853 20LG/PK WATER IN FUEL SENSOR SIGNAL
32 K25 20BR/TN BATTERY TEMPERATURE SENSOR SIGNAL
33 - -
34 K4 20BK/LB LOW IDLE POSITION SWITCH GROUND
35 K853 20DB/BR ACCELERATOR PEDAL POSITION SENSOR 5 VOLT
SUPPLY
36 C18 20LB/BR A/C PRESSURE SENSOR SIGNAL
37 - -
38 V37 20VT/TN SPEED CONTROL SWITCH SIGNAL
39 - -
40 K2 20TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
41 K21 20DB/LG INTAKE AIR TEMPERATURE SENSOR SIGNAL
42 Z122 18WT GROUND (DRAIN)
43 K24 20BR/LB CRANKSHAFT POSITION SENSOR SIGNAL NO. 2
44 - -
45 - -
46 - -
47 L50 20WT/TN PRIMARY BRAKE SWITCH SIGNAL
48 B29 20DG/WT SECONDARY BRAKE SWITCH SIGNAL
49 T751 20YL FUSED IGNITION SWITCH OUTPUT (START)
50 F855 20PK/YL SENSOR REFERENCE VOLTAGE A
51 - -
52 K121 20DB BOOST PRESSURE SENSOR GROUND
53 - -
RS8W-80 CONNECTOR PIN-OUTS8W-80-63
ProCarManuals.com
