2003 CHRYSLER VOYAGER sensor

LEFT LIFTGATE FLOOD LAMP - GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 Z311 20BK/VT GROUND
1 Z312 20BK/YL GROUND
2- -
3 M11 20YL/VT COURTESY LAMPS DRIVER
LEFT LOW BEAM LAMP (EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z343 16BR GROUND
2 L43 16WT LEFT LOW BEAM DRIVER
LEFT MID READING LAMP (PREMIUM/LUXURY) - GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 M22 20YL/OR COURTESY LAMPS DRIVER
2 Z327 20BK/OR GROUND
3 M27 20YL/LB READING LAMPS DRIVER
LEFT PARK LAMP (EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z343 16BR GROUND
2 L77 16BK FUSED PARK LAMP RELAY OUTPUT (LEFT)
LEFT POWER MIRROR - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1 P171 20TN/YL (EXPORT) LEFT FOLDING MIRROR UNFOLD DRIVER
2 P112 22TN/OR (EXCEPT EXPORT/
MEMORY)MIRROR B(+)
3 P114 22TN/WT (EXCEPT EXPORT/
MEMORY)MIRROR B(-)
4 P65 20TN/VT (MEMORY) LEFT MIRROR HORIZONTAL POSITION SIGNAL
5 P69 20TN/WT (MEMORY) LEFT MIRROR SENSOR GROUND
6 P64 20TN (MEMORY EXPORT) LEFT MIRROR VERTICAL POSITION SIGNAL
7 P160 20TN/LG (RHD) PASSENGER FOLDING MIRROR RELAY OUTPUT
7 P159 20TN/DG (LHD EXPORT) DRIVER FOLDING MIRROR FOLD DRIVER
8 Z215 22BK/LG GROUND
9 C16 20DB/GY (HEATED MIRRORS) FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
10 P73 20TNYL LEFT MIRROR COMMON DRIVER (RIGHT/DOWN)
11 P71 20TN/DG LEFT MIRROR UP DRIVER
12 P75 20TN/LG LEFT MIRROR LEFT DRIVER
8W - 80 - 84 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com

LEFT REAR SPEAKER (MIDLINE/HIGHLINE) - BLACK/RED 6 WAY
CAV CIRCUIT FUNCTION
1 X151 20DG/WT (HIGHLINE) LEFT REAR PILLAR SPEAKER (+)
2 X15 16GY/DG (HIGHLINE) AMPLIFIED SPEAKER GROUND
3 X157 20DG (HIGHLINE) LEFT REAR PILLAR SPEAKER (-)
4 X51 20DG/DB LEFT REAR SPEAKER (+)
5 X13 16DG/GY (HIGHLINE) NAME BRAND SPEAKER RELAY OUTPUT
6 X57 22DG/OR LEFT REAR SPEAKER (-)
LEFT REAR VENT MOTOR - NATURAL 3 WAY
CAV CIRCUIT FUNCTION
1 Q13 16OR/DB (LHD) DRIVER SIDE REAR WINDOW CLOSE
1 Q14 16OR/BR (RHD) PASSENGER SIDE REAR WINDOW CLOSE
2 Q23 16OR/LB (LHD) DRIVER SIDE REAR WINDOW OPEN
2 Q24 16OR/DG (RHD) PASSENGER SIDE REAR WINDOW OPEN
3- -
LEFT REAR WHEEL SPEED SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B4 18DG/GY LEFT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY
2 B3 18DG/YL LEFT REAR WHEEL SPEED SENSOR SIGNAL
LEFT REMOTE RADIO SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X20 20RD/BK RADIO CONTROL MUX
2 X920 20RD/DB RADIO CONTROL MUX RETURN
8W - 80 - 86 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com

LEFT TURN SIGNAL LAMP (EXPORT) - ORANGE 2 WAY
CAV CIRCUIT FUNCTION
1 Z343 16BR GROUND
2 L61 16YL LEFT FRONT TURN SIGNAL DRIVER
LEFT VISOR/VANITY LAMP (EXCEPT BASE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A Z327 20BK/OR GROUND
B M27 20YL/LB READING LAMP DRIVER
LICENSE LAMP (MANUAL RELEASE) - DK. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 L77 18WT/BR FUSED PARK LAMP RELAY OUTPUT
2 Z367 20BK/BR GROUND
LICENSE LAMP (POWER LIFTGATE) - DK. GRAY 8 WAY
CAV CIRCUIT FUNCTION
1 L77 18WT/BR FUSED PARK LAMP RELAY OUTPUT (LEFT)
2 Z367 20BK/BR GROUND
3 P30 20TN/DG LIFTGATE HANDLE SWITCH SENSE
4 Z430 20BK/LG GROUND
5 Q94 20TN/LG LIFTGATE CHIME DRIVER
6 Z294 20BK/LG GROUND
7 G32 20VT/LB LIFTGATE TEMPERATURE SENSOR SIGNAL
8 Z78 20BK/OR GROUND
8W - 80 - 90 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com

LIFTGATE CINCH/RELEASE MOTOR (POWER LIFTGATE) - BLUE 7 WAY
CAV CIRCUIT FUNCTION
1 Z78 20BK/OR GROUND
2 G78 20VT/OR LIFTGATE AJAR SWITCH SENSE
3 Q60 20OR/YL LIFTGATE PAWL SWITCH SENSE
4 Z245 18BK/GY GROUND
5 Q85 18TN/WT LIFTGATE LATCH RELEASE DRIVER
6 Q84 18TN/GY LIFTGATE LATCH CINCH DRIVER
7 Q83 18OR/GY LIFTGATE LATCH CLUTCH DRIVER
LIFTGATE CYLINDER LOCK SWITCH (EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z465 20BK/GY GROUND
2 G165 20VT/GY LIFTGATE CYLINDER LOCK SWITCH MUX
LIFTGATE LEFT PINCH SENSOR (POWER LIFTGATE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Q77 20OR/DB RIGHT PINCH SENSOR SIGNAL
2 Q76 20OR/LB PINCH SENSOR SIGNAL
LIFTGATE RIGHT PINCH SENSOR (POWER LIFTGATE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Q77 20OR/DB RIGHT PINCH SENSOR SIGNAL
2 Z78 20BK/OR GROUND
LOW NOTE HORN - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z298 18BK/DB GROUND
2 X2 18DG/OR HORN RELAY OUTPUT
8W - 80 - 92 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com

MANIFOLD ABSOLUTE PRESSURE SENSOR (GAS) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K1 18VT/BR (3.3L/3.8L) MANIFOLD ABSOLUTE PRESSURE SENSOR SIGNAL
1 K1 18VT/BR (2.4L) MAP SIGNAL
2 K900 18DB/DG SENSOR GROUND
3 F855 18PK/YL 5 VOLT SUPPLY
MASS AIR FLOW SENSOR (DIESEL) - ORANGE 5 WAY
CAV CIRCUIT FUNCTION
1- -
2 K342 16BR/WT ECM/PCM RELAY OUTPUT
3 K957 20BK/OR MASS AIR FLOW SENSOR GROUND
4 F855 20PK/YL SENSOR REFERENCE VOLTAGE A
5 K55 20DB/OR MASS AIR FLOW SENSOR SIGNAL
MEMORY SEAT/MIRROR MODULE C1 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
1 P69 20TN/WT LEFT MIRROR SENSOR GROUND
2 P25 20LG/VT SEAT HORIZONTAL POSITION SIGNAL
3 P27 20LG/LB REAR RISER POSITION SIGNAL
4- -
5- -
6 P67 20OR RIGHT MIRROR VERTICAL POSITION SIGNAL
7 P64 20TN/OR LEFT MIRROR VERTICAL POSITION SIGNAL
8 P21 20LG/TN SEAT FRONT DOWN SWITCH SENSE
9 P13 20LG/OR SEAT REAR DOWN SWITCH SENSE
10 P15 20LG/WT SEAT HORIZONTAL FORWARD SWITCH SENSE
11 P43 14LG/VT RECLINER UP SWITCH SENSE
12 - -
13 - -
14 P66 20WT RIGHT MIRROR SENSOR GROUND
15 P26 20LG FRONT RISER POSITION SIGNAL
16 P47 20LG/LB RECLINER POSITION SIGNAL
17 - -
18 - -
19 P68 20YL RIGHT MIRROR HORIZONTAL POSITION SIGNAL
20 P65 20TN/YL LEFT MIRROR HORIZONTAL POSITION SIGNAL
21 P19 20LG/LB SEAT FRONT UP SWITCH SENSE
22 P11 20LG/YL SEAT REAR UP SWITCH SENSE
23 P17 20LG/DG SEAT HORIZONTAL REARWARD SWITCH SENSE
24 P41 14LG/GY RECLINER DOWN SWITCH SENSE
25 - -
26 D25 20WT/VT PCI BUS
RS8W-80 CONNECTOR PIN-OUTS8W-80-93
ProCarManuals.com

MEMORY SEAT/MIRROR MODULE C2 - GRAY 16 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 P73 18TN/LB LEFT MIRROR COMMON DRIVER (RIGHT/DOWN)
4 P75 18DB LEFT MIRROR LEFT DRIVER
5 P71 18TN/GY LEFT MIRROR UP DRIVER
6 P29 20LG/WT SEAT SENSOR 5 VOLT SUPPLY
7- -
8- -
9- -
10 - -
11 P70 18LB RIGHT MIRROR COMMON DRIVER (RIGHT/DOWN)
12 P74 18TN/DB RIGHT MIRROR LEFT DRIVER
13 P72 18GY RIGHT MIRROR UP DRIVER
14 - -
15 - -
16 P28 20LG/BR SEAT POSITION SENSOR GROUND
MEMORY SEAT/MIRROR MODULE C3 - WHITE 12 WAY
CAV CIRCUIT FUNCTION
1 P111 14LG/YL SEAT REAR UP DRIVER
2 P115 14LG SEAT HORIZONTAL FORWARD DRIVER
3 P119 14LG/DG SEAT FRONT UP DRIVER
4 P113 14LG/WT SEAT REAR DOWN DRIVER
5 P121 14LG/DB SEAT FRONT DOWN DRIVER
6- -
7 P143 14LG/GY (EXPORT) SEAT RECLINER UP DRIVER
7 P43 14LG/VT (EXCEPT EXPORT) SEAT RECLINER UP DRIVER
8 P9 20LG/OR SEAT SWITCH B(+) SUPPLY
9- -
10 P141 14LG/BR (EXPORT) SEAT RECLINER DOWN DRIVER
10 P41 14LG/GY (EXCEPT EXPORT) SEAT RECLINER DOWN DRIVER
11 P117 14LG/LB SEAT HORIZONTAL REARWARD DRIVER
12 - -
MEMORY SEAT/MIRROR MODULE C4 - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 Z849 14BK/OR GROUND
2 A210 14OR/RD FUSED B(+)
8W - 80 - 94 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com

MULTI-FUNCTION SWITCH - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 W52 22BR/YL FRONT WIPER SWITCH MUX
2 G902 22VT/LB MULTI-FUNCTION SWITCH MUX RETURN
3 L305 20WT/LB TURN SIGNAL SWITCH MUX
4 G194 22VT/LG HIGH BEAM/FRONT WASHER SWITCH MUX
NATURAL VACUUM LEAK DETECTION ASSEMBLY (2.4L EXCEPT EXPORT) - LT. GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 Z166 18BK/WT GROUND
2 K107 20VT/WT NVLD SWITCH SIGNAL
3 K106 20VT/LB NVLD SOL CONTROL
OUTPUT SPEED SENSOR (EATX) - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 T13 18DG/VT SPEED SENSOR GROUND
2 T14 18DG/BR OUTPUT SPEED SENSOR SIGNAL
OVERHEAD CONSOLE (EXCEPT BASE) - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1 G23 20VT/DB (EXCEPT SUNROOF) SLIDING DOORS OVERHEAD SWITCH MUX
1 G23 22VT/DB (SUNROOF) SLIDING DOORS OVERHEAD SWITCH MUX
2 G25 20VT/TN (EXCEPT SUNROOF) LIFTGATE SWITCH MUX
2 G25 22VT/TN (SUNROOF) LIFTGATE SWITCH MUX
3 D25 20WT/VT PCI BUS
4 Z113 20BK/DB GROUND
5 A114 20GY/RD FUSED B(+) (I.O.D.)
6 F503 20WT/PK FUSED IGNITION SWITCH OUTPUT (RUN)
7 Z13 20BK/WT GROUND
8 E15 20OR/DB ASH/RECEIVER LAMP FEED
9- -
10 - -
11 L24 20BK/GY (EXCEPT EXPORT/
PREMIUM/LUXURY)AUTOMATIC HEADLAMP SWITCH SENSOR
12 L1 20BK/WT (PREMIUM/LUXURY) BACK-UP LAMP FEED
8W - 80 - 96 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com

OXYGEN SENSOR 1/1 UPSTREAM (GAS) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K99 18BR/LG (3.3L/3.8L) OXYGEN SENSOR 1/1 HEATER CONTROL
1 Z42 18BK/LG (2.4L) GROUND
2 K99 18BR/LG (2.4L) O2 1/1 HEATER CONTROL
2 K342 16BR/WT (3.3L/3.8L) AUTOMATIC SHUT DOWN RELAY OUTPUT
3 K902 18BR/DG (3.3L/3.8L) OXYGEN SENSOR 1/1 GROUND
3 K902 18BR/DG (2.4L) O2 RETURN (UP)
4 K41 18DB/LB (2.4L) O2 1/1 SIGNAL
4 K41 18DB/LB (3.3L/3.8L) OXYGEN SENSOR 1/1 SIGNAL
OXYGEN SENSOR 1/2 DOWNSTREAM (GAS) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 Z43 18BK/DB GROUND
2 K342 16BR/WT (3.3L/3.8L) AUTOMATIC SHUT DOWN RELAY OUTPUT
2 K299 18BR/WT (2.4L) O2 1/2 HEATER CONTROL
3 K904 18DB/DG (2.4L) O2 RETURN (DOWN)
3 K902 18BR/DG (3.3L/3.8L) OXYGEN SENSOR 1/2 GROUND
4 K141 18DB/YL (3.3L/3.8L) OXYGEN SENSOR 1/2 SIGNAL
4 K141 18DB/YL (2.4L) O2 1/2 SIGNAL
PASSENGER AIRBAG - YELLOW 4 WAY
CAV CIRCUIT FUNCTION
1 R42 18LB/BR PASSENGER SQUIB 1 LINE 2
2 R44 18LB/OR PASSENGER SQUIB 1 LINE 1
3 R62 18LB/VT (EXCEPT LHD EXPORT) PASSENGER SQUIB 2 LINE 2
3 R62 18LG/DB (LHD EXPORT) PASSENGER SQUIB 2 LINE 2
4 R64 18LB/WT PASSENGER SQUIB 2 LINE 1
PASSENGER BLEND DOOR ACTUATOR (ATC) - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 C133 20DB/WT PASSENGER BLEND DOOR DRIVER (B)
2 C33 20LB/BR PASSENGER BLEND DOOR DRIVER (A)
RS8W-80 CONNECTOR PIN-OUTS8W-80-97
