2003 CHEVROLET SSR relay

Fuses Usage
25 Blank
26 Blank
27 HomeLink
®System
28 Roof Door Module
29 Blank
31 Truck Body Controller
32 Remote Keyless Entry (RKE)
33 Windshield Wipers
34 Stoplamps
35 Blank
36Climate Control System,
Driver’s Door Unlock
37 Front Parking Lamps
38 Driver’s Side Turn Signal
39 Climate Control System
40 Truck Body Controller
41 Radio
42 Trailer Parking Lamps
43 Passenger’s Side Turn Signal
44 Blank
Fuses Usage
46 Accessory Power Outlets
47 Ignition
48 Blank
49 Blank
50 Truck Body Controller, Ignition
51 Brakes
52 Blank
Relays Usage
18 Locks
24 Unlock
30 Parking Lamps
45Rear Window Defogger,
Outside Power Heated Mirrors
Circuit
BreakersUsage
01 Roof & Door Module
02 Roof Pump
08 Power Seats
5-84

Relays Usage
34 Air Conditioning
35 Fuel Pump
36 Fog Lamps
37 High Beam Headlamps
38 Cargo Cover Release
39 Horn
40 Windshield Washer
41 Headlamp Driver Module
42 Ignition
43 StarterRelay Center
There is a relay center located in the area where the
convertible top is stored when it is open. To access the
relay center, do the following:
1. Open the convertible top until the roof tonneau and
the boot cover panel are upright so that you can
reach into the convertible top storage area as
shown. See “Convertible Top Operation” under
Convertible Top on page 2-37for more information.
5-87

2. Locate the water-tight box that houses the relay
center and remove the four nuts that secure the
cover to the backside of the passenger
compartment.
3. Press in the tabs on the sides of the cover and lift
to remove the cover.4. Locate the relay center inside the box. It is located
toward the driver’s side of the vehicle.
5. Press in the tabs at each end of the relay center
cover and lift to remove.
6. Reverse the steps to reinstall the relay center cover
and close the water-tight box.
5-88

Following is a list of
relays contained in
the relay center.Relays Usage
eDriver’s Door Lock
RT DRLPassenger’s Side Daytime
Running Lamps (DRL)
LT DRLDriver’s Side Daytime
Running Lamps (DRL)
=Rear Window Defogger
5-89
