2003 CHEVROLET CORVETTE key

Ignition Automatic Transmission
Lock Check
While parked, and with the parking brake set, try to turn
the ignition key to OFF in each shift lever position.
The key should turn to OFF only when the shift lever is
in PARK (P).
On all vehicles, the key should come out only in OFF.
Parking Brake and Automatic
Transmission Park (P)
Mechanism Check
{CAUTION:
When you are doing this check, your vehicle
could begin to move. You or others could be
injured and property could be damaged. Make
sure there is room in front of your vehicle in
case it begins to roll. Be ready to apply the
regular brake at once should the vehicle begin
to move.Park on a fairly steep hill, with the vehicle facing
downhill. Keeping your foot on the regular brake, set the
parking brake.
·To check the parking brake's holding ability:
With the engine running and transmission in
NEUTRAL (N), slowly remove foot pressure from
the regular brake pedal. Do this until the vehicle is
held by the parking brake only.
·To check the PARK (P) mechanism's holding
ability: With the engine running, shift to PARK (P).
Then release the parking brake followed by the
regular brake.
Underbody Flushing Service
At least every spring, use plain water to ¯ush any
corrosive materials from the underbody. Take care to
clean thoroughly any areas where mud and other debris
can collect.
6-11

Usage Fluid/Lubricant
Key Lock
CylindersMulit-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241, in
Canada 10953474, or equivalent).
Rear Axle
(Limited-Slip
Differential)SAE 75W-90 Synthetic Axle
Lubricant (GM Part No. U.S.
12378261, in Canada 10953455, or
equivalent) meeting GM
Speci®cation 9986115. With a
complete drain and re®ll add
4 ounces (118 ml) of Limited-Slip
Axle Lubricant Additive (GM Part
No. U.S. 1052358, in Canada
992694, or equivalent) where
required. See
Rear Axle on
page 5-46.
Usage Fluid/Lubricant
Hood Latch
Assembly,
Secondary
Latch, Pivots,
Spring Anchor
and Release
PawlLubriplate Lubricant Aerosol (GM
Part No. U.S. 12346293, in Canada
992723, or equivalent) or lubricant
meeting requirements of NLGI #2,
Category LB or GC-LB.
Hood and Door
HingesMulti-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241, in
Canada 10953474, or equivalent).
Weatherstrip
ConditioningDielectric Silicone Grease (GM Part
No. U.S. 12345579, in Canada
10953014, or equivalent).
6-15

Roadside Assistance Program
To enhance Chevrolet's strong commitment to customer
satisfaction, Chevrolet is excited to announce the
establishment of the Chevrolet Roadside Assistance
Center. As the owner of a 2003 Chevrolet, membership
in Roadside Assistance is free.
Roadside Assistance is available 24 hours a day,
365 days a year, by calling 1-800-CHEV-USA
(243-8872). This toll-free number will provide you
over-the-phone roadside assistance with minor
mechanical problems. If your problem cannot be
resolved over the phone, our advisors have access to a
nationwide network of dealer recommended service
providers. Roadside membership is free; however some
services may incur costs.
Roadside offers two levels of service to the customer,
Basic CareandCourtesy Care:
RoadsideBasic Careprovides:
·Toll-free number, 1-800-CHEV-USA (243-8872),
text telephone (TTY) users, call 1-888-889-2438
·Free towing for warranty repairs
·Basic over-the-phone technical advice
·Available dealer services at reasonable costs (i.e.,
wrecker services, locksmith/key service, glass
repair, etc.)Roadside
Courtesy Careprovides:
·RoadsideBasic Careservices (as outlined
previously)
Plus:
·FREE Non-Warranty Towing (to the closest dealer
from a legal roadway)
·FREE Locksmith/Key Service (when keys are lost
on the road or locked inside)
·FREE Flat Tire Service (spare installed on the road)
·FREE Jump Start (at home or on the road)
·FREE Fuel Delivery ($5 of fuel delivered on
the road)
Chevrolet offers Courtesy Transportation for customers
needing warranty service. Courtesy Transportation
will be offered in conjunction with the coverage provided
by the Bumper-to-Bumper New Vehicle Limited
Warranty to eligible purchasers of 2003 Chevrolet
passenger cars and light duty trucks. (See your selling
dealer for details.)
Courtesy Careis available to retail and retail lease
customers operating 2003 and newer Chevrolet vehicles
for a period of 3 years/36,000 miles (60 000 km),
whichever occurs ®rst. All
Courtesy Careservices must
be pre-arranged by Chevrolet Roadside or dealer
service management.
7-6

How to Wear Safety Belts Properly...................1-12
Hydraulic Clutch.............................................5-22
Hydroplaning..................................................4-21
I
If No Steam Is Coming From Your Engine..........5-28
If Steam Is Coming From Your Engine...............5-27
If the Light Is Flashing.....................................3-39
If the Light Is On Steady.................................3-39
If You Are Stuck in Sand, Mud, Ice or Snow.......4-32
If You're Caught in a Blizzard...........................4-30
Ignition Automatic Transmission
Lock Check................................................6-11
Ignition Positions.............................................2-20
Infants and Young Children, Restraints...............1-23
In¯ation -- Tire Pressure..................................5-56
In¯ator Kit, Tire...............................................5-70
Inspection......................................................6-13
Brake System.............................................6-13
Engine Cooling System................................6-13
Exhaust System..........................................6-12
Fuel System...............................................6-13
Part C - Periodic Maintenance.......................6-12
Steering and Suspension..............................6-12
Tire and Wheel...........................................6-12
Installing the Roof Panel..................................2-47
Instrument Panel Brightness.............................3-15
Instrument Panel Fuse Block............................5-86Instrument Panel.............................................3-30
Cluster.......................................................3-30
Overview..................................................... 3-2
Integrated Windshield and Rear Window
Antennas....................................................3-80
Interior Lamps................................................3-15
J
Jump Starting.................................................5-41
K
Key Lock Cylinders Service................................ 6-9
Keyless Entry System....................................... 2-4
Keys............................................................... 2-3
L
Lamps...........................................................3-12
Exterior......................................................3-12
Interior.......................................................3-15
Lap Belt Cinch Feature....................................1-14
Lap-Shoulder Belt...........................................1-13
LATCH System...............................................1-31
Child Restraints...........................................1-31
Securing a Child Restraint Designed for the
LATCH System........................................1-33
7

P
Park (P)........................................................2-31
Shifting Into................................................2-31
Shifting Out of............................................2-33
Parking Brake and Automatic Transmission
Park (P) Mechanism Check...........................6-11
Parking Your Vehicle.......................................2-34
Parking.........................................................2-30
Brake........................................................2-30
Over Things That Burn.................................2-34
Part A - Scheduled Maintenance Services............ 6-4
Part B - Owner Checks and Services.................. 6-8
Part C - Periodic MaintenanceInspections..........6-12
Part D - Recommended Fluids and Lubricants....6-14
Part E - Maintenance Record...........................6-16
Passenger Position, Safety Belts.......................1-20
Passing.........................................................4-15
PASS-Key
ž....................................................2-17
Plan Ahead When Possible................................ 7-7
Playing a Cassette Tape..................................3-65
Playing a Compact Disc...................................3-69
Playing the Radio...................................3-63, 3-67
Power Antenna Service..................................... 6-8
Power Steering...............................................4-13
Power...........................................................3-20
Accessory Outlets........................................3-20
Antenna Mast Care......................................3-79
Door Locks.................................................2-10
Electrical System.........................................5-85Power (cont.)
Seat............................................................ 1-2
Steering Fluid.............................................5-35
Windows....................................................2-15
Q
Questions and Answers About Safety Belts.........1-11
R
Racing or Other Competitive Driving..................2-22
Radios..........................................................3-62
Care of Your Cassette Tape Player................3-78
Care of Your CD Player...............................3-79
Care of Your CDs........................................3-79
Radio with Cassette.....................................3-63
Radio with CD............................................3-67
Setting the Time..........................................3-62
Theft-Deterrent............................................3-75
Trunk-Mounted CD Changer..........................3-71
Understanding Reception..............................3-77
Raising the Convertible Top..............................2-53
Reading Lamps..............................................3-16
Rear Axle......................................................5-46
Limited-Slip.................................................4-11
Service......................................................6-13
Rear Storage Area..........................................2-41
Rear Window Defogger....................................3-27
10

Rearview Mirror, Automatic Dimming..................2-37
Rearview Mirrors.............................................2-37
Reclining Seatbacks.......................................... 1-3
Recreational Vehicle Towing.............................4-33
Remote Keyless Entry System, Operation............ 2-5
Remote Keyless Entry System............................ 2-4
Removing the Roof Panel................................2-43
Replacement Bulbs.........................................5-51
Replacing Brake System Parts..........................5-40
Replacing Restraint System Parts
After a Crash..............................................1-48
Reporting Safety Defects.................................7-10
Canadian Government..................................7-10
General Motors...........................................7-10
United States Government.............................. 7-9
Restraint System Check.................................... 6-9
Checking Your Restraint Systems...................1-48
Replacing Restraint System Parts After a
Crash.....................................................1-48
Restraint Systems...........................................1-48
Checking....................................................1-48
Replacing Parts...........................................1-48
Retained Accessory Power (RAP)......................2-21
Roadside......................................................... 7-6
Assistance Program....................................... 7-6
Rocking Your Vehicle To Get It Out...................4-32
Roof Panel....................................................2-43
Installing the Roof Panel...............................2-47
Removing the Roof Panel.............................2-43Roof Panel (cont.)
Storing the Roof Panel.................................2-46
Running Your Engine While You Are Parked.......2-36
S
Safety Belt.....................................................3-31
Reminder Light............................................3-31
Safety Belts...................................................5-77
Care of......................................................5-77
Driver Position............................................1-13
How to Wear Safety Belts Properly................1-12
Passenger Position......................................1-20
Questions and Answers About Safety Belts.....1-11
Safety Belt Extender....................................1-20
Safety Belt Use During Pregnancy.................1-20
Safety Belts Are for Everyone......................... 1-7
Safety Warnings and Symbols.............................. iii
Scheduled Maintenance..................................... 6-4
Seatback Latches............................................. 1-5
Seats.............................................................. 1-2
Manual........................................................ 1-2
Power Seats................................................. 1-2
Reclining Seatbacks...................................... 1-3
Seatback Latches.......................................... 1-5
Sport Seat................................................... 1-6
11

Securing a Child Restraint................................1-33
Designed for the LATCH System...................1-33
Passenger Seat Position...............................1-34
Security Light.................................................3-42
Selective Ride Control.....................................4-12
Sensors.........................................................3-26
Service Bulletins.............................................7-11
Service Manuals.............................................7-10
Service........................................................... 5-3
Adding Equipment to the Outside of Your
Vehicle..................................................... 5-4
Doing Your Own Work................................... 5-3
Engine Soon Light.......................................3-38
Publications Ordering Information...................7-10
Servicing Your Air Bag-Equipped Vehicle............1-47
Setting Preset Stations............................3-64, 3-68
Setting the Time.............................................3-62
Setting the Tone (Bass/Treble)..................3-64, 3-68
Shift Speeds (Manual Transmission)..................2-28
Shifting Into Park (P).......................................2-31
Shifting Out of Park (P)...................................2-33
Skidding........................................................4-17
Some Other Rainy Weather Tips.......................4-21
Speci®cations, Capacities.................................5-92
Speedometer..................................................3-31
Sport Seat....................................................... 1-6
Starter Interlock Feature..................................2-22
Starter Switch Check.......................................6-10
Starting Your Engine.......................................2-21
Steering and Suspension Inspection..................6-12Steering in Emergencies..................................4-14
Steering Tips..................................................4-13
Steering........................................................4-13
Storage Areas................................................2-39
Center Console Storage Area........................2-39
Convenience Net.........................................2-42
Cupholder(s)...............................................2-39
Glove Box..................................................2-39
Rear Storage Area.......................................2-41
Storing the Roof Panel....................................2-46
Stuck in Sand, Mud, Ice or Snow......................4-32
Sun Visors.....................................................2-15
T
Tachometer....................................................3-31
Taillamps.......................................................5-49
Turn Signal Lamps......................................5-49
TCS Warning Light..........................................3-36
Telescopic Steering Column............................... 3-5
Testing the Alarm............................................2-17
Theft-Deterrent, Radio.....................................3-75
Theft-Deterrent System....................................2-16
Theft-Deterrent Systems...................................2-16
PASS-Key
ž.................................................2-17
Tilt Wheel........................................................ 3-5
Tire In¯ation Check........................................... 6-8
Tire In¯ator Kit Storage....................................5-73
Tire Sealant...................................................5-71
12
