2003 CHEVROLET C/K clock

5-17
6. Turn the stud nut
clockwise several turns
to release the brakes.
Follow the same
procedure to release the
other brake.
7. At the repair facility, apply air pressure of at least
70 psi (480 kPa) to the brake chambers, either from
an external air supply or the vehicle's air system.
8. Turn the stud nut counterclockwise several turns.
Remove the stud from the chamber.
9. Replace the stud and washer and tighten the nut
into the side of the chamber.
10. Replace the rubber cap.Engine Overheating
You will find a coolant temperature warning gage on
your vehicle's instrument panel, as well as a low coolant
warning light. Your vehicle also has a check gages
warning light on the instrument panel.

5-23
CAUTION:
Adding only plain water to your cooling system
can be dangerous. Plain water, or some other
liquid such as alcohol, can boil before the proper
coolant mixture will. Your vehicle's coolant
warning system is set for the proper coolant
mixture. With plain water or the wrong mixture,
your engine could get too hot but you wouldn't
get the overheat warning. Your engine could
catch fire and you or others could be burned.
Use a 50/50 mixture of clean, drinkable water
and DEX
-COOL
coolant.
NOTICE:
In cold weather, water can freeze and crack the
engine, radiator, heater core and other parts.
Use the recommended coolant and the proper
coolant mixture.
CAUTION:
You can be burned if you spill coolant on hot
engine parts. Coolant contains ethylene glycol
and it will burn if the engine parts are hot
enough. Don't spill coolant on a hot engine.
1. Park the vehicle on a level surface. You can remove
the coolant surge tank pressure cap when the cooling
system, including the coolant surge tank pressure cap
and upper radiator hose, is no longer hot. Turn the
pressure cap slowly counterclockwise (left) about
one full turn. If you hear a hiss, wait for that to stop.
A hiss means there is still some pressure left.

6-12
5. Open the fuel filter vent
valve by turning the
screw counterclockwise
several full turns.
6. Repeatedly press down
on the fuel filter primer
pump with the palm
of your hand. Let the
pump return upward
between presses.7. Operate the priming pump until a small amount of
fuel seeps from the vent valve. When you see the
fuel, the filter is now full of fuel and the system
should be primed.
8. Close the vent valve.
9. Clean any fuel which accumulated on the fuel filter.
10. Start the engine and let it idle for a few minutes.
11. Check the filter for leaks.

6-14 Fuel Filter Replacement (Diesel Engines)
If you want to change the fuel filter yourself, here's how
to do it:
CAUTION:
Diesel fuel is flammable. It could start a fire if
something ignites it, and you could be burned.
Don't let it get on hot engine parts, and keep
matches or other ignition sources away.
First, drain any water from the filter following the
procedure for draining water listed previously.
Your vehicle's engine should be off until the end of
this procedure.
The fuel filter is located in the engine compartment on
the passenger's side of the vehicle, or on the driver's
side frame rail in front of the fuel tank.
1. Apply the parking brake.
2. Unplug the water sensor
wire connected to the
fuel filter and unscrew
the filter element.
3. Remove the filter element. If there is any dirt on the
filter sealing surface, clean it off. Remove and reuse
the water sensor float switch located on the bottom
of the fuel filter.
4. Install the new filter element.
5. Reinstall and tighten the filter container and
reconnect the water sensor wire to the filter.
6. Use the fuel filter priming procedure earlier in this
section to prime the fuel filter.
7. Tighten the air bleed valve by turning it clockwise
until hand tight.
8. Start your engine and let it idle for five minutes.
Check your fuel filter and air bleed valve for leaks.

6-16
C6/C7/C8 Models
CAUTION:
Fuel vapor is highly flammable. It burns
violently, and that can cause very bad injuries.
Don't smoke if you're near fuel or refueling your
vehicle. Keep sparks, flames and smoking
materials away from fuel.
The fuel cap can be on either or both sides of your
vehicle depending on option content.
To take off the cap, turn it slowly to the left
(counterclockwise).
CAUTION:
Gasoline Engine Vehicles: If you get gasoline on
you and then something ignites it, you could be
badly burned. Gasoline can spray out on you if
you open the fuel cap too quickly. This spray can
happen if your tank is nearly full, and is more
likely in hot weather. Open the fuel filler cap
slowly and wait for any ªhissº noise to stop. Then
unscrew the cap all the way.
When you put the cap back on, turn it to the right
(clockwise) until it is tight.

6-56 Automatic Ether Injection System
(If Equipped)
If you have a Caterpillar
diesel engine, you may have
this feature. The ether
cylinder is located in the
engine compartment on the
driver's side of the vehicle.To change an empty ether cylinder, follow these steps.
1. Loosen the screw head on the cylinder
-to-bracket
clamp.
2. Spread the clamp apart.
3. Clean any dirt from the neck of the cylinder and the
top of the valve before you take out the cylinder.
4. Check the inside of the valve for any foreign matter.
Clean the valve as necessary.
5. Cover the valve to protect it from dirt and take out
the cylinder.
6. Install a new gasket whenever you take out the
cylinder. Use only one gasket and spread a light film
of clean oil on it before installation.
7. Put in the new cylinder. Turn it clockwise until it just
starts to contact the gasket.
8. Tighten the cylinder another half turn (180 degrees).
Don't over
-tighten.
9. Retighten the cylinder clamp.

6-63
Hub-Piloted Type,
8
-HoleHub
-Piloted Type,
10
-Hole
Then, follow the steps below for the wheels you have.
CAUTION:
Never use oil or grease on studs or the threads of
the wheel nuts. If you do, the nuts might come
loose. Your wheel could fall off, causing a crash.
Hub-Piloted Wheels, 8-Hole or 10-Hole
The studs and nuts used with these wheels have
right
-hand threads.
1. With intermittent pilot pads, position a pad at
12 o'clock to center the wheel and reduce run
-out.
2. Put the tire and rim assembly on the axle hub. Install
the outer rear tire and rim assembly so that its valve
stem is exactly opposite the valve stem on the inner
tire and rim assembly.
3. Put on the wheel nuts.
4. Finger
-tighten the nuts.
5. Oil the surfaces between the nuts and washers.
Do not oil the studs or the threads of the nut.
6. Tighten the nuts to 400 lb
-ft (542 N´m) if an 8-hole
stud or 480 lb
-ft (650 N´m) if a 10-hole stud. Use the
following diagrams.
