2002 SUBARU IMPREZA WRX ECO mode

11
11-1
– CONTINUED –
Maintenance schedule 11-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance precautions 11-3 . . . . . . . . . . . . . . . . . . . . . . . .
Engine hood 11-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine compartment overview 11-7 . . . . . . . . . . . . . . . . .
2.5 liter model 11-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.0 liter (Turbo) model 11-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil 11-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the oil level 11-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the oil and oil filter 11-10 . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-11 . . . . . . . . . . .
Recommended grade and viscosity under
severe driving conditions 11-13 . . . . . . . . . . . . . . . . . . . . . .
Cooling system 11-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hose and connections 11-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant 11-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air cleaner element 11-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing the air cleaner element 11-18 . . . . . . . . . . . . . .
Spark plugs 11-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended spark plugs 11-21 . . . . . . . . . . . . . . . . . . . . .
Drive belts 11-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission oil 11-23 . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the oil level 11-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-24 . . . . . . . . . . .
Automatic transmission fluid 11-24 . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-24 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended fluid 11-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front differential gear oil (AT vehicles) 11-26 . . . . . Checking the oil level 11-26
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-26 . . . . . . . . . . .
Rear differential gear oil 11-27 . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the gear oil level 11-27 . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-28 . . . . . . . . . . .
Power steering fluid 11-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-29 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended fluid 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake fluid 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended brake fluid 11-31 . . . . . . . . . . . . . . . . . . . . . . .
Clutch fluid (MT vehicles) 11-31 . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-31 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended clutch fluid 11-32 . . . . . . . . . . . . . . . . . . . . . .
Brake booster 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pedal 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the brake pedal free play 11-33 . . . . . . . . . . . .
Checking the brake pedal reserve distance 11-34 . .
Clutch pedal (MT vehicles) 11-34 . . . . . . . . . . . . . . . . . . . . . .
Checking the clutch function 11-34 . . . . . . . . . . . . . . . . . . . .
Checking the clutch pedal free play 11-35 . . . . . . . . . . .
Replacement of brake pad and lining 11-35 . . . . . . . .
Breaking-in of new brake pads and linings 11-36 . . .
Parking brake stroke 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires and wheels 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Types of tires 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire inspection 11-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire pressures and wear 11-38 . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance and service

Maintenance and service
11-11
– CONTINUED –
5. Wipe the seating surface of the drain plug with a
clean cloth and tighten it securely with a new seal-ing washer after the oil has completely drained out.
HS0176
1) Oil filter
6. Remove the oil filter with an oil filter wrench.
7. Before installing a new oil filter, apply a thin coat of engine oil to the seal.
8. Clean the rubber seal seating area of the lower
crank case and install the oil filter by hand turning.
Be careful not to twist or damage the seal.
9. Tighten it approximately two-thirds of a turn afterthe seal makes contact with the lower crank case.
CAUTION
Never over tighten the oil filter because that can result in an oil leak.
10. Pour the specified amount of engine oil throughthe filler neck.
Oil capacity: Non-turbo models: 4.2 US qt (4.0 liters, 3.5 Imp qt)
Turbo models: 4.8 US qt (4.5 liters, 4.0 Imp qt)
11. Start the engine and make sure that no oil leaks
appear around the filter ’s rubber seal.
12. Run the engine until it reaches the normal oper-
ating temperature. Then stop the engine and wait a
few minutes to allow the oil drain back. Check the oil
level again and if necessary, add more engine oil. Recommended grade and viscosity
CAUTION
Use only engine oil with the recommended
grade and viscosity.

Maintenance and service
11-18
diator cap is correctly in place.
6. Start and run the engine for more than five min-utes at 2,000 to 3,000 rpm.
7. Stop the engine and wait until the coolant coolsdown (122 to 140°F [50 to 60 °C]). If there is any loss
of coolant, add coolant to the radiator ’s filler neck
and to the reserve tank ’s “FULL” level.
8. Put the radiator cap and reservoir cap back on
and tighten firmly. Air cleaner element
WARNING
Do not operate the engine with the air cleaner
element removed. The air cleaner element notonly filters intake air but also stops flames ifthe engine backfires. If the air cleaner elementis not installed when the engine backfires, youcould be burned.
The air cleaner element functions as a filter screen.
When the element is perforated or removed, engine
wear will be excessive and engine life shortened.
The air cleaner element is a viscous type. It is un-
necessary to clean or wash the element. Replacing the air cleaner element
Non-turbo models
Replace the air cleaner element according to the
maintenance schedule in the “Warranty and Mainte-
nance Booklet ”. Under extremely dusty conditions,
replace it more frequently. It is recommended that
you always use genuine SUBARU parts.

Maintenance and service
11-21
– CONTINUED –
Spark plugs
CAUTION
When disconnecting the spark plug cables,
always grasp the spark plug cap, not the cables. Make sure the cables are replaced in the
correct order.
HBA004BA
It may be difficult to replace the spark plugs. It is
recommended that you have the spark plugs re-
placed by your SUBARU dealer.
The spark plugs should be replaced according to the maintenance schedule in the
“Warranty and
Maintenance Booklet ”.
Recommended spark plugs
Non-turbo models: RC10YC4 (Champion) BKR6E-11 (NGK)
BKR5E-11 (NGK)
Turbo models: PFR6G (NGK)

GAS STATION REFERENCE
Fuel: 2.5 Liter models: Use only unleaded gasoline with an octane
rating of 87 AKI or higher.
2.0 Liter (Turbo) models:
Use premium unleaded gasoline with an oc-
tane rating of 91 AKI or higher. If premium un-
leaded gasoline is not available, regular un-
leaded gasoline with octane rating of 87 AKI
or higher may be temporarily used. For opti-
mum engine performance and driveability, it
is recommended that you use premium grade
unleaded gasoline. Fuel octane rating: This octane rating is the average of the Re-
search Octane and Motor Octane numbers
and is commonly referred to as the Anti
Knock Index (AKI). Refer to “Fuel” section inthis manual.Fuel capacity:
15.9 US gal (60 liters, 13.2 Imp gal)
Engine oil:
Use only API classification SJ or SH with the
words “ENERGY CONSERVING II”
or the New API certification mark (starburst
mark) displayed on the container.
Engine oil capacity: Non turbo models:
4.2 US qt (4.0 liters, 3.5 Imp qt)
Turbo models: 4.8 US qt (4.5 liters, 4.0 Imp qt)
Cold tire pressure:
See the label located under the driver’s door latch.
