2002 SUBARU IMPREZA WRX ECO mode

Audio
5-21
– CONTINUED –
Tape program sensor button (TPS)
n Blank skip
When the “TPS” button (13) is pressed, the “TPS” in-
dicator will come on and the player will automatically
skip any blank portion of 15 second or more and
play the next program, even if it is on the other side.
To cancel blank skip mode, press the “TPS” button
again.
n Blank search
Press “TPS” button (13) during playback to return to
the beginning of the current selection or to skip to
the beginning of the next selection. To use this func-
tion, press the “TPS” button to turn on the “TPS” in-
dicator. If the fast-forward button “FF” (15) is then
pressed, the player advances the tape to the begin-
ning of the next selection and starts playing it. If the
rewind button “REW” (17) is pressed instead, the
player rewinds the tape to the beginning of the cur-
rent selection and starts replaying it. The “TPS”
function may not operate properly under the follow- ing conditions: When the recording level is low.
When there are long pauses in the middle of a
selection. When the tape contains verbal material such as
conversations.
When the blanks between selections are shorter
than five seconds. When there are no blanks between selections (live
concerts, etc.).
Repeat button (RPT)
Push the “RPT” button (11) to repeat the piece of
music being listened to. To use this function, push the “RPT” button while the piece you want to hear
again is being played. “RPT” will be indicated on the
display. When the selection ends, the cassette play-
er automatically rewinds to the beginning of the
piece and the selection begins again. To cancel the
repeat function, push the “RPT” button again. Until
the repeat function is cancelled, the same piece of
music will be repeated indefinitely. The “RPT” func-
tion may not operate properly under the followingconditions: When the recording level is low.
When there are long pauses in the middle of a
selection. When the tape contains verbal material such as
conversations. When the blanks between selections are shorter
than five seconds. When there are no blanks between selections (live
concerts, etc).

Audio
5-23
– CONTINUED –
NOTE
Make sure to always insert a disc with the label side up. If a disc is inserted with the label sidedown, it might be ejected or the player mightshut off.
How to insert a CD(s)
n Inserting a CD
1. Press “LOAD” button (18). If the magazine in the
player has an idle position where you can insert adisc, the “DISC” indicator associated with the idle
position will blink.
If no indicator blinks, it means that there is no idleposition in the magazine.
2. As soon as the “DISC” indicator begins to blink,
the “IN” will appear on display for a period of 15 se-
conds. Insert a disc during the period. The disc will be then automatically drawn in, and the player willbegin to play back the first number of the disc. To insert more discs in succession, repeat Steps 1
and 2. The magazine will be loaded with discs in the
ascending order of position number.
If you do not insert any disc in 15 seconds after you
have pressed the “LOAD” button, the player will be-
gin to play back the first number of the last disc you
have inserted.
The disc indicator steadily lights up if a disc is al-
ready inserted in the corresponding position of themagazine. While the player is in the loading mode, if you
press any of the other mode buttons “FM” (2), “AM”
(1)
and “TAPE” (12), the player will enter the stand-
by mode. Press the “CD” button (21) to start play-
back.
n Inserting a disc in a desired position
1. Press the “LOAD” button. If the magazine in the
player has an idle position where you can insert adisc, the “DISC” indicator associated with the idle
position will blink.
The positions in the magazine the indicator of which
steadily lights up are already loaded with discs.
2. Press the “DISC SELECT ” button (26) at the posi-
tion where you want to insert a disc. The associated
“DISC” indicator will blink, and the “IN” will be dis-
played.
3. If you insert a disc during the 15-second periodwhile the “IN” is on display, the disc will be automati-
cally drawn in, and the player will start playback of
the disc, beginning with the first number. To insert more discs in succession, repeat Steps 1
and 2. While the player is in the loading mode, if you

Audio
5-24
press any of the other mode buttons “FM” (2), “AM”
(1) and “TAPE” (12), the player will enter standby
mode. Press the “CD” button to start playback.
n Loading all the magazine (Full disc loading mode)
1. If you continue to press the “LOAD” button for
more than 1.5 seconds, the player will produce beep sound and will enter the full disc loading mode.
2. A “DISC” indicator will blink, and the “IN” will be
on display for a period of 15 seconds. If a disc issuccessfully loaded during this period, the “DISC”
indicator will stop blinking and will steadily light.
3. When the loading of a disc is complete, the next
“DISC” indicator will blink. Then repeat Step 2.
4. When the magazine is filled with discs by repeat-
ing Steps 2 and 3, the player will start playback of
the discs, beginning with the one inserted first.
If you fail to insert any disc during each 15-second interval, the full disc loading mode will be canceled,
and the player will start playback of the disc in-
serted first.
How to play back a CD or make a pause
n When there is no CD inserted:
Insert a CD by referring to “How to Insert a CD(s) ”.When a CD is loaded, the player will start playback
of the CD, beginning with the first number.
n When there are CDs loaded:
Press a desired one of the “DISC SELECT ” buttons
(26) the “DISC” indicator of which steadily lights up.
The player will then start playback of the selected
CD, beginning with the first number.
Selecting a desired track (TRACK)
HS5005BA
❚: Skipping forward
❚ : Skipping backward
: Fast forwarding
: Fast reversing

Audio
5-25
– CONTINUED –
nSkipping forward
Turn the “TRACK” knob (24) clockwise and release it
immediately to skip to the beginning of the next
track. Each time the knob is turned and released,
the indicated track number will increase.
n Skipping backward
Turn the “TRACK” knob (24) counterclockwise and
release it immediately to skip to the beginning of the
current track. If you continue to turn and release the
knob, the indicated truck number will decrease.
n Fast forwarding
Turn the “TRACK” knob (24) clockwise and hold it
continuously for more than 2 seconds to fast forwardthe disc.
Release the knob to stop fast forwarding.
n Fast reversing
Turn the “TRACK” knob (24)
counterclockwise and
hold it continuously for more than 2 seconds to fast
reverse the disc.
Release the knob to stop fast reverse.
Repeat playback
Press the “RPT” button (25) while a song is playing
to play the song repeatedly. The “RPT” indicator will
come on and the song will be played continuously. To cancel the repeat mode, press the button again.
Then the
“RPT” indicator goes out, and normal play-
back mode is restored.
Random playback
Press the “RDM” button (23) while a disc is being
played back to play all songs on the disc in a ran-
dom order. The “RDM” indicator will come on and all
songs on the disc will be played in a random order.
To cancel the random mode, press the button again.
Then the “RDM” indicator goes out, and normal
playback mode is restored.
Scan
When the “SCAN” button (19) is pressed while the
disc is being played back, you can hear the first 10
seconds of each track to search for the desired pro-
gram. To continue listening to the program, pressthe “SCAN” button again. After all tracks on the disc
have been scanned, normal playback mode is re-
stored.
How to unload CDs from the player
n Ejecting a CD from the player
Of the discs loaded, you can select and removeonly one disc.
1. Press the “DISC SELECT ” button (26) of the disc

Starting and operating
7-2
Fuel
CAUTION
Use of a fuel which is low in quality or use of an inappropriate fuel additive may cause en- gine damage.
Fuel requirements
2.5 Liter models
The 2.5 Liter engine is designed to operate using
unleaded gasoline with an octane rating of 87 AKI or
higher.
2.0 Liter (turbo) models
The 2.0 Liter turbo engine is designed to operate
using premium unleaded gasoline with an octane
rating of 91 AKI or higher. If premium unleaded gas-
oline is not available, regular unleaded gasoline with an octane rating of 87 AKI or higher may be tempo-
rarily used. For optimum engine performance and
driveability, it is recommended that you use pre-
mium grade unleaded gasoline.
Fuel octane rating
This octane rating is the average of the ResearchOctane and Motor Octane numbers and is com-
monly referred to as the Anti Knock Index (AKI).Using a gasoline with a lower octane rating cancause persistent and heavy knocking, which can
damage the engine. Do not be concerned if your
vehicle sometimes knocks lightly when you drive up a hill or when you accelerate. See your dealer or a
qualified service technician if you use a fuel with thespecified octane rating and your vehicle knocks
heavily or persistently.
Unleaded gasoline
The neck of the fuel filler pipe is designed to acceptonly an unleaded gasoline filler nozzle. Under no
circumstances should leaded gasoline be used be-
cause it will damage the emission control system
and may impair driveability and fuel economy.
Gasoline for California-certified LEV
Your vehicle was certified to California ’s low emis-
sion vehicle (LEV) standards as indicated on the
underhood tune-up label. It is designed to optimize
engine and emission performance with gasoline that
meets the clean burning low-sulfur California gaso-
line specifications. If you live in any other state than
California, your vehicle will operate on gasoline

Starting and operating
7-17
– CONTINUED –
3 (Third)
This position is for using engine braking when going down a hill or for climbing a grade.The transmission automatically shifts into a suitable
gear from 1st to 3rd according to the vehicle speed
and the acceleration you require.
When more acceleration is required in this position,
press the accelerator pedal fully to the floor and hold that position. The transmission will automatical-
ly downshift to 2nd or 1st gear. When you release
the pedal, the transmission will return to the originalgear position.
2 (Second)
This position is for using engine braking when goingdown a hill or for climbing a steep grade.In this position, the transmission holds in the 2nd
gear.
Use this position when starting off from a standstill
on slippery road surfaces such as mud or snow. It
will ensure greater traction.
1 (First)
This position is for driving up or down very steep
grades, or driving through mud or sand, or on slip-
pery surfaces. In this position, the transmission
holds in the 1st gear.
Maximum speeds
The following tables show the maximum speeds that
are possible with each different gear. The tachome-ter’ s needle will enter the red area if these speeds
are exceeded.
When shifting down a gear, it is important to confirm
that the current vehicle speed is not in excess of the
Maximum Allowable Speed of the gear which is
about to be selected.Exceeding the Maximum Allowable Speeds will
result in over-revving of the engine. In addition a
powerful engine brake will engage and control of the vehicle may be lost. mph (km/h)
2.5 liter models2.0 liter turbo
RSTS, OUTBACKSPORTmodelsWRX
129 (47)35 (56)40 (65)
258 (93)64 (103)73 (118)
NOTE In order to prevent over-revving during accel-
eration of the vehicle, the transmission will auto-
matically shift to the next highest gear if the Max-

8
8-1
– CONTINUED –
New vehicle break-in driving –
the first 1,000 miles (1,600 km) 8-2 . . . . . . . . . . . . . . .
Fuel economy hints 8-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust gas (Carbon monoxide) 8-3 . . . .
Catalytic converter 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Periodic inspections 8-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving in foreign countries 8-6 . . . . . . . . . . . . . . . . . . . . .
Driving tips for AWD vehicles 8-6 . . . . . . . . . . . . . . . . . .
Off road driving 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
All AWD models except OUTBACK SPORT 8-8 . . .
OUTBACK SPORT 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Winter driving 8-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation during cold weather 8-10 . . . . . . . . . . . . . . . . .
Driving on snowy and icy roads 8-12 . . . . . . . . . . . . . . . .
Corrosion protection 8-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Snow tires 8-13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire chains 8-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rocking the vehicle 8-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading your vehicle 8-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle capacity weight 8-16 . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR and GAWR (Gross Vehicle Weight
Rating and Gross Axle Weight Rating) 8-17 . . . . . .
Roof rail and crossbar (if equipped) 8-18 . . . . . . . . . . .
Trailer hitch (if equipped) 8-23 . . . . . . . . . . . . . . . . . . . . . . . .
Connecting a trailer 8-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When you do not tow a trailer 8-26 . . . . . . . . . . . . . . . . . . .
Trailer towing 8-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Warranties and maintenance 8-27
. . . . . . . . . . . . . . . . . . . .
Maximum load limits 8-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer hitches 8-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting a trailer 8-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer towing tips 8-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving tips

In case of emergency
9-14
(1) Connect one jumper cable to the positive (+)
terminal on the discharged battery.
(2) Connect the other end of the jumper cable to
the positive (+) terminal of the booster battery.
(3) Connect one end of the other cable to thenegative (–) terminal of the booster battery.
(4) Connect the other end of the cable to the en-gine lifting bracket.
Make sure that the cables are not near any mov-
ing parts and that the cable clamps are not in
contact with any other metal.
5. Start the engine of the vehicle with the booster
battery and run it at moderate speed. Then start the
engine of the vehicle that has the discharged bat-
tery.
6. When finished, carefully disconnect the cables in
exactly the reverse order. Engine overheating
WARNING
Never attempt to remove the radiator cap until the engine has been shut off and has fullycooled down. When the engine is hot, thecoolant is under pressure. Removing the cap
while the engine is still hot could release aspray of boiling hot coolant, which could burn
you very seriously.
If the engine overheats, safely pull off the road and stop the vehicle in a safe place. If steam is coming from the engine compartment
Turn the engine off and get everyone away from the
vehicle until it cools down. If no steam is coming from the engine compartment
1. Keep the engine running at idling speed.
2. Open the hood to ventilate the engine compart-ment.
