2002 SUBARU IMPREZA WRX brake fluid

Maintenance and service
11-30
If the fluid level is extreme low, it may indicate pos-
sible leakage. Consult your SUBARU dealer for in-spection.
WARNING
Be careful not to burn yourself because the fluid may be hot.
CAUTION
When power steering fluid is being added,
use only clean fluid, and be careful not to al- low any dirt into the tank. And never use dif-
ferent brands together. Avoid spilling fluid when adding it in the
tank.
Recommended fluid
“ Dexron III ” Type Automatic Transmission Fluid
Brake fluid Checking the fluid level
Check the fluid level monthly.
HGB001GB
1) “MAX” level mark
2) “MIN” level mark
Check the fluid level on the outside of the reservoir. If the level is below “MIN”, add the recommended
brake fluid to “MAX”.
Use only brake fluid from a sealed container.

Maintenance and service
11-31
– CONTINUED –
WARNING
Brake fluid absorbs moisture from the air.
Any absorbed moisture can cause a danger- ous loss of braking performance. If the vehicle requires frequent refilling,
there may be a leak. If you suspect a problem,
have the vehicle checked at your SUBARU
dealer.
CAUTION
Never use different brands of brake fluid to-
gether. When adding brake fluid, be careful not to
allow any dirt into the reservoir. Never splash the brake fluid over painted
surfaces or rubber parts. Alcohol contained inthe brake fluid may damage them.
Recommended brake fluid
FMVSS No. 116, fresh DOT 3 or 4 brake fluid
Clutch fluid (MT vehicles) Checking the fluid level
HGB001HB
1) “MAX” level mark
2) “MIN” level mark

Maintenance and service
11-32
HGB001KB
1) “MAX” level mark
2) “MIN” level mark
Check the fluid level on the outside of the reservoir. If
the level is below “MIN ” level mark, add the recom-
mended clutch fluid to “MAX ” level mark.
Use only clutch fluid from a sealed container.
CAUTION
Clutch fluid absorbs moisture from the air.
Any absorbed moisture can cause improper clutch operation. If the vehicle requires frequent refilling,
there may be a leak. If you suspect a problem,
have the vehicle checked at your SUBARU dealer.
Never use different brands of clutch fluid to-
gether. When clutch fluid is added, be careful not to
allow any dirt into the tank.
Recommended clutch fluid
FMVSS No. 116, fresh DOT 3 or 4 brake fluid

Index
14-2
A
ABS (Anti-lock Brake System) 7-22. . . . . . . . . . . . . . . . . . . .
ABS system self-check 7-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ABS warning light 3-12, 7-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ACC 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessory power socket 6-7 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air cleaner element 11-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioner compressor shut-off when
engine is heavily loaded 4-11 . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioner operation 4-8 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air filtration system (if equipped) 4-12 . . . . . . . . . . . . . . . . .
Air flow selection 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
All AWD models except OUTBACK SPORT 8-8 . . .
Aluminum wheels (If equipped) 11-45 . . . . . . . . . . . . . . . . . .
Antenna system 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Arming the system 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Armrest (if equipped) 1-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtray 6-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AT OIL TEMPerature warning light (for AT vehicles) 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio set 5-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic/Emergency Locking Retractor (A/ELR) 1-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission 7-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission fluid 11-24 . . . . . . . . . . . . . . . . . . . . . . B
Battery
11-50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake booster 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake fluid 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pedal 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system 7-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 3-13 . . . . . . . . . . . . . . . . . . . . . . . .
Braking 7-21
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking tips 7-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Breaking-in of new brake pads and linings 11-36 . . .
Built in CD changer operation 5-22 . . . . . . . . . . . . . . . . . . . .
Bulb chart 12-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CCapacities 12-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo anchorage eyelets (if equipped) 6-14 . . . . . . . .
Cassette player operation 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . .
Catalytic converter 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD changer control (If optional in-dash CD
changer is connected) 5-10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Center and side ventilators 4-3 . . . . . . . . . . . . . . . . . . . . . . . .
Center console 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center visor 6-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a flat tire 9-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the oil and oil filter 11-10 . . . . . . . . . . . . . . . . . . . . . .
Charge warning light 3-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Index
14-3
CHECK ENGINE warning light/ Malfunction indicator lamp 3-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking air conditioning system before summer season 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the brake pedal free play 11-33 . . . . . . . . . . . . .
Checking the brake pedal reserve distance 11-34 . .
Checking the clutch function 11-34 . . . . . . . . . . . . . . . . . . . . . .
Checking the clutch pedal free play 11-35 . . . . . . . . . . . .
Checking the fluid level 11-24, 11-29, . . . . . . . . . . . . . . . . . . .
11-30, 11-31
Checking the gear oil level 11-27 . . . . . . . . . . . . . . . . . . . . . . . .
Checking the oil level 11-9, 11-23, 11-26 . . . . . . . . . . . . . .
Child restraint systems 1-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child safety locks 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter (if equipped) 6-9 . . . . . . . . . . . . . . . . . . . .
Cigarette lighter socket (if equipped) 6-9 . . . . . . . . . . .
Cleaning aluminum wheels 10-3 . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning the interior 10-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning ventilator grille 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Climate control system 4-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock 3-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch fluid (MT vehicles) 11-31 . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch pedal (MT vehicles) 11-34 . . . . . . . . . . . . . . . . . . . . . . . .
Compact disc player operation 5-8 . . . . . . . . . . . . . . . . . . .
Connecting a trailer 8-24, 8-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control panel 4-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cooling and dehumidifying in high humidity and
low temperature weather condition 4-11 . . . . . . . . . .
Cooling system 11-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Corrosion protection 8-13, 10-4 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise control (if equipped) 7-27 . . . . . . . . . . . . . . . . . . . . . . .
Cup holder 6-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D
Daytime running light system 3-17 . . . . . . . . . . . . . . . . . . . . .
Dimensions 12-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disarming the system 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disc brake pad wear warning indicators 7-22 . . . . . . .
Dome light 6-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door locks 2-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door open warning lights 3-13 . . . . . . . . . . . . . . . . . . . . . . . . . .
Drive belts 11-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving in foreign countries 8-6 . . . . . . . . . . . . . . . . . . . . . . . .
Driving on snowy and icy roads 8-12 . . . . . . . . . . . . . . . . . .
Driving tips 7-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving tips for AWD vehicles 8-6 . . . . . . . . . . . . . . . . . . . . .
E
Efficient cooling after parking in direct sunlight 4-10 Electrical power socket located on the lower part of the instrument panel 6-8 . . . . . . . . . . . . . . . . . . .
Electrical system 12-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency Locking Retractor (ELR) 1-12 . . . . . . . . . . . .

Index
14-6
Meters and gauges 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mirrors 3-25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Most common causes of corrosion 10-4 . . . . . . . . . . . . . .
N
New vehicle break-in driving –
the first 1,000 miles (1,600 km) 8-2 . . . . . . . . . . . . . . .
O
Odometer/Trip meter 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Off road driving 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil pressure warning light 3-11 . . . . . . . . . . . . . . . . . . . . . . . . . .
ON 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating tips for heater and air conditioner 4-10 .
Operation during cold weather 8-10 . . . . . . . . . . . . . . . . . . .
OUTBACK SPORT 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside mirrors 3-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside temperature indicator (if equipped) 3-9 . .
P
Parking brake stroke 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking light switch 3-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking your vehicle 7-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Passive arming 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Periodic inspections 8-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power door locking switches (if equipped) 2-5 . . . . Power steering 7-20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power steering fluid 11-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power windows 2-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions against vehicle modification 1-27, 1-61 .
Precautions to observe when handling a compact disc (CD) 5-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preparing to drive 7-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
R
Radio operation 5-4, 5-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear combination lights 11-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear differential gear oil 11-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear gate (Wagon) 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seats 1-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear viscous limited slip differential (LSD)
(if equipped) 7-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window defogger switch 3-24 . . . . . . . . . . . . . . . . . . . .
Rear window wiper and washer switch
(if equipped) 3-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reclining the seatback 1-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended brake fluid 11-31 . . . . . . . . . . . . . . . . . . . . . . . .
Recommended clutch fluid 11-32 . . . . . . . . . . . . . . . . . . . . . . . .
Recommended fluid 11-25, 11-30 . . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-11, 11-24, . .
11-26, 11-28
Recommended grade and viscosity under severe driving conditions 11-13 . . . . . . . . . . . . . .
