2002 SUBARU IMPREZA WRX mirror

Interior equipment
6-4
Center visor
HG6002BA
To block out glare, swing down the visor.
Vanity mirror (if equipped)
HB0137
To use the vanity mirror, swing down the sun visor
and open the vanity mirror cover.

Starting and operating
7-7
– CONTINUED –
CAUTION
Resultant vehicle damage due to improper testing is not covered under the SUBARU Lim-
ited Warranty and is the responsibility of the state inspection program or its contractors orlicensees. Preparing to drive
You should perform the following checks and adjust-
ments every day before you start driving.
1. Check that all windows, mirrors, and lights are
clean and unobstructed.
2. Check the appearance and condition of the tires.
Also check tires for proper inflation.
3. Look under the vehicle for any sign of the leaks.
4. Check that the hood, trunk and rear gate are fullyclosed.
5. Check the adjustment of the seat.
6. Check the adjustment of the inside and outside
mirrors.
7. Fasten your seatbelt. Check that your passen-gers have fastened their seatbelts.
8. Check the operation of the warning and indicator
lights when the ignition switch is turned to the
“ON”
position.
9. Check the gauges, indicator and warning lights
after starting the engine. NOTE Engine oil, engine coolant, brake fluid, washer
fluid and other fluid levels should be checked
daily, weekly or at fuel stops.

Driving tips
8-34
Side mirrors
HB0085
After hitching a trailer to your vehicle, check that the
standard side mirrors provide a good rearward field of view without significant blind spots. If significant blind spots occur with the vehicle ’s standard side
mirrors, use towing mirrors that conform with Fed-
eral, state/province and/or other applicable regula-tions.
Trailer lights
Connection of trailer lights to your vehicle ’s electrical
system requires modifications to the vehicle ’s light-
ing circuit to increase its capacity and accommo-
date wiring changes. To ensure the trailer lights are
connected properly, please consult your SUBARU dealer. Check for proper operation of the turn sig-nals, the brake lights and parking lights each timeyou hitch up.
CAUTION
Direct splicing or other improper connection
of trailer lights may damage your vehicle
’s
electrical system and cause a malfunction of your vehicle ’s lighting system.
Tires
Make sure that all the tires on your vehicle are prop-
erly inflated to the pressure specified on the tire
placard located on the left center pillar of your ve-hicle.
Trailer tire condition, size, load rating and proper
inflation pressure should be in accordance with the
trailer manufacturer ’s specifications.
In the event your vehicle gets a flat tire when towing
a trailer, ask a commercial road service to repair the
flat tire.
If you carry a regular size spare tire in your vehicle
or trailer as a precaution against getting a flat tire,
be sure that the spare tire is firmly secured.

Driving tips
8-35
– CONTINUED –
WARNING
Never tow a trailer when the temporary spare tire is used. The temporary spare tire is not
designed to sustain the towing load. Use ofthe temporary spare tire when towing can result in failure of the spare tire and/or less
stability of the vehicle.
Trailer towing tips
CAUTION
Never exceed 45 mph (72 km/h) when tow-
ing a trailer in hilly country on hot days. When towing a trailer, steering, stability,
stopping distance and braking performancewill be different from normal operation. For
safety’ s sake, you should employ extra cau-
tion when towing a trailer and you should
never speed. You should also keep the follow-ing tips in mind:
Before starting out on a trip
Check that the vehicle and vehicle-to-hitch mount-
ing are in good condition. If any problems are apparent, do not tow the trailer.
Check that the vehicle sits horizontally with the
trailer attached. If the vehicle is tipped sharply up at
the front and down at the rear, check the total trailer
weight, GVW, GAWs and tongue load again, then
confirm that the load and its distribution are accept- able. Check that the tire pressures are correct.
Check that the vehicle and trailer are connected
properly. Confirm that. –the trailer tongue is connected properly to the
hitch ball. – the trailer lights connector is connected prop-
erly and trailer ’s brake lights illuminate when the
vehicle’ s brake pedal is pressed, and that the trail-
er’ s turn signal lights flash when the vehicle ’s turn
signal lever is operated. – the safety chains are connected properly.
– all cargo in the trailer is secured safety in posi-
tion.– the side mirrors provide a good rearward field of
view without a significant blind spot.
Sufficient time should be taken to learn the “feel”
of the vehicle/trailer combination before starting out
on a trip. In an area free of traffic, practice turning, stopping and backing up.

Specifications
12-6
Fuses and circuits Fuse panel located behind the coin tray
HS0224
Fuse panelFuse ratingCircuit
115AHeater fan
215AHeater fan
315APower door lock
Keyless entry
420ACigarette lighter
Remote controlled rear view mirrors
510ATail light
Parking light
615ASRS airbag
715AFog light
820AABS solenoid
915ARadio
10Empty
1115AEngine ignition sys- tem
SRS airbag
AT control system

Specifications
12-7
– CONTINUED –
Fuse panelFuse ratingCircuit
1210AIllumination bright- ness control
1310ACombination meter
SRS lamp
1410ARear window wiper and washer
1530AWindshield wiper and washer
1620ABrake light
1715AAir conditioner
1815ABackup light
Cruise control
1920AMirror heater

Index
14-5
I
If no steam is coming from the engine compartment 9-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If steam is coming from the engine compartment 9-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you park your vehicle in case of an
emergency 9-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illuminated entry 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illumination brightness control 3-18 . . . . . . . . . . . . . . . . . . . .
In center console (if equipped) 6-6 . . . . . . . . . . . . . . . . . . .
In instrument panel 6-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside mirror 3-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of accessories 5-2, 11-54 . . . . . . . . . . . . . . . . . . .
Installation of child restraint systems by use of lower and tether anchorages 1-32 . . . . . . . . . . . . . . . . . .
Installing child restraint systems with seatbelt 1-31 Interior light 6-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In the luggage compartment (if equipped) 6-7 . . . .
J
Jack and jack handle 9-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump starting 9-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
K
Key interlock release (AT vehicles only) 3-4 . . . . . . . . Keyless entry system (if equipped) 2-6
. . . . . . . . . . . . .
Key number 2-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key reminder chime 3-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keys 2-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
L
Leather seat materials 10-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
License plate light 11-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light control switch 3-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading your vehicle 8-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LOCK 3-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Locking and unlocking from the inside 2-4 . . . . . . . . .
Locking and unlocking from the outside 2-3 . . . . . . .
Locking the doors 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication oil circulation in the refrigerant
circuit 4-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage area light (if equipped) 6-2 . . . . . . . . . . . . . . . . .
Luggage cover (if equipped) 6-12 . . . . . . . . . . . . . . . . . . . . .
M
Main fuse 11-53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance precautions 11-3 . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance schedule 11-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance tools 9-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission 7-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission oil 11-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum load limits 8-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Index
14-6
Meters and gauges 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mirrors 3-25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Most common causes of corrosion 10-4 . . . . . . . . . . . . . .
N
New vehicle break-in driving –
the first 1,000 miles (1,600 km) 8-2 . . . . . . . . . . . . . . .
O
Odometer/Trip meter 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Off road driving 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil pressure warning light 3-11 . . . . . . . . . . . . . . . . . . . . . . . . . .
ON 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating tips for heater and air conditioner 4-10 .
Operation during cold weather 8-10 . . . . . . . . . . . . . . . . . . .
OUTBACK SPORT 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside mirrors 3-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside temperature indicator (if equipped) 3-9 . .
P
Parking brake stroke 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking light switch 3-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking your vehicle 7-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Passive arming 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Periodic inspections 8-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power door locking switches (if equipped) 2-5 . . . . Power steering 7-20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power steering fluid 11-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power windows 2-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions against vehicle modification 1-27, 1-61 .
Precautions to observe when handling a compact disc (CD) 5-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preparing to drive 7-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
R
Radio operation 5-4, 5-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear combination lights 11-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear differential gear oil 11-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear gate (Wagon) 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seats 1-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear viscous limited slip differential (LSD)
(if equipped) 7-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window defogger switch 3-24 . . . . . . . . . . . . . . . . . . . .
Rear window wiper and washer switch
(if equipped) 3-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reclining the seatback 1-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended brake fluid 11-31 . . . . . . . . . . . . . . . . . . . . . . . .
Recommended clutch fluid 11-32 . . . . . . . . . . . . . . . . . . . . . . . .
Recommended fluid 11-25, 11-30 . . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-11, 11-24, . .
11-26, 11-28
Recommended grade and viscosity under severe driving conditions 11-13 . . . . . . . . . . . . . .
