2002 PONTIAC BONNEVILLE engine

2-98
Fuel Range: Press the SELECT button until the display
shows FUEL RANGE. The fuel range will calculate the
remaining distance you can drive without refueling. This
calculation is based on the average fuel economy for the
last 25 miles (40.25 km) driven, and the fuel remaining
in the fuel tank. If the fuel range drops below 40 miles
(64.4 km), the display will show FUEL RANGE LOW.
The RESET button does not function in this mode.
Fuel Used: Press the SELECT button until the display
shows FUEL USED. The value indicates how much fuel
has been used since the last reset. Don't confuse fuel
used with the amount of fuel in your tank. To learn how
much fuel will be used from a specific starting point,
press the RESET button for five seconds while the fuel
used is displayed on the DIC.
Battery Volts: On vehicles with a supercharged engine,
press the SELECT button until the display shows
BATTERY VOLTS. If the voltage is normal the display
will show BATTERY ## VOLTS. If the voltage drops
below 10.5 volts for 30 seconds, the battery volts
display will show BATTERY LOW. If the voltage is
above 16.2 volts for 30 seconds, the battery volts display
will show BATTERY HIGH. If the display shows the
high or low message, you need to have your battery
and/or electrical system checked.GM Oil Life System
: Press the SELECT button until
OIL LIFE appears in the display. The OIL LIFE
NORMAL display will show an estimate of the oil's
remaining useful life. When the oil life index is less than
10%, an ENGINE OIL CHANGE SOON message will
be displayed and the oil life display will show OIL LIFE
CHANGE. When you have the oil changed according to
the maintenance schedule, you will have to reset the Oil
Life System. To reset the Oil Life System, see ªOil Life
Systemº in the Index. Also, see ªEngine Oil, When to
Changeº and ªMaintenance Scheduleº in the Index.
Tire Pressure Status: Press the SELECT button until
TIRE PRESSURE appears in the display. TIRE
PRESSURE NORMAL is displayed when the Check
Tire Pressure System believes your vehicle's tire
pressures are normal. If a potential problem is detected,
the display will show CHECK TIRE PRESSURE and
the tire pressure status will show TIRE PRESSURE
LOW. If you see the CHECK TIRE PRESSURE
message, you should stop as soon as you can and check
all your tires for damage. (If a tire is flat, see ªIf a Tire
Goes Flatº in the Index.) Also check the tire pressure in
all four tires as soon as you can. See ªInflation
-- Tire
Pressureº and ªCheck Tire Pressure Systemº in
the Index.

2-99 DIC Warnings and Messages
Other messages or warnings may appear in the DIC
display. For Canadian drivers, in addition to the DIC
message your DIC will display EXP with a number after
it which reflects the following messages:
EXP (Export ID) Warning Message. . . . . . . . . . . .
3 SERVICE VEHICLE SOON. . . . . . . . . . . . . . . . .
9 CHECK GAGES VOLT. . . . . . . . . . . . . . . . . . . . .
11 CHECK GAGES LOW FUEL. . . . . . . . . . . . . . .
16 ENGINE HOT A/C DISABLED. . . . . . . . . . . . .
20 TURN SIGNAL ON?. . . . . . . . . . . . . . . . . . . . . .
24 TRUNK AJAR. . . . . . . . . . . . . . . . . . . . . . . . . . .
25 WASHER FLUID LOW. . . . . . . . . . . . . . . . . . . .
27 BATTERY SAVER ACTIVE. . . . . . . . . . . . . . . .
33 STARTING DISABLED
- THEFT * . . . . . . . . . .
34 SERVICE THEFT SYSTEM. . . . . . . . . . . . . . . .
35 CHECK GAGES OIL PRESSURE *. . . . . . . . . .
36 OIL LEVEL LOW. . . . . . . . . . . . . . . . . . . . . . . .
37 BRAKE FLUID LOW *. . . . . . . . . . . . . . . . . . . .
40 ALARM OCCURRED. . . . . . . . . . . . . . . . . . . . .
44 CHECK GAGES TEMPERATURE *. . . . . . . . .
54 SERVICE STABILITY SYSTEM. . . . . . . . . . . .
55 STABILITY SYSTEM ACTIVE. . . . . . . . . . . . .
61 CHECK GAS CAP. . . . . . . . . . . . . . . . . . . . . . . . EXP (Export ID) Warning Message. . . . . . . . . . . .
81 ENGINE OIL CHANGE SOON. . . . . . . . . . . . .
83 SERVICE AIR BAG. . . . . . . . . . . . . . . . . . . . . . .
102 CHECK CHARGE SYSTEM. . . . . . . . . . . . . . .
140 DRIVER DOOR AJAR. . . . . . . . . . . . . . . . . . .
141 FRONT PASSENGER DOOR AJAR. . . . . . . .
142 LEFT REAR DOOR AJAR. . . . . . . . . . . . . . . .
143 RIGHT REAR DOOR AJAR. . . . . . . . . . . . . . .
144 CHECK TIRE PRESSURE. . . . . . . . . . . . . . . .
147 PARK BRAKE SET *. . . . . . . . . . . . . . . . . . . .
The EXP codes are used to make translation from
English to other languages easier.
Pressing any of the DIC control buttons will remove the
above messages or warnings from the DIC display,
unless noted by an asterisk (*).
SERVICE STABILITY SYSTEM
- 54: If you ever
see the SERVICE STABILITY SYSTEM message,
it means there may be a problem with your stability
enhancement system. If you see this message, try to
reset the system (stop; turn off the engine; then start the
engine again). If the SERVICE STABILITY SYSTEM
message still comes on, it means there is a problem.
You should see your dealer for service. Reduce your
speed and drive accordingly.

2-110
When the ignition key is turned to ON, all possible
HUD images will come on, then the HUD will
operate normally.
If you never look at your instrument panel cluster, you
may not see something important, such as a warning
light. So be sure to scan your displays and controls and
the driving environment just as you would in a vehicle
without HUD.
NOTICE:
Although the HUD image appears to be near
the front of the vehicle, do not use it as a parking
aid. The HUD was not designed for that purpose.
If you try to use it that way, such as in a parking
lot, you may misjudge distance and run
into something.
The HUD controls are located to the left of the
steering column.
1. Start your engine and turn the HUD INTENSITY
knob all of the way clockwise to MAX (Maximum).
The brightness of the HUD image is determined by
ambient light, and where you have set the HUD
INTENSITY knob.

3-7
Be sure not to cover the sensor located on the top of the
instrument panel near the windshield. This sensor
regulates interior temperatures based on sun load.
To avoid blowing cold air through the system in cold
weather, the automatic system will delay turning on the
fan until warm air is available. The length of delay
depends on engine coolant temperature. Pressing the fan
button will override this delay and cancel the automatic
mode, returning the system to manual mode.
The EXT (exterior) temperature sensor is located in the
front of the vehicle behind the grill. The EXT temperature
displayed may not be accurate for a few minutes if you
have restarted the engine after it was already warmed.
Air Conditioning
On hot days, open the windows long enough to let hot
air inside the vehicle escape. This reduces the time it
takes for your vehicle to cool down. Then keep your
windows closed for the air conditioner to work its best.
If you have the standard system, for quick cool
-down on
very hot days, use the airflow from the instrument panel
outlets, press RECIRC and A/C with the temperature knob in
the blue area. If this maximum A/C setting is used for long
periods of time, the air in your vehicle may become too cold
and dry. For normal cooling on hot days, use A/C without
recirculation with the temperature knob in the blue area.If you have the electronic system, in AUTO mode
the system will cool and dehumidify the air inside
the vehicle. Also while in AUTO mode, the system
will maximize its performance by using recirculation
as necessary.
On cool, but sunny days, with the standard system or
through manual operation of the electronic system, use
bi
-level to deliver warm air to the floor and cooler air to
the instrument panel outlets. To warm or cool the air
delivered, turn the temperature knobs.
Heating
If you have the standard system, on cold days use the
floor ducts with the temperature knob in the red area. If
you have the electronic system, press AUTO and adjust
the temperature by turning the temperature knob up or
down. You may also adjust the electronic system
manually by pressing the MODE button and selecting
FLOOR. Again, adjust the temperature by turning the
temperature knobs.
With either system, outside air will be heated and sent
through the floor ducts. The heater works best if you
keep your windows closed while using it.

3-11 Comfort Controls Personalization
(If Equipped)
This feature enables up to two drivers to store and recall
comfort control settings for the temperature, fan speed
and the direction of the airflow.
The memory buttons (1 or 2) for this feature are located
on the driver's door panel and correspond to the
numbers (1 or 2) found on the back of each remote
keyless entry transmitter.
To recall comfort settings, press the unlock button on
the remote keyless entry transmitter before entering
your vehicle.
If you enter your vehicle without using the remote
keyless entry, the settings for the last identified driver
will be recalled when you put the ignition in
ACCESSORY or RUN.
To program a personal choice climate control setting,
do the following:
1. Choose a temperature setting for the driver and if
desired, for the passenger. See ªElectronic Climate
Control System (Option)º earlier in this section.
2. Adjust the fan speed and the direction of the airflow.3. Locate the memory buttons on the driver's
door panel.
4. Press a memory button (1 or 2) until you hear two
beeps. The beeps confirm that your selection has
been saved and can now be recalled.
Follow these steps each time you want to change the
stored settings.
For more information on the memory feature, see
ªMemory Seat and Mirrorsº in the Index.
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all of its controls to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is turned off. See
ªRetained Accessory Power (RAP)º in the Index.

3-46
NOTICE:
Before you add any sound equipment to your
vehicle
-- like a tape player, CB radio, mobile
telephone or two
-way radio -- be sure you can
add what you want. If you can, it's very
important to do it properly. Added sound
equipment may interfere with the operation of
your vehicle's engine, Delphi Electronics radio or
other systems, and even damage them. Your
vehicle's systems may interfere with the
operation of sound equipment that has been
added improperly.
So, before adding sound equipment, check with
your dealer and be sure to check federal rules
covering mobile radio and telephone units.
Care of Your Cassette Tape Player
A tape player that is not cleaned regularly can cause
reduced sound quality, ruined cassettes or a damaged
mechanism. Cassette tapes should be stored in their
cases away from contaminants, direct sunlight and
extreme heat. If they aren't, they may not operate
properly or may cause failure of the tape player.
Your tape player should be cleaned regularly after every
50 hours of use. Your radio may display CLEAN
PLAYER to indicate that you have used your tape player
for 50 hours without resetting the tape clean timer. If
this message appears on the display, your cassette tape
player needs to be cleaned. It will still play tapes, but
you should clean it as soon as possible to prevent
damage to your tapes and player. If you notice a
reduction in sound quality, try a known good cassette to
see if it is the tape or the tape player at fault. If this other
cassette has no improvement in sound quality, clean the
tape player.
The recommended cleaning method for your cassette
tape player is the use of a scrubbing action,
non
-abrasive cleaning cassette with pads which scrub
the tape head as the hubs of the cleaner cassette turn.
The recommended cleaning cassette is available through
your dealer (GM Part No. 12344789).

4-7
Avoid needless heavy braking. Some people drive in
spurts
-- heavy acceleration followed by heavy
braking
-- rather than keeping pace with traffic. This is a
mistake. Your brakes may not have time to cool between
hard stops. Your brakes will wear out much faster if you
do a lot of heavy braking. If you keep pace with the
traffic and allow realistic following distances, you will
eliminate a lot of unnecessary braking. That means
better braking and longer brake life.
If your engine ever stops while you're driving, brake
normally but don't pump your brakes. If you do, the
pedal may get harder to push down. If your engine
stops, you will still have some power brake assist. But
you will use it when you brake. Once the power assist is
used up, it may take longer to stop and the brake pedal
will be harder to push.
Anti-Lock Brake System (ABS)
Your vehicle has anti-lock brakes. ABS is an advanced
electronic braking system that will help prevent a
braking skid.
When you start your engine, or when you begin to drive
away, your anti
-lock brake system will check itself. You
may hear a momentary motor or clicking noise while
this test is going on, and you may even notice that your
brake pedal moves or pulses a little. This is normal.
United States Canada
If there's a problem with the anti
-lock brake system,
this warning light will stay on. See ªAnti
-Lock Brake
System Warning Lightº in the Index.

4-9
Remember: Anti-lock doesn't change the time you need
to get your foot up to the brake pedal or always decrease
stopping distance. If you get too close to the vehicle in
front of you, you won't have time to apply your brakes
if that vehicle suddenly slows or stops. Always leave
enough room up ahead to stop, even though you have
anti
-lock brakes.
Using Anti
-Lock
Don't pump the brakes. Just hold the brake pedal down
firmly and let anti
-lock work for you. You may feel a
slight brake pedal pulsation or notice some noise, but
this is normal.
Braking in Emergencies
With anti-lock, you can steer and brake at the same
time. In many emergencies, steering can help you more
than even the very best braking.
Traction Control System
(If Equipped)
Your vehicle may have a traction control system that
limits wheel spin. This is especially useful in slippery
road conditions. The system operates only if it senses
that one or both of the front wheels are spinning or
beginning to lose traction. When this happens, the
system works the front brakes and reduces engine power
to limit wheel spin.
You may feel or hear the system working, but this
is normal.
If your vehicle is in cruise control when the traction
control system begins to limit wheel spin, the cruise
control will automatically disengage. When road
conditions allow you to safely use it again, you may
reengage the cruise control. See ªCruise Controlº in
the Index.
This light should come on
briefly when you start the
engine. If it stays on or
comes on while you are
driving, there's a problem
with your traction
control system.
