10 -Passenger air bag.
11 - Glove box.
12 - Side adjustable heating/ ventilation vent and air flowregulation.
13 - Window demisting vent.
14 - Speaker (tweeter) location.
15 - Multi-function display.
16 - Heating/ventilation controls.
17 - Radio.
18 - Gear lever.
19 - Front ashtray.
20 - Rear footwell heating vent.
21 - Lighter. 22 -
Heated seat switches. Coin storage.Passenger air bag disarming switch.
23 - Handbrake.
24 - Cup-holder.
25 - Rear ashtray.
26 - Steering lock and ignition.
27
-Steering wheel adjustment.
28 - Fuse box.
29 - Electronic Stability Program- me (ASR/ESP) switch.
30 - Headlamp height adjustment.
31 - Cruise control
YOUR 406 AT A GLANCE
3
1 - Electric mirror controls. Window controls.Rear window locking control.
2 - Lights and direction indicators stalk. Arming/disarming of automatic switching on of lights.
3 - Driver's air bag. Horn.
4 - Instrument dials.
5 - Radio remote control stalk.
6 - Windscreen wash-wipe stalk.
Trip computer stalk.
7 - Hazard warning lights switch.
8 - Central adjustable heating/ ventilation vents and air flowregulation.
9 - Windscreen demistingvents.

MAINTENANCE OF YOUR 406
23
∀All driving conditions.o Arduous conditions.
A AND C SERVICES AND THE INTERMEDIATE VISIT
- Oil filter∀∀- Fuel filter (Petrol only)∀- Fuel filter element (Diesel only)∀- Air filter element∀- Spark plugs (Petrol only)HPI∀
- Operation of lights and indicators∀∀∀- Condition of glass, headlamp & light lenses and mirrors∀∀- Horn∀∀- Windscreen washer jets∀∀- Condition of wiper blades∀∀- Condition and tension of the ancillary drive belts∀∀- Handbrake∀∀- Condition of hydraulic circuits (hoses and covers)∀∀- Condition of rubber boots and gaiters∀∀∀- Brake pads∀∀
o- Play in hubs, link rods, ball joints, flexible mountings∀- Shock absorbers∀- Rear drum brake lining wear∀- Condition and pressure of tyres (including spare wheel)∀∀∀- Emission control check (Petrol only)∀∀∀- Smoke opacity (Diesel only)∀∀- Pollen filter (according to specification)∀∀o- Visual check of the whole vehicle∀∀
DRAIN and
REFILL
REPLACE
CHECK
∀∀
ROAD TEST
- Courtesy vehicle∀
SERVICE
Level
Operation Description of Operation First Service
A C Intermediate
- Engine oil∀∀- Bleed fuel filter (Diesel only)∀∀∀
- Engine oil (check + top-up)∀∀- Gearbox level (check + top-up)∀∀- Battery level (check + top-up) if cap is removable∀∀- Front/rear screen wash level (check + top-up)∀∀∀∀- Coolant level (check + top-up)∀∀∀∀- Brake fluid level (check + top-up)∀∀∀- Power steering fluid level (check + top-up, according to specification)∀∀∀

Horn Press one of the spokes or the centre of the steeringwheel.
Adjusting the headlamps Depending on the load in your vehi- cle, adjusting the beam of the head-lamps is recommended as follows.0- 1 or 2 people in the front seats.
–- 3 people.
1- 5 people.
2- 5 people + maximum authorised load.
3- Driver + maximum authorised load.
Initial setting is position 0. Hazard warning lights Press the button, the direction indi- cators flash. They can operate with the ignition
off.
Steering wheel height and depth adjustment
When the vehicle is stationary, unlock the steering wheel by pullinghandle
A.
Adjust the height and depth of thesteering wheel, then lock it by push-ing handle Adown fully.
YOUR 406 IN DETAIL
144
Automatic lighting of hazard warning lights*
When braking in an emergency, depending on the force of decelera-tion, the hazard warning lights come
on automatically. they switch of auto-matically the first time you accelerate.
However, it is also possible to switch
them off by pressing the button.
* According to country.

Fuse N° RatingFunctions
11* 10ALeft–hand main beam.
12* 10 A Right–hand main beam.
13* 15 AHorn.
14 10 AFront and rear screen wash pump.
15* 30 A Ignition coil –Windscreen wiper - Oxygen sensor - Oil pressure – Injection system.
16 * 30AAir pump and oil temperature - Oil level - Brake lights function - Alternator – Water in diesel
detector – Injection relay control.
17 * 30APassenger's electric seat.
18 40A Heater blower- Starter – Windscreen wiper slow speed.
