SPECIAL FEATURES Some of your vehicle's vital components have specific servicing schedules. The air bags and the pretensioning seat beltsmust be replaced every 10 years.
The brake fluid must be replaced every 36/40,000 miles (60 000 km) or every 2 years.
The pollen filter must be checked at each visit to the PEUGEOT dealer (intermediate visits and regular services).
Replacement of the timing belt: consult your Peugeot dealer.
MAINTENANCE OF YOUR 406
19
Arduous conditions of use If the vehicle is used in certain particularly arduous conditions:

80,000 (120 000) 100,000 (150 000) 120,000 (180 000) 140,000 (210 000) 160,000 (240 000)
MILES (KM) 20,000 (30 000) 40,000 (60 000) 60,000 (90 000)
SERVICE LEVELS Each vehicle has its own servicing cycle, based upon the engine type.
The servicing cycle consists of alternating 2 types of service A and C, intermediate visits, and a few additional operations depending on your vehicle; these correspond to key stages in the life of your 406. Level B service is designed for less recent vehicles.When the first service is carried out and at each subsequent service, your dealer will advise you of the type and content of the next service due.
MAINTENANCE OF YOUR 406
20
Automatic gearbox oil level every 40,000 miles (60 000 km). Replacement of brake fluidevery 2 years or 40,000 miles (60 000 km).
These fixed operations are carried out with synthetic based oil; Fuel Economy oil or
synthetic oil may also be used.
Warning: do not use Fuel Economy oil in the 2.2 litre 16V petrol engine. Intermediate top-up visit
THE MAINTENANCE CYCLE FOR YOUR 406 PETROL
Petrol engine (except 24V V6 injection): service every 20,000 miles (30 000 km) or 2 years
1st service at 6,000
miles (10 000 km) or 6 months*.
This is necessary in
order to benefit from the warranty.
* Whichever comes first.

MAINTENANCE OF YOUR 406
21
80,000 (120 000) 100,000 (150 000) 120,000 (180 000) 140,000 (210 000) 160,000 (240 000)
MILES (KM) 20,000 (30 000) 40,000 (60 000) 60,000 (90 000)
Automatic gearbox oil level every 40,000 miles (60 000 km). Replacement of brake fluidevery 2 years or 40,000 miles (60 000 km).
These fixed operations are carried out with synthetic based oil; Fuel Economy oil or
synthetic oil may also be used. Intermediate top-up visit
THE MAINTENANCE CYCLE FOR YOUR 406 PETROL
24V V6 petrol injection engine: service every 20,000 miles (30 000 km) or 2 years
1st service at 6,000 miles
(10 000 km) or 6 months*. This is necessary
in order to benefit
from the warranty.
+ replacement of air filter
+ replacement of fuel filter
+ replacement of air filter
+ replacement of fuel filter
* Whichever comes first.

MAINTENANCE OF YOUR 406
22
Automatic gearbox oil every 2 years or 36,000 miles (60 000 km). Replacement of brake fluidevery 2 years or 36,000 miles (60 000 km).
These fixed operations are carried out with synthetic basedoil; Fuel Economy oil or
synthetic oil may also be used.
Warning: only use 5W 40 oil for 2.2 litre HDI engines. Intermediate top-up visit
MILES (KM) 12,000 (20 000) 24,000 (40 000) 36,000 (60 000) 48,000 (80 000)
60,000 (100 000) 72,000 (120 000) 84,000 (140 000) 96,000 (160 000) 108,000 (180 000)
THE MAINTENANCE CYCLE FOR YOUR 406 TURBO DIESEL HDI
Service every 12,000 miles (20 000 km) or 2 years
1st service at 6,000 miles
(10 000 km) or 6 months*. This is necessary
in order to benefit
from the warranty.
+ maintenance of particulate
emission filter
(except 2 litre HDI 90 bhp)
+ maintenance of particulate emission
filter (except 2 litre HDI 90 bhp)
* Whichever comes first.

MAINTENANCE OF YOUR 406
23
∀All driving conditions.o Arduous conditions.
A AND C SERVICES AND THE INTERMEDIATE VISIT
- Oil filter∀∀- Fuel filter (Petrol only)∀- Fuel filter element (Diesel only)∀- Air filter element∀- Spark plugs (Petrol only)HPI∀
- Operation of lights and indicators∀∀∀- Condition of glass, headlamp & light lenses and mirrors∀∀- Horn∀∀- Windscreen washer jets∀∀- Condition of wiper blades∀∀- Condition and tension of the ancillary drive belts∀∀- Handbrake∀∀- Condition of hydraulic circuits (hoses and covers)∀∀- Condition of rubber boots and gaiters∀∀∀- Brake pads∀∀
o- Play in hubs, link rods, ball joints, flexible mountings∀- Shock absorbers∀- Rear drum brake lining wear∀- Condition and pressure of tyres (including spare wheel)∀∀∀- Emission control check (Petrol only)∀∀∀- Smoke opacity (Diesel only)∀∀- Pollen filter (according to specification)∀∀o- Visual check of the whole vehicle∀∀
DRAIN and
REFILL
REPLACE
CHECK
∀∀
ROAD TEST
- Courtesy vehicle∀
SERVICE
Level
Operation Description of Operation First Service
A C Intermediate
- Engine oil∀∀- Bleed fuel filter (Diesel only)∀∀∀
- Engine oil (check + top-up)∀∀- Gearbox level (check + top-up)∀∀- Battery level (check + top-up) if cap is removable∀∀- Front/rear screen wash level (check + top-up)∀∀∀∀- Coolant level (check + top-up)∀∀∀∀- Brake fluid level (check + top-up)∀∀∀- Power steering fluid level (check + top-up, according to specification)∀∀∀

25
MAINTENANCE OF YOUR 406
Recommendations for approved lubricants The oils which appear in the table opposite are suitable for most pur-poses. The diagram opposite states the optimum range of viscosity depend-ing on the temperatures at which theoils are to be used. It is also possible to use synthetic oils of `superior quality'. In the absence of semi-synthetic or
synthetic oils, oils of API SH/SJ qual-ity (for petrol engines), or CD/CFquality (for diesel engines) may beused by following the 'Arduous Con-ditions' servicing schedule, whichspecifies shorter service intervals. Do not hesitate to ask for advice from a Peugeot dealer to maintaindriving pleasure and to minimise themaintenance cost of your vehicle. For countries outside Europe, please
contact a local PEUGEOT dealer.
ONLY ONLY
Manual Gearbox ESSO GEAR OIL BV TOTAL TRANSMISSION BV 75W-80W PR 9736.41 75W-80
Automatic ONLY
Gearbox ATF 4HP20–AL4
4HP20–AL4 PR 9736.22
Power steering ESSO ATF D TOTAL FLUIDE AT42 PR 9730.94
Power steering FLUIDE DA PR 9730. A1*
Brake fluid PEUGEOT DOT4
Coolant PROCOR TM108/GLYSANTIN G33 or REVKOGEL 2000ONLYProtection to minus 35 degrees Celsius
* Only for extremely cold countries. Other approved products

INSTRUMENT PANEL DIALS: PETROL / DIESEL1 - Fuel filler cap warning light.
2 - Door open warning ligt.
3 - Dipped beam headlamps indicator light.
4 - Main beam headlamps indicatorlight.
5 - Rev counter.
6 - Left-hand direction indicator.
7 - Central (STOP) warning light.
8 - Service indicator, oil level and
total distance recorder. 9 -
Right-hand direction indicator.
10 - Speedometer.
11 - Clogging of the particulate emission filter warning light(Diesel).
12 - Front fog lamps indicator light.
13 - Rear fog lamp indicator light.
14 - Dynamic stability control(ASR/ESP) indicator light(petrol versions only).
15 - Low coolant level warning light.
YOUR 406 IN DETAIL
127
16 -Coolant temperature indicator.
17 - Trip recorder zero reset.
18 - Hand-brake and low brake fluid level warning light.
19 - Seat belt not fastened warning light.
20 - Air bags warning light.
21 - ABS system warning light.
22 - Engine diagnostics warning light.
23 - Battery charge warning light.
24 - Diesel engine preheating indicator light.
25 - Passenger air bag disarming warning light.
26 - Water in diesel filter warning light.
27 - Front brake pad wear warning light.
28 - Engine oil pressure warning light.
29 - Electronic immobiliser warning light.
30 - Lighting rheostat.
31 - Fuel gauge.
32 - Low fuel level warning light.

1 -Fuel filler cap warning light.
2 - Door open warning light.
3 - Dipped beam headlamps indicator light.
4 - Main beam headlamps indicatorlight.
5 - Rev. counter.
6 - Left-hand direction indicator.
7 - Central (STOP) warning light.
8 - Low fuel level warning light.
9 - Fuel gauge. 10 -
Service indicator, oil level and
total distance recorder.
11 - Right-hand direction indicator.
12 - Speedometer.
13 - Clogging of the particulateemission filter warning light(Diesel).
14 - Front fog lamps indicator light.
15 - Rear fog lamp indicator light.
16 - Dynamic stability control(ASR/ESP) indicator light(petrol versions only). 17 -
Low coolant level warning light.
18 - Coolant temperature indicator.
19 - Trip recorder zero reset.
20 - Handbrake and low brake fluid level warning light.
21 - Seat belt not fastened warning light.
22 - Air bags warning light.
23 - ABS system warning light.
24 - Engine diagnostics warning light.
25 - Battery charge warning light.
26 - Diesel engine preheatingindicator light.
27 - Passenger air bag disarmingwarning light.
28 - Water in diesel filter warning light.
29 - Front brake pad wear warning light.
30 - Engine oil pressure warning light.
31 - Electronic immobiliser warning light.
32 - Lighting rheostat.
33 - Engine oil temperature.
YOUR 406 IN DETAIL
128
INSTRUMENT PANEL DIALS: PETROL / DIESEL
