2002 Peugeot 406 C Dag engine

80,000 (120 000) 100,000 (150 000) 120,000 (180 000) 140,000 (210 000) 160,000 (240 000)MILES (KM) 20,000 (30 000) 40,000 (60 000) 60,000 (90 000)
These fixed operations are carried out with
synthetic based oil; Fuel Economy oil
or synthetic oil may also be used.
* Whichever comes first. Intermediate visit.
THE MAINTENANCE CYCLE FOR YOUR 406 COUPE PETROL ENGINE
V6 24V Petrol injection Engine : Service every 20,000 miles (30 000 km) or 2 years
1st service at 6,000 miles
(10 000 km) or 6 months*. This is necessary
in order to benefit
from the warranty.
+ replacement of air filter
+ replacement of fuel filter
+ replacement of air filter
+ replacement of fuel filter
MAINTENANCE OF YOUR 406 COUPE 21
01-07-2002

These fixed operations are carried out with synthetic oil.
Warning : only use 5W 40 oil.
* Whichever comes first. Intermediate visit.
MILES (KM) 12,000 (20 000) 24,000 (40 000) 36,000 (60 000) 48,000 (80 000)
60,000 (100 000) 72,000 (120 000) 84,000 (140 000) 96,000 (160 000) 108,000 (180 000) THE MAINTENANCE CYCLE FOR YOUR 406 COUPE TURBO DIESEL HDI ENGINE
2.2 litre 16V Turbo Diesel HDI engine: service every 12,000 miles (20 000 km) or 2 years
1st service at 6,000 miles
(10,000 km) or 6 months*. This is necessary
in order to benefit from the warranty
+ maintenance of particulate emission filter + maintenance of particulate
emission filter
MAINTENANCE OF YOUR 406 COUPE
22
01-07-2002

MAINTENANCE OF YOUR 406 COUPE23

All driving conditions. oArduous conditions.
A AND C SERVICES AND THE INTERMEDIATE VISIT
- Oil filter- Fuel filter(Petrol)- Fuel filter element (diesel only).- Air filter element- Spark plugs (petrol only)
- Engine oil- Bleed fuel filter (diesel only)
- Engine oil (check + top-up)- Gearbox oil (check + top-up)- Battery (check + top-up)- Front/rear screen wash (check + top-up )- Coolant (check + top-up)- Brake fluid (check + top-up)- Power steering fluid (check + top-up according to specification)- Operation of lights and indicators- Condition of glass, headlamp & light lenses and mirrors- Horn- Windscreen washer jets- Condition of wiper blades- Condition and tension of the ancillary drive belts- Handbrake- Condition of hydraulic circuits (hoses and covers)- Condition of rubber boots and gaiters- Brake pads o- Play in hubs, link rods, ball joints, flexible mountings- Shock absorbers- Rear drum brake lining wear- Condition and pressure of tyres (including spare wheel)- Emission control check according to current legislation (petrol only)- Smoke opacity (diesel only) - Pollen filter (according to specification)o- Visual check of the whole vehicle by a Peugeot technician
DRAIN and REFILL
REPLACE
LEVELS
CHECK

ROAD TEST
- Courtesy vehicle
SERVICE
LevelOperation Description of Operation First Service
A C Intermediate
01-07-2002

TRADE NAMES OF APPROVED AND RECOMMENDED LUBRICANTS IN EUROPE(1)
PETROL
24
(1) Minimum quality standard: Petrol engines ACEA A3 and API SH/SJ; Diesel engines: ACEA B3 and API CF/CD - ACEA = Association des Constructeurs Europeens Automobiles
(Association of European Automobile Manufacturers) - API = American Petroleum Institute. If oil is used which does not conform to the ACEA A3-B3 standard, this requires the "Arduous Conditions" servicing schedule to be followed, which involves shorter intervals between services.
*This Fuel Economy oil can only be used in engines designed for its use (from 2000 Model Year). Use only 5W40 oil for the 2.2 litre HDI engine. Fuel Economy oil may not be used for the 2.2 litre 16 valve petrol engine
PETROL DIESEL DIESEL
01-07-2002

25
MAINTENANCE OF YOUR 406 COUPE
Recommendations for approved lubricants The oils which appear in the table opposite are suitable for most pur-poses. The diagram opposite states the optimum range of viscosity depend-ing on the temperatures at which theoils are to be used. It is also possible to use synthetic oils of "superior quality". In the absence of semi-synthetic or
synthetic oils, oils of API SH/SJ qual-ity (for petrol engines) or CD/CFquality (for diesel engines) may beused by following the "Arduous Con-ditions" maintenance schedule,which specifies shorter service inter-vals. Do not hesitate to ask for advice
from a PEUGEOT dealer to maintaindriving pleasure and to minimise themaintenance cost of your vehicle. For countries outside Europe, please
contact a local PEUGEOT dealer.
ONLY ONLY
Manual Gearbox ESSO GEAR OIL BV TOTAL TRANSMISSION BV 75W-80W PR 9736.41 75W-80W
Automatic Gearbox ONLY
4HP20 Ð AL4
ATF 4HP20-AL4 PR 9736.22
Power steering ESSO ATF D TOTAL FLUIDE AT42 PR 9730.94
Power steering FLUIDE DA PR9730. A1*
Brake fluid PEUGEOT DOT4 Coolant
PROCOR TM108/GLYSANTIN G33 or REVKOGEL 2000ONLYprotection to minus 35C
* Only for extremely cold countries. Other approved products
01-07-2002

1 -Fuel filler cap warning light.
2 - Door open warning light.
3 - Dipped beam headlamps indicator light.
4 - Main beam headlamps indicator light.
5 - Rev. counter.
6 - Left-hand direction indicator.
7 - Central (STOP) warning light.
8 - Low fuel level warning light.
9 - Fuel gauge. 10 -
Service indicator, oil level indica-
tor and total distance recorder.
11 - Right-hand direction indicator.
12 - Speedometer.
13 - Clogging of the particulateemission filter warning light(Diesel).
14 - Front fog lamps indicator light.
15 - Rear fog lamp indicator light.
16 - Dynamic stability control(ASR/ESP) warning light (petrolversions only). 17 -
Low coolant level warning light.
18 - Coolant temperature indicator.
19 - Trip recorder zero reset button.
20 - Handbrake and low brake fluid level warning light.
21 - Seat belt not fastened warninglight.
22 - Air bags warning light.
23 - ABS system warning light.
24 - Engine diagnostics warninglight.
25 - Battery charge warning light.
26 - Diesel engine preheating indicator light.
27 - Passenger air bag disarmingwarning light.
28 - Water in diesel filter warninglight.
29 - Front brake pad wear warninglight.
30 - Engine oil pressure warninglight.
31 - Electronic immobiliser warninglight.
32 - Lighting rheostat.
33 - Engine oil temperature indicator.
YOUR 406 COUPE IN DETAIL
102
INSTRUMENT PANEL DIALS: PETROL / DIESEL
01-07-2002

YOUR 406 COUPE IN DETAIL103
1 -
Fuel filler cap warning light.
2 - Door open warning light.
3 - Dipped beam headlamps indi- cator light.
4 - Main beam headlamps indicatorlight.
5 - Rev. counter.
6 - Left-hand direction indicator.
7 - Central (STOP) warning light.
8 - Low fuel level warning light.
9 - Fuel gauge. 10 -
Service indicator, oil level indicator and total distance
recorder.
11 - Right-hand direction indicator.
12 - Speedometer.
13 - Front fog lamps indicator light.
14 - Rear fog lamp indicator light.
15 - Dynamic Stability Control(ASR/ESP) warning light.
16 - Low coolant level warning light. 17 -
Coolant temperature indicator.
18 - Trip recorder zero reset button.
19 - Handbrake and low brake fluid level warning light.
20 - Seat belt not fastened warninglight.
21 - Air bags warning light.
22 - ABS system warning light.
23 - Engine diagnostics warninglight.
24 - Battery charge warning light.
25 - Passenger air bag disarmingwarning light.
26 - Front brake pad wear warninglight.
27 - Engine oil pressure warninglight.
28 - Operating programmes.
29 - Gear lever position indicator.
30 - Electronic immobiliser warninglight.
31 - Lighting rheostat.
32 - Engine oil temperature indicator.
INSTRUMENT PANEL DIALS: AUTOMATIC GEARBOX
01-07-2002

YOUR 406 COUPE IN DETAIL
104
WARNING LIGHTS AND INDICATORS
A permanently lit warning light, or flashing with the engine running, is an indication of a malfunction in the relevant unit. Some warning lights may
be linked to buzzers and a message on the multiÐfunction display. Do notignore this warning: contact a PEUGEOT dealer as quickly as possible.
If the Central (STOP) warning light comes on when you are driving, stop your vehicle immediately where it is safe to do so.
Central (STOP) warning light Linked to the "engine oil pressure", ''the low brake fluid level'', '' the coolant temperature gauge'' and ''electronic brake force distribu-tion system fault'' warning lights. It comes on each time the igni-tion is switched on.
Stop immediately if it flashes with the engine running.
Contact a PEUGEOT dealer.
Engine oil pressure warning light
Linked to the central (STOP) warning light.Stop immediately if it comes on with the engine running.
It indicates either:
Ðinsufficient oil pressure,Ðlack of oil in the lubrication circuit. Top up the oil level.
Contact a PEUGEOT dealer as soon as possible. Low coolant level warning light
Stop immediately. Allow the engine to cool before top- ping up. The cooling system is pressurised.In the event of a breakdown and to prevent the risk of scalding, turn thecap to the first notch to allow thepressure to drop. Once the pressure has dropped, remove the cap and top up the level.
Contact a PEUGEOT dealer.
Fuel filler cap warning light This comes on if the fuel cap is not correctly screwed
on or is missing.
