2002 Peugeot 406 C Dag engine

YOUR 406 COUPE IN DETAIL
86
Make a careful note of the number of each key. This number is coded on the label attached to the key. If the key is lost, your PEUGEOT dealer can rapidly supply you with new keys. The high frequency remote control is a sensitive system.
Do not operate it while it is in your pocket as there is a possibility that it may unlock your vehicle.The remote control cannot operate while the key is in the ignition, even if the ignition is off, except for reprogramming.
However, do not operate the deadlocking system if there is someone inside the vehicle.As a safety measure (when there are children on board), remove the key from the ignition when you leave the vehicle, even for a short time.
Avoid operating the remote control buttons out of range of your vehicle; you run the risk of stopping it from working. It would then be necessary to reprogramme it. When buying a second-hand vehicle:
- check that you have been given the confidential card;
- have the keys memorised by a PEUGEOT dealer to be sure that the keys in your possession are the only ones which can start the vehicle.
Do not make any modifications to the electronic engine immobiliser system.
01-07-2002

BOOT Simultaneous locking or unlock- ing of the boot and the doors
Turn the key a quarter turn from Ato
B .
The boot is then controlled by the remote control or the driver's doorlock. Locking the boot only
Turn the key a quarter of a turn from A to C. The boot is then locked,
whatever the action of the remotecontrol or the driver's door lock.
To return to simultaneous operation with the doors: turn the key from Ato
B .
YOUR 406 COUPE IN DETAIL
88
OPENING THE BONNET From inside:
pull the handle on the
left-hand side under the fascia.From outside: lift the catch and
raise the bonnet. Bonnet struts These open the bonnet and hold it open.
To close Lower the bonnet and release it at the end of its travel. Check that thebonnet is properly locked. FILLING WITH FUEL Fill with fuel with the engine switched
off.
To open the fuel filler flap, firmly pull the handle on the floor on the outsideof the driver's seat. If you are filling up your tank, do not
continue after the 3rd cut-off of thepump; this could cause your vehicleto malfunction. The capacity of the tank is approx- imately 15.4 gallons (70 litres).
A filler cap hook is provided on the inside of the fuel filler flap.
01-07-2002

AUTOMATIC SWITCHING ON OF THE LIGHTS Side lights and dipped beam head- lamps switch on automatically if the
light is poor, or during continuousoperation of the windscreen wipers.
They switch off as soon as the lightbecomes bright enough or the wind-screen wipers stop. This function is active when the vehi-
cle is supplied to the customer.
To disarm or activate the function: Place the key in the accessories position (1st notch),
 Press the end of the lights stalkfor more than two seconds.
Note: In foggy weather, the bright-
ness sensor can detect sufficientlight. Because of this, the lights do
not come on automatically. Do not cover the brightness sen-
sor connected to the rain sensor,located in the windscreen behind
the mirror. It is used for automaticswitching on of the lights. Operating check Activation Activation of this function is accom- panied by an audible signal and themessage
"Automatic lighting of
the headlamps activated" on the
multi-function display. Note: Always operate the lighting
controls manually where this is pos- sible. Disarming Disarming of the function is accom- panied by an audible signal. When driving, if this function is
switched off when the headlampswould switch on in automatic mode,the lights remain on. It is however possible to disarm this
function and switch off the lights by:
- manually switching off the lights using the lights stalk,
- switching off the engine. If the brightness sensor does not
function correctly,
the system acti-
vates the function (the lights comeon). The driver is alerted by the flashingof the ''dipped beam'' warning lighton the instrument panel.
Contact a PEUGEOT dealer to have the system checked. Follow me Home When there is a low level of bright- ness or at night, if you leave yourvehicle, the side lights and thedipped beam lights may remain onfor approximately one minute.
To do this: place the lights stalk in the AUTO
position,
 place the key in the accessories position (first notch),
 press the end of the lights stalk formore than two seconds,
 place the lights stalk in the 0posi-
tion,
 flash the headlamps,
 get out of the car and lock it.
YOUR 406 COUPE IN DETAIL
100
01-07-2002

AUTOMATIC AUTOADAPTIVE GEARBOX The 4-speed automaticgearbox offers the comfort of integral automatic
operation , enhanced by a sportprogramme (switch A) and a snowprogramme
(switch B).
Gear selection gate
Move the lever in the gate to select one of the positions. Once the position is selected, the indicator light for that position illuminates on the instrument panel
display.
PPark: for immobilising the vehicle and for startingthe engine, with the
handbrake on or off.
RReverse: this must be engaged when the vehicle is stationary and the engine
at idle.
NNeutral: for startingthe engine and for parking, with the handbrake on.
DDrive: for driving in autoadaptive mode (automatic changing of the four gears).
3.For driving in townor on winding roads (automatic changing of the first three
gears only).
2.For driving in the mountainsor for towing a trailer (automatic changing of
the first two gears only).
1.For use on steep gradients (selection of first gear only).
Special feature of the gearbox (2 litre petrol engine) Selection of first gear is by pressing button Cwith the lever in position 2.
To exit first gear, press button Cagain or move the selector lever.
121
DRIVING YOUR 406 COUPE
V6 engine 2 litre engine
01-07-2002

Moving Off
With the engine running, to move off from position P:
It is essential to press the brake pedal to exit position P (shift
lock),
Select the required position ( R, D ,
3 , 2 or 1) then gradually release
the brake pedal: the vehicle
moves off immediately.
You can also move off from positionN :
Release the handbrake with your foot on the brake pedal,
Select the required position ( R, D ,
3 , 2 or 1) then gradually release
the brake pedal: the vehicle
moves off immediately. Automatic Operation Automatic changing of the
four
gears :
Move the selector lever to position D.
The gearbox continuously selectsthe most suitable gear according tothe following parameters:
Ðdriving style,
Ðroad characteristics,
Ðvehicle load.
The gearbox functions in autoadaptive mode without any
action on your part. When the engine is idling
with position
R, D, 3, 2or
1 selected and the brakes
off, the car will move even
without you accelerating. For this reason, do not leave
children unsupervised inside the vehicle when the engine isrunning. If work needs to be done with the engine running, apply thehandbrake and select position P
.
Never select position Nwhen the
vehicle is moving. Never select position Por R
unless the vehicle is stationary .
Do not change from one position to another to optimise braking onslippery roads. In the event of battery failure, if the lever is in position Pit will not
be possible to change to anotherposition.
122
DRIVING YOUR 406 COUPE
Note: For immediate maximum acceleration
without touching the gear lever, pressthe accelerator pedal down as far as it
will go (kickdown). The gearbox willchange down automatically or stay inthe gear selected, up to maximumengine speed. When braking, the gearbox changes down automatically to provide
efficient engine braking.
If you take your foot off the
accelerator suddenly, the gearboxwill not change up for reasons of
safety.
01-07-2002

Sport and Snow programmes In addition to the autoadaptive programme, two special
programmes are available. Theindicator light corresponding to theprogramme selected lights up on theinstrument panel. Sport programme
Once the vehicle has been started and position Dselected, press the
S button.
The gearbox automatically favoursdynamic driving. Snow programme This programme makes starting
easier and offers smooth driving in
conditions when traction is poor.
Once the vehicle has been started and position Dselected, press the
button.
The gearbox adapts to driving on slippery roads. Note : You can return to the
autoadaptive programme at any time.
Press the Sor button again to
cancel the current programme. Operating anomaly Any disruption of the system is indicated by the alternate flashing ofthe sport and snow lights on theinstrument panel. In such a case, the gearbox will operate in downgrade mode (locked
in 3rd gear). You may feel asubstantial knock when reverse isselected from position
Por N(this
does not damage the gearbox). Do not exceed 60 m.p.h. (100 km/h), if regulations permit this.
Contact a PEUGEOT dealer without
delay.
DRIVING YOUR 406 COUPE 123
MANUAL GEARBOX Reverse
To change to reverse gear, lift the ring under the gear lever knob andpush the gear lever to the left then tothe front. Reverse gear can only be engaged when the vehicle is stationary withthe engine idling.
01-07-2002

Sport and Snow programmes In addition to the autoadaptive programme, two special
programmes are available. Theindicator light corresponding to theprogramme selected lights up on theinstrument panel. Sport programme
Once the vehicle has been started and position Dselected, press the
S button.
The gearbox automatically favoursdynamic driving. Snow programme This programme makes starting
easier and offers smooth driving in
conditions when traction is poor.
Once the vehicle has been started and position Dselected, press the
button.
The gearbox adapts to driving on slippery roads. Note : You can return to the
autoadaptive programme at any time.
Press the Sor button again to
cancel the current programme. Operating anomaly Any disruption of the system is indicated by the alternate flashing ofthe sport and snow lights on theinstrument panel. In such a case, the gearbox will operate in downgrade mode (locked
in 3rd gear). You may feel asubstantial knock when reverse isselected from position
Por N(this
does not damage the gearbox). Do not exceed 60 m.p.h. (100 km/h), if regulations permit this.
Contact a PEUGEOT dealer without
delay.
DRIVING YOUR 406 COUPE 123
MANUAL GEARBOX Reverse
To change to reverse gear, lift the ring under the gear lever knob andpush the gear lever to the left then tothe front. Reverse gear can only be engaged when the vehicle is stationary withthe engine idling.
01-07-2002

DRIVING YOUR 406 COUPE125
Handbrake Applying When parking, pull the handbrake to immobilise your vehicle.
Warning: when parking on a slope,
direct your wheels towards the pave- ment and apply the handbrake. Releasing Pull the handle and press the button to release the handbrake.
Disarming the ESP / ASR systems In certain conditions (vehicle stuck in
mud or snow, or on loose ground...),it could prove useful to disarm theASR system to make the wheelsspin and regain grip.
Press the switch
"ESP OFF", sit-
uated to the left of the steering wheel.
The switch lights up and the indicatorlights come on, accompanied by themessage '' ASR/ESP de-activated''
on the multi-function display: the
ESP and ASR systems no longer
affect the operation of the engine orthe brakes. They engage again:
automatically when the ignition is
switched off,
manually by pressing the switch again. The ESP system offersincreased safety duringnormal driving, but shouldnot incite the driver to take
risks or to drive at high speed.The operation of the system isassured to the extent to which therecommendations of the manufac-turer regarding the wheels (tyresand wheel rims), the braking com-ponents, the electronic compo-nents and the assembly andrepair procedures within thePEUGEOT network are respect-ed.After an accident or impact, havethe system checked by a
PEUGEOT dealer.
Operating check When a system malfunctionoccurs, the switch lightflashes and the indicatorlight comes on. Contact a
PEUGEOT dealer to check
the system.
TRACTION CONTROL (ASR)
AND DYNAMIC STABILITY
CONTROL (ESP) These systems are linked and com-
plement the ABS system.
The ASR system optimises drive to prevent the wheels skidding, by act-ing on the brakes of the drive wheelsand on the engine. It also allows thedirectional stability of the vehicle tobe improved on acceleration. If thereis a variation between the trajectoryfollowed by the vehicle and that
required by the driver, the ESP sys-tem automatically acts on the engineand the brake of one or morewheels, in order to put the vehicleback on course.
Operation of the ASR and ESP systems
When one of these two sys-tems is operating, this lightflashes.
01-07-2002
