2002 MINI Hardtop 2 Door Owner's Manual

OVERVIEW
CONTROLS
OPERATION, CARE, MAINTENANCE
OWNER SERVICE PROCEDURES
INDEX TECHNICAL DATA
119
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX
Data

120
ENGINE DATA
MINI COOPER MINI COOPER S
Displacement
Number of cylinders cu in/cmm97.52/1,598
497.52/1,598
4
Maximum output
at engine speed kW/bhp
rpm85/115
6,000120/163
6,000
Maximum torque
at engine speedlb ft/Nm
rpm110/149
4,500155/210
4,000
Compression ratioe
10.6 8.3
Stroke
Borein/mm
in/mm3.38/85.8
3.03/773.38/85.8
3.03/77
Fuel-injection system Digital electronic engine-management system

121
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX
DIMENSIONS
All dimensions specified in inches (millimeters). Smallest turning circle 35 ft (10.66 m).

122
WEIGHTS
MINI COOPER MINI COOPER S
Curb weight, ready for operation, with 165 lbs./75 kg
load, 90 % full tank, options not included
with manual transmission
with Continuously Variable automatic Transmission (CVT)lbs./kg
lbs./kg2,480/1,125
2,535/1,1502,678/1,215
Ð
Approved gross vehicle weightwith manual transmission
with Continuously Variable automatic Transmission (CVT)lbs./kg
lbs./kg3,263/1,480
3,318/1,5053,461/1,570
Ð
Approved front axle load lbs./kg 1,918/870 1,962/890
Approved rear axle load lbs./kg 1,543/700 1,675/760
Approved roof load (with special MINI roof rack) lbs./kg 165/75 165/75Luggage compartment capacity
cu ft/liters 5.3/150 5.3/150

123
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX
CAPACITIES
Notes
Fuel tank
Reserve gal./liters
gal./litersapprox. 13.2/50
approx. 2.1/8Fuel quality, see page 78
Windshield washer/
headlamp cleaning systemquarts/liters
quarts/litersapprox. 2.6/2.5
approx. 2.6/2.5 More details, see page 89
Cooling system including heater circuit quarts/liters 5.6/5.3 MINI COOPER
6.3/6.0 MINI COOPER SMore details, see page 91
Engine oil and filter change quarts/liters 4.7/4.5 MINI COOPER
4.7/4.5 MINI COOPER SLonglife Oil
More details, see page 89
Manual transmission, incl. differential quarts/liters approx. 2.1/2 MINI COOPER
approx. 1.8/1.7 MINI COOPER SContact your MINI center for more
details
Continuously Variable automatic
Transmission (CVT), incl. differentialquarts/liters approx. 4.2/4.0 MINI COOPER Contact your MINI center for more
details

124
ELECTRICAL SYSTEMBattery 12V, 55 AhSpark plugs NGK BKR 6 EQUPOriginal MINI parts and accessories
as well as qualified advice is available
at your MINI center.
<

125
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX

126
