2002 MERCEDES-BENZ M-Class display

143
Introduction Audio TelephoneNavigationIndex
System settings
If you select “Edit” a list of 6 icons will appear. Select up
to any 3 of the following icon types with the joystick.
After selecting each icon type press .
•ATM
•Bank
• Gas station
•Hotel
•Parking
• Restaurant and type of restaurantTo save the setting, select “Return” with the joystick and
press .
The Display Setup menu will appear indicating your 3
POI icon selections. To return to the Detailed Map Dis-
play, select “Return” with the joystick and press .
Move the Present Vehicle Position icon to any of the vis-
ible POI icons, press , and the name and address will
appear on the display for that icon.
Navigation settings

149
Introduction Audio TelephoneNavigationIndex
System settings
Viewing GPS Information
MCS allows you to view dynamic location information
received from GPS satellites. This feature is useful for
off-road users in establishing a starting point before off-
roading.
Press .
Select “Option” with the joystick and press .
The Option Select menu appears. Select “GPS Informa-
tion” with the joystick and press .The system will display the following GPS information:
• “Current Location”: Displays street, city and state
information.
• “Current Position”: Shows approximate latitude and
longitude information.
• “Satellites”: Displays the number of satellite signals
being received.
To return to the Option menu select “Return” with the
joystick and press .
P82.85-5095-26
P82.85-6542-26
Navigation settings

150
Introduction Audio TelephoneNavigationIndex
System settings
Viewing Software Information
You can view information about the CD-ROM version.
Use this information if you are requesting help from
your Mercedes-Benz Center.
Press .
Select “Option” with the joystick and press .
T he Option men u appe ars. Select “Information” with the
joystick and press .The CD-ROM version information is displayed.
To return to the Option menu select “Return” with the
joystick and press .
P82.85-5036-26
P82.85-5079-26
Navigation settings

151
Introduction Audio Telephone Navigation Index
System settings
Operating and display elements -
System settings............................................................. 152
Adjust sound settings...................................................... 153
Switching between
the light mode and the dark mode ............................ 155
Adjusting the brightness
in the dark mode .......................................................... 155
Adjusting the brightness
for navigation systems................................................. 157
Setting the display
dimming characteristics ............................................. 158
Contents - System settings

152
Introduction Audio Telephone Navigation Index
System settings
Operating and display elements - System settings 1Selecting audio sources or navigation menu,
Pages 18, 33, 50, 66, 88
2Color display with main menu
3Raising or lowering the volume, page 11
4Navigation menu:
Push joystick to : Adjusting the parameters,
p a g e 15 6 , 15 7
Push joystick to : Adjusting the parameters,
p a g e 15 6 , 15 7
Push joystick to : Select mode,
p a g e 15 6 , 15 7
Push joystick to : Select mode,
p a g e 15 6 , 15 7
5Audio sources:
Softkeys for:
Selecting the parameters, page 153
Adjusting the parameters, page 153
Switching between dark and light mode, page 155
Exit menu, page 153
System settings

155
Introduction Audio Telephone Navigation Index
System settings
Reset the sound settings:
Return to the audio menu and press the softkey
“ADJ” for longer then 2 seconds. All parameters will be
set to 0 and the sound system will switch to “STAN-
DARD“, and the MCS will return automatically to the
audio mode.Switching between
the light mode and the dark mode
When the parking lights are turned on, the display
switches to the dark mode. The display is illuminated in
a low dimmed level.P82.85-7160-26
P82.85-7156-26
System settings

157
Introduction Audio Telephone Navigation Index
System settings
Adjusting the brightness
for the navigation system
Start navigation mode, page 86.
Press . Select the menu “SETUP” with the joystick
and press .
Select the “Brightness” menu by pushing the joystick up
or down and press .
The brightness menu will appear with the current set-
tings.To darken the screen:
Push the joystick to .
To brighten the screen:
Push the joystick to .
Once you are satisfied with the brightness setting press
. A number corresponding to the brightness level will
be displayed for reference.
To return to the navigation mode, select “Return” with
the joystick and press .
P68.20-2110-27
P86-0081-B13 (2-fbg)
System settings

158
Introduction Audio Telephone Navigation Index
System settings
Setting the display dimming characteristics
You can set the monitor’s dimming characteristics for
the navigation mode.
Start navigation mode, page 86.
Press .
Select the menu “Setup” with the joystick and press .
Select the “Display” menu by pushing the joystick up or
down and press .
The display menu will appear with the current settings.You have 3 choices of display modes:
• “Day” mode: The display colors are always bright.
• “Night” mode: The display colors are always dark.
• “Auto” mode: The display switches automatically
between Night and Day mode when the parking
lights are turned on and off.
After selecting the mode press .
To return to the navigation mode, select “Return” with
the joystick and press .
P82.85-5072-26
P86-0081-B13 (2-fbg)
