2002 MERCEDES-BENZ E55AMG Owner's Manual

326 Fuels, coolants, lubricants etc. - capacities
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Gasoline additives
A major concern among engine manufacturers is carbon
build up caused by gasoline. Mercedes-Benz
recommends the use of only quality gasoline containing
additives that prevent the build up of carbon deposits.
After an extended period of using fuels without such
ad ditives , car bon d ep osits c an bui ld up esp eci ally on t he
intake valves and in the combustion area, leading to
engine performance problems such as:
•warm-up hesitation,
•unstable idle,
•knocking / pinging,
•misfire,
•power loss.
Do not blend other specific fuel additives with fuel.
They only result in unnecessary cost, and may be
harmful to the engine operation.
Damage or malfunctions resulting from poor fuel
quality or from blending specific fuel additives are not
covered by the Mercedes-Benz Limited Warranty.Coolants
The engine coolant is a mixture of water and
anticorrosion / antifreeze, which provides:
•corrosion protection,
•freeze protection,
•boiling protection (by increasing the boiling point).
The cooling system was filled at the factory with a
coolant providing freeze protection to approximately
-22
°F (-30
°C) and corrosion protection.
If the antifreeze mixture is effective to -22
°F (-30
°C), the
boiling point of the coolant in the pressurized cooling
system is reached at approximately 266
°F (130
°C).
The coolant solution must be used year round to provide
the necessary corrosion protection and increase in the
boil-over protection. You should have it replaced every
3years.
To provide the important corrosion protection, the
solution must be at least 45% anticorrosion / antifreeze
(equals a freeze protection to approx. - 22
°F [- 30
°C]). If
you use a solution that is more than 55% anticorrosion /
antifreeze (freeze protection to approx. - 49
°F [- 45
°C]),
W210.book Seite 326 Mittwoch, 30. Mai 2001 11:45 11

327 Fuels, coolants, lubricants etc. - capacities
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index the engine temperature will increase due to the lower
heat transfer capability of the solution. Therefore, do not
use more than this amount of anticorrosion / antifreeze.
If the coolant level is low, water and MB anticorrosion /
antifreeze should be used to bring it up to the proper
level (have cooling system checked for signs of leakage).
The water in the cooling system must meet minimum
requirements, which are usually satisfied by normal
drinking water. If your are not sure about the water
quality, consult your authorized Mercedes-Benz Center.
Anticorrosion / antifreeze
Your vehicle contains a number of aluminum parts. The
use of aluminum components in motor vehicle engines
necessitates that anticorrosion / antifreeze coolant used
in such engines be specifically formulated to protect the
aluminum parts. (Failure to use such anticorrosion /
antifreeze coolant will result in a significantly
shortened service life.)
Therefore the following product is strongly
recommended for use in your vehicle: Mercedes-Benz
Anticorrosion / Antifreeze Agent.Before the start of the winter season (or once a year in
the hot southern regions), you should have the
anticorrosion / antifreeze concentration checked. The
coolant is also regularly checked each time you bring
your vehicle to your authorized Mercedes-Benz Center
for service.
Anticorrosion / antifreeze quantity
Model Approx. freeze protection
– 35
°F
(– 37°C)– 49
°F
(– 45°C)
E 320 5.6 US qt
(5.3 l)5.8 US qt
(5.5 l)
E 430, E 55 AMG 6.1 US qt
(5.8 l)6.5 US qt
(6.1 l)
W210.book Seite 327 Mittwoch, 30. Mai 2001 11:45 11

328 Consumer information
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Consumer information
This has been prepared as required of all manufactures
of passenger cars under Title 49, Code of U.S. Federal
Regulations, Part 575 pursuant to the “National Traffic
and Motor Vehicle Safety Act of 1966”.
Uniform tire quality grading
Quality grades can be found where applicable on the
tire sidewall between tread shoulder and maximum
section width. For example:
All passenger car tires must conform to federal safety
requirements in addition to these grades.Treadwear
The treadwear grade is a comparative rating based on
the wear rate of the tire when tested under controlled
conditions on a specified government test course. For
example, a tire graded 150 would wear one and one-half
(1
1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends
upon the actual conditions of their use, however, and
may depart significantly from the norm due to
variations in driving habits, service practices and
differences in road characteristics and climate.
Traction
The traction grades, from highest to lowest are “AA”,
“A”, “B”, and “C”. Those grades represent the tire’s
ability to stop on wet pavement as measured under
controlled conditions on specified government test
surfaces of asphalt and concrete. A tire marked “C” may
have poor traction performance. Tread wear 200 Traction AA Temperature A
Wa r n i n g !
The traction grade assigned to this tire is based on
straightahead braking traction tests, and does not
include acceleration, cornering, hydroplaning, or
peak traction characteristics.
W210.book Seite 328 Mittwoch, 30. Mai 2001 11:45 11

329 Consumer information
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Tempera t u re
The temperature grades are “A” (the highest), “B”, and
“C”, representing the tire‘s resistance to the generation
of heat and its ability to dissipate heat when tested
under controlled conditions on a specified indoor
laboratory test wheel. Sustained high temperature can
cause the material of the tire to degenerate and reduce
tire life, and excessive temperature can lead to sudden
tire failure. The grade “C” corresponds to a level of
performance which all passenger car tires must meet
under the Federal Motor Vehicle Safety Standard
No. 109. Grades B and A represent higher levels of
performance on the laboratory test wheel than the
minimum required by law.
Wa r n i n g !
The temperature grade for this tire is established
for a tire that is properly inflated and not
overloaded. Excessive speed, underinflation, or
excessive loading, either separately or in
combination, can cause excessive heat build up
and possible tire failure.
W210.book Seite 329 Mittwoch, 30. Mai 2001 11:45 11

330 Index
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Index
AABS (Antilock brake system) ....................................... 217
Malfunction indicator lamp ..................................... 238
ABS-SYSTEM -
malfunction and warning messages ......................243
Adjusting steering wheel ................................................ 81
Air conditioner refrigerant ........................................... 324
Air distribution .............................................................. 130
Air volume ...................................................................... 130
Airbag deactivation system ............................................ 66
AIRBAG OFF indicator lamp ........................................239
Airbags .............................................................................. 69
Alarm system ............................................................. 43, 44
Anticorrosion/antifreeze ....................210, 264, 323, 326
Antilock brake system (ABS) ....................................... 217
Malfunction indicator lamp ..................................... 238
Antitheft alarm system ................................................... 43
Aquaplaning ...................................................................207
Armrest, rear bench ...................................................... 162
Ashtrays .......................................................................... 166
Center console ........................................................... 166
Rear doors .................................................................. 167Audio system
Anti-theft system ....................................................... 137
Button and soft key operation ................................. 138
Cassette mode ............................................................ 143
CD changer ................................................................. 148
CD mode ..................................................................... 147
Operating and display elements ............................. 136
Operating safety ........................................................ 135
Operation – audio and telephone ........................... 135
Radio mode ................................................................ 141
Telephone operation ................................................. 151
Audio systems ................................................................... 97
Cassette player ............................................................ 99
CD player ......................................................................98
Radio .............................................................................97
Automatic central locking .............................................. 36
Automatic climate control ............................................ 126
Activated charcoal filter ........................................... 132
Air distribution .......................................................... 130
Air recirculation ........................................................ 131
Air volume .................................................................. 130
Basic setting ............................................................... 129
Defogging windows ................................................... 129
Defrosting ...................................................................129
Display and controls .................................................128
Dust filter ................................................................... 131
W210.book Seite 330 Mittwoch, 30. Mai 2001 11:45 11

331 Index
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex Economy ..................................................................... 129
Front center console
compartment ventilation .................................... 133
Rear passenger compartment
adjustable air outlet ............................................. 134
Rear window defroster ............................................. 130
Residual engine heat utilization (REST) ............... 132
Special settings ......................................................... 129
Automatic transmission ............................................... 193
Emergency operation ............................................... 201
Fluid level ...................................................................263
Program mode selector switch ............................... 200
Selector lever position .............................................. 196
Transmission selector lever,
manually unlocking ............................................. 287
BBabySmart
TM airbag deactivation system ..................... 66
Self-test ......................................................................... 66
BAS (Brake assist system) ............................................ 215
Malfunction indicator lamp ..................................... 237
Battery .............................................................................280
Battery recycling ....................................................... 281
BATTERY / ALTERNATOR -
malfunction and warning messages ......................242Block heater .................................................................... 211
BRAKE ASSIST -
malfunction and warning messages ..................... 243
Brake assist system (BAS) ............................................ 215
Malfunction indicator lamp .................................... 237
Brake fluid ..................................................................... 324
BRAKE FLUID -
malfunction and warning messages ..................... 244
BRAKE LINING WEAR -
malfunction and warning messages ..................... 244
Brake pad wear .............................................................. 244
Brake warning lamp ..................................................... 235
Brake fluid low ......................................................... 235
Brakes .................................................... 204, 215, 217, 220
Bulbs
Replacing bulbs ........................................................ 288
CCapacities
Fuels, coolants, lubricants etc. .............................. 322
Cargo tie-down hooks .................................................... 169
Catalytic converter ......................................................... 188
CD changer ...................................................................... 148
Audio systems ..............................................................97
Cellular telephone .......................................................... 170
W210.book Seite 331 Mittwoch, 30. Mai 2001 11:45 11

332 Index
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Center console .................................................................. 20
Central locking switch .................................................... 35
Central locking system ................................................... 27
Automatic central locking ......................................... 36
Choosing global or selective mode ........................... 30
Electronic main key .................................................... 25
Locking and unlocking .............................................. 29
Mechanical keys .......................................................... 32
Remote control ............................................................ 25
Summer opening/convenience feature ................... 31
CHECK ENGINE
malfunction indicator lamp ..................................... 234
Check regularly and before a long trip ...................... 231
Checking engine oil level
Via engine oil level indicator ...................................117
Via oil dipstick ...........................................................262
Child restraint .....................................................59, 66, 77
Child seat
Infant and child restraint systems ........................... 77
Cleaning and care of the vehicle .................................304
Clock, setting ................................................................... 111
Coin holder in glove box lid ......................................... 163
COMAND, radio and telephone ....................................176
Combination switch ...................................................... 122
Consumer information .................................................. 328
Control and operation of radio transmitters ..............176COOLANT (coolant level) -
malfunction and warning messages ..................... 246
Coolant level .................................................................. 263
Adding coolant .......................................................... 264
Checking .................................................................... 263
COOLANT TEMP. -
malfunction and warning messages ..................... 247
Coolant temperature gauge ............................................90
Coolants .......................................................................... 326
Anticorrosion/antifreeze quantity ........................ 327
Cruise control ................................................................. 212
Cup holder
In center console ....................................................... 165
In glove box lid .......................................................... 163
In rear bench armrest ............................................... 162
DDaytime running lamps ................................................120
Deep water
Driving instructions ................................................. 211
DISPLAY DEFECTIVE (engine control unit) -
malfunction and warning messages ...................... 241
DISPLAY DEFECTIVE (several systems) -
malfunction and warning messages ...................... 241
Display illumination ........................................................89
W210.book Seite 332 Mittwoch, 30. Mai 2001 11:45 11

333 Index
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex Doors .................................................................................. 33
Drinking and driving ....................................................203
Drive sensibly - Save Fuel ............................................ 203
Driving instructions ......................................................203
Driving off .......................................................................205
EELEC. STABIL. PROG. -
malfunction and warning messages ......................253
Electronic main key ......................................................... 25
Changing batteries ................................................... 294
Synchronizing remote control ................................ 296
Electronic stability program (ESP) .............................. 220
Control switch ...........................................................222
Malfunction indicator lamp ..................................... 237
Synchronizing ........................................................... 221
Warning lamp ............................................................237
Emergency call
See Tele Aid ............................................................... 178
Emergency engine shut-down ..................................... 296
Emergency tensioning retractor (ETR) ......................... 68
SRS Indicator lamp ................................................... 236
Emergency trunk lid release button ....................... 41, 42
Emergency unlocking in case of accident ................... 36Emission control ............................................................ 189
Emission control label ................................................... 314
Engine compartment .................................................... 259
ENGINE FAN -
malfunction and warning messages ..................... 245
Engine malfunction
CHECK ENGINE
malfunction indicator lamp ............................... 234
Engine Oil Additives ..................................................... 324
Engine oil consumption ................................................ 118
Engine oil level
Checking ............................................................. 117, 262
Warning ...................................................................... 251
ENGINE OIL LEVEL -
malfunction and warning messages ......................251
Engine oil level indicator .............................................. 117
Engine oils ..................................................................... 324
ESP (Electronic Stability Program) ............................ 220
Control switch .......................................................... 222
Malfunction indicator lamp .................................... 237
Synchronizing ...........................................................221
Warning lamp ........................................................... 237
ETR (Emergency tensioning retractor) .........................68
SRS Indicator lamp .................................................. 236
Express opening and closing
Power windows .......................................................... 154
W210.book Seite 333 Mittwoch, 30. Mai 2001 11:45 11
