2002 MERCEDES-BENZ E55AMG Owner's Manual

318 Technical data
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
2 Must only be used with special MB authorized snow chains.
3 Also permissible 235 / 45 ZR 17.Model E 320
(Sport Package)E 430
(without Sport Package)E 430
(Sport Package)
Rims (light alloy)
Wheel offset8 J x 17 H2
1.46 in (37 mm)7
1/2 J x 17 H2
1.46 in (37 mm)8 J x 17 H2
1.46 in (37 mm)
Summer tires:
Radial-ply tires 235 / 45 R 17 93 W
2, 3
235 / 45 R 17 93 W
2, 3
235 / 45 R 17 93 W
2, 3
Winter tires:
Radial-ply tires 235 / 45 R 17 93 W M+S
2
235 / 45 R 17 93 H M+S
2
235 / 45 R 17 93 H M+S
2
Spare wheel
Rim (light alloy)
Wheel offset7
1/2 J x 17 H 2
1.46 in (37 mm)7
1/2 J x 17 H 2
1.46 in (37 mm)7
1/2 J x 17 H 2
1.46 in (37 mm)
Summer tire:
Radial-ply tire 235 / 45 R 17 93 W
2, 3
235 / 45 R 17 93 W
2, 3
235 / 45 R 17 93 W
2, 3
W210.book Seite 318 Mittwoch, 30. Mai 2001 11:45 11

319 Technical data
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
3 Also permissible 235 / 45 ZR 17.
4 Must not be used with snow chains.
Model E 55 AMG
Rims and summer tires
Rims front axle
(AMG light alloy)
Wheel offset8 J x 18 H 2
1.2 in (31 mm)
Rims rear axle
(AMG light alloy)
Wheel offset9 J x 18 H 2
1.4 in (35 mm)
Radial-ply tires, front axle
Radial-ply tires, rear axle245 / 40 ZR 18
4
275 / 35 ZR 18
4
Rims and winter tires
Rims
(AMG light alloy)
Wheel offset7
1/2 J x 17 H 2
1.4 in (35 mm)
Radial-ply tires 235 / 45 R 17 93 H M+SSpare wheel
Rim
(AMG light alloy)
Wheel offset7
1/2 J x 17 H 2
1.46 in (37 mm)
Summer tire:
Radial-ply tire 235 / 45 R 17 93 W
3
W210.book Seite 319 Mittwoch, 30. Mai 2001 11:45 11

320 Technical data
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Electrical system
We i g h t s
(see certification tag) Model E 320 E 430 E 55 AMG
Generator (alternator) 14 V / 115 A 14 V / 150 A 14 V / 150 A
Starter motor 12V / 1.7 kW 12V / 1.7 kW 12V / 1.7 kW
B a t t e r y 12 V / 10 0 A h 12 V / 10 0 A h 12 V / 10 0 A h
Spark plugs
Electrode gap
Tightening torqueBosch F 8 DPER
Beru 14 FGH 8 DPUR X 2
NGK PFR 5 R-11
0.039 in (1.0 mm)
15 – 22 ft.lb (20 – 30 Nm)Bosch F 8 DPER
Beru 14 FGH 8 DPUR X 2
NGK PFR 5 R-11
0.039 in (1.0 mm)
15 – 22 ft.lb (20 – 30 Nm)NGK PFR 5 -11
0.039 in (1.0 mm)
15 – 22 ft.lb (20 – 30 Nm)
Roof load max. 220 lb (100 kg)
Trunk load max. 220 lb (100 kg)
W210.book Seite 320 Mittwoch, 30. Mai 2001 11:45 11

321 Technical data
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Main Dimensions
Model E 320 E 430 E 55 AMG
Overall vehicle length 189.5 in (4812 mm) 189.5 in (4812 mm) 190 in (4818 mm)
Overall vehicle width 70.8 in (1799 mm) 70.8 in (1799 mm) 70.8 in (1799 mm)
Overall height 56.7 in (1441 mm) 56.8 in (1443 mm) 56.9 in (1445 mm)
Wheel base 111.5 in (2833 mm) 111.5 in (2833 mm) 111.5 in (2833 mm)
Track, front 60.4 in (1534 mm) 60.7 in (1542 mm) 61.4 in (1560 mm)
Track, rear 60.2 in (1528 mm) 60.5 in (1536 mm) 60.7 in (1543 mm)
Model E 320 AWD E 430 AWD
Overall vehicle length 189.5 in (4812 mm) 189.5 in (4812 mm)
Overall vehicle width 70.8 in (1799 mm) 70.8 in (1799 mm)
Overall height 57.1 in (1451 mm) 57.3 in (1455 mm)
Wheel base 111.5 in (2833 mm) 111.5 in (2833 mm)
Track, front 60.2 in (1528 mm) 60.1 in (1526 mm)
Track, rear 60.1 in (1526 mm) 60.4 in (1534 mm)
W210.book Seite 321 Mittwoch, 30. Mai 2001 11:45 11

322 Fuels, coolants, lubricants etc. - capacities
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Fuels, coolants, lubricants etc. - capacities
Vehicle components and their respective lubricants must match. Therefore use only brands tested and recommended
by us. Please refer to the Factory Approved Service Products pamphlet, or inquire at your authorized Mercedes-Benz
Center.
Model Capacity Fuels, coolants, lubricants etc.
Engine with oil filter E 320, E 430
E 55 AMG8.5 US qt (8.0 l)
8.0 US qt (7.5 l)Recommended engine oils
Automatic
transmissionE 320, E 430 with AWD,
E 430,
E 55 AMG8.0 US qt (7.5 l)
9.1 US qt (8.6 l)
9.6 US qt (9.1 l)Automatic transmission fluid
Rear axle 1.4 US qt (1.3 l) Hypoid gear oil SAE 90, 85 W 90
Front axle E 320 with AWD
E 430 with AWD0.5 US qt (0.46 l) Hypoid gear oil SAE 90, 85 W 90
Transfer case E 320 with AWD
E 430 with AWDapprox. 1.1 US qt (1.0 l) Automatic transmission fluid
Power steering approx. 1.3 US qt (1.1 l) MB Power steering fluid
Front wheel hubs approx. 2.1 oz (60 g) each High temperature roller bearing
grease
Brake system E 320
E 430approx. 0.5 US qt (0.5 l)
approx. 0.7 US qt (0.7 l)MB Brake fluid (DOT 4)
W210.book Seite 322 Mittwoch, 30. Mai 2001 11:45 11

323 Fuels, coolants, lubricants etc. - capacities
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Windshield washer
systemapprox. 5.8 US qt (5.5 l) MB Windshield washer
concentrate “S” 1
Headlamp washer
systemapprox. 1.9 US qt (1.8 l) MB Windshield washer
concentrate “S”
1
Cooling system E 320
E 430, E 55 AMGapprox. 10.6 US qt (10.1 l)
approx. 11.8 US qt (11.2 l)MB Anticorrosion / antifreeze
Fuel tank including
a reserve ofapprox. 21.1 US gal (80.0 l)
approx. 2.6 US gal (10.0 l)Premium unleaded gasoline:
Posted Octane 91
(Avg. of 96 RON / 86 MON)
Air conditioner
systemR-134a refrigerant and special
PA C l u b r i c a n t (Never R-12)1 Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing or MB Windshield Washer Concentrate “S” and
commercially available premixed windshield washer solvent / antifreeze for temperatures below freezing. Follow suggested mixing ratios, see
page 265.
Model Capacity Fuels, coolants, lubricants etc.
W210.book Seite 323 Mittwoch, 30. Mai 2001 11:45 11

324 Fuels, coolants, lubricants etc. - capacities
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Engine oils
Engine oils are specifically tested for their suitability in
our engines. Therefore, use only engine oils
recommended by Mercedes-Benz. Information on
recommended brands is available at your authorized
Mercedes-Benz Center.
Please follow Service Booklet recommendations for
scheduled oil changes. Failure to do so could result in
engine damage not covered by the Mercedes-Benz
Limited Warranty.
Engine oil additives
Do not blend oil additives with engine oil. They may be
harmful to the engine operation.
Damage or malfunctions resulting from blending oil
additives are not covered by the Mercedes-Benz Limited
Warranty.Air conditioner refrigerant
R-134a (HFC) refrigerant and special PAG lubricating oil
is used in the air conditioner system.
Never use R-12 (CFC) or mineral-based lubricating oil,
otherwise damage to the system will occur.
Brake fluid
During vehicle operation, the boiling point of the brake
fluid is continuously reduced through the absorption of
moisture from the atmosphere. Under extremely hard
operating conditions, this moisture content can lead to
the formation of bubbles in the system thus reducing
the system’s efficiency.
The brake fluid must therefore be replaced every two
years, preferably in the spring.
It is recommended to use only brake fluid approved by
Mercedes-Benz. Your authorized Mercedes-Benz Center
will provide you with additional information.
W210.book Seite 324 Mittwoch, 30. Mai 2001 11:45 11

325 Fuels, coolants, lubricants etc. - capacities
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Premium unleaded gasoline
Caution!
To maintain the engine‘s durability and performance,
premium unleaded gasoline must be used. If premium
unleaded is not available and low octane fuel is used,
follow these precautions:
•have the fuel tank filled only partially with unleaded
regular and fill up with premium unleaded as soon
as possible,
•avoid full throttle driving and abrupt acceleration,
•do not exceed an engine speed of 3000 rpm, if the
vehicle is loaded with a light load such as two
persons and no luggage,
•do not exceed
2/3 of maximum accelerator pedal
position, if the vehicle is fully loaded or operating in
mountainous terrain.Fuel requirements
Use only Premium unleaded meeting ASTM
standard D 439:
The octane number (posted at the pump) must be
91 min. It is an average of both the Research (R) octane
number and the Motor (M) octane number: [(R+M) / 2].
This is also known as ANTI-KNOCK INDEX.
Unleaded gasoline containing oxygenates such as
Ethanol, IPA, IBA and TBA can be used provided the
ratio of any one of these oxygenates to gasoline does not
exceed 10%, MTBE not to exceed 15%.
The ratio of Methanol to gasoline must not exceed 3%
plus additional cosolvents.
Using mixtures of Ethanol and Methanol is not allowed.
Gasohol, which contains 10% Ethanol and 90% unleaded
gasoline, can be used.
These blends must also meet all other fuel requirements
such as resistance to spark knock, boiling range, vapor
pressure etc.
