2002 MERCEDES-BENZ CL-Class Navigation

137 Destination input
Introduction
Audio Telephone
Navigation
Index Info Services and
system settings
NavigationChanging the Navigation CD
Press
to eject an inserted navigation CD.
Insert another navigation CD.
The screen above will be displayed. The program stored
on the navigation CD is being loaded.
Important!
Do not interrupt the loading process. Do not insert
an audio CD until the loading process has been
completed.
P82.85-6094-26
You will then hear a voice output message informing
you that the language is being loaded into memory.
Notes:
If it has not been removed, the navigation CD ejected
will be automatically retrieved by the CD player after
10 seconds.
The CD player can either read navigation CDs (destina-
tion input, route guidance) or play back audio CDs (CD
mode).
During CD mode only the playback modes “Standard”,
“Track repeat” and “Magazine mix” can be selected,
page 60.
08-NAVI1-203-US.pm507.06.2001, 16:49 Uhr 137

138
Destination input
Audio TelephoneNavigation
Index Info Services and
system settings Introduction
Menu overview – Destination entry
P82.85-6123-29
8
6
432
1
7
5
08-NAVI1-203-US.pm507.06.2001, 16:49 Uhr 138

139 Destination input
Introduction
Audio Telephone
Navigation
Index Info Services and
system settings 1Main destination input menu, select type of
destination entry:
Entering destination address, page 140
Retrieving a destination from destination memory,
page 197
Selecting a destination via the map, page 151
Entering points of interest, page 155
Selecting the last destinations
(the last 12 destinations), page 160
2Entering destination address, page 1403Main destination memory menu, page 196
4Set destination via location on map, page 151
5Details about previous destination
6Entering the vehicle position manually, page 203
System calibration, page 204
7Activates the list of the last 12 destinations for a
new calculation, page 160
8Points of interest main menu – set destination via
point of interest listing, page 155
08-NAVI1-203-US.pm507.06.2001, 16:49 Uhr 139

140
Destination input
Audio TelephoneNavigation
Index Info Services and
system settings Introduction
Entering destination address
Press the right-hand rotary/pushbutton
in the main
destination input menu to confirm the “Address...” menu
field.1Info/status line
2Select city/suburb, page 141
No entry: place not yet entered
Entry available: place last entered
3Selecting a street, page 145
Menu field can be selected if a city has been
previously selected
4Selecting a city center, page 150
Menu field can be selected if a city has been
previously selected
To cancel destination input:
Press
.
The main destination input menu will appear.
P82.85-2595-26
43
2
1
08-NAVI1-203-US.pm507.06.2001, 16:49 Uhr 140

141 Destination input
Introduction
Audio Telephone
Navigation
Index Info Services and
system settings Select city/suburb
Press the right-hand rotary/pushbutton
to confirm the
“City/Suburb...” menu field. An entry menu will appear.
5Input line, selected characters are shown inverted;
the last city selected is also shown here
6Character set – alphabetic, numeric and special
characters
7Zoom, enlarges the currently selected character
8Move the insertion point one position to the right
9Activate the city listSelecting a new destination:
Selections are made from the city list (9), call up via
the menu field (9). First enter in the input line (5) the
required destination or adopt the destination last
selected.
Entering the destination via the input menu:
Turn the right-hand rotary/pushbutton
to select the
desired letter from the character set (6), it will appear
magnified (7).
Press the right-hand rotary/pushbutton to confirm
your selection, the letter selected will appear highligh-
ted in the input line (5).
The new entry will be completed with additional letters
to form one of the city/suburb names available on the
list.
Note:
For quicker input, the system will offer available
characters from the character set (6) based on your
selections and the names of the cities stored on the
navigation CD.
P82.85-7080-26
7
6
5
8
9
08-NAVI1-203-US.pm507.06.2001, 16:49 Uhr 141

142
Destination input
Audio TelephoneNavigation
Index Info Services and
system settings Introduction
Move the insertion point one positon to the right:
Use the right-hand rotary switch/pushbutton
to
highlight the symbol (8) and confirm by pressing.Correcting the entry:
To delete the last character entered – press
briefly
To delete all of the characters entered – press
longer than 2 seconds
08-NAVI1-203-US.pm507.06.2001, 16:49 Uhr 142

143 Destination input
Introduction
Audio Telephone
Navigation
Index Info Services and
system settings To access the list of places:
Press the right-hand rotary/pushbutton
longer than
2 seconds or highlight and confirm menu field (9).
10Selected City/Suburb, already highlighted
11Display to previous page
12Display to next pageP82.85-3011-26
1211
10
The next/previous page can be reached by turning the
right-hand rotary/pushbutton
past the last/first entry.
Turn the right-hand rotary/pushbutton
to highlight
the desired destination and press it to confirm.
08-NAVI1-203-US.pm507.06.2001, 16:49 Uhr 143

144
Destination input
Audio TelephoneNavigation
Index Info Services and
system settings Introduction
If the destination selected is stored on the CD more
than once, a menu will appear so you can confirm the
desired place name.
Otherwise, the selection menu illustrated above will
appear on the screen.
P82.85-3012-26
131514
16
13City previously selected
14Selecting a street, page 145
15Selecting a city center, page 150
16Activates the map to select a destination, page 152
