2002 LINCOLN BLACKWOOD Owners Manual

POSITIVE RETENTION FLOOR MAT
Position the floor mat so that the
eyelet is over the pointed end of the
retention post and rotate forward to
lock in. Make sure that the mat does
not interfere with the operation of
the accelerator or the brake pedal.
To remove the floor mat, reverse the
installation procedure.
TAILGATE DUAL-DOORS
The rear cargo area is intended for cargo storage only, not for
passengers. You can open and close the tailgate dual-doors from outside
the vehicle only.
²To access the rear cargo area,
open the tonneau cover using the
overhead console button, the key
fob button or key pad on the
door.
²To open dual-doors, open the
right door using the inside door
handle, then open the left door
using the handle on the side of
the door.
²To close dual-doors, close the left
door first, then the right door.
²Close the tonneau cover using the overhead console button, the key
fob button or key pad on the door.
The tailgate dual-doors should be closed before driving your
vehicle. Leaving the tailgate dual-doors open could cause serious
damage to the tailgate dual-doors and its components.
Controls and features
73

The outside edge of the tonneau cover, or the top edge of the
pickup box, must remain clear of excessive ice, snow, dirt, or
other debris to ensure proper closure of the tonneau cover and prevent
damage to the vehicle.
NOTE:Slide-in campers cannot be installed on this vehicle.
PICKUP BOX STORAGE COMPARTMENT
The storage compartments are located inside the pickup box.
1. To open, push the button on the
storage compartment to pop up the
knob.
2. Turn knob counterclockwise to
unlock and pull the storage
compartment open.
3. To close, follow steps 1 and 2 in
reverse order.
POWER HARD TONNEAU COVER
The tonneau cover has been designed to enclose the cargo area.
To avoid damage to the cover, do not operate the vehicle unless the
cover is fully secured.
Controls and features
74

The tonneau cover can be operated
by the following:
²overhead console button
²key fob button
²keyless entry key pad
²manually
The Overhead console button and
Keyless entry pad features will only
operate the tonneau cover with the
vehicle in P (Park) or N (Neutral),
the ignition in any position and both
tailgate dual doors must be closed.
The Key fob feature will only operate the tonneau cover with the ignition
in any position except RUN.
NOTE:The instrument panel door ajar light will illuminate when the
tonneau cover is in the open position.
To open the cover from the Overhead console:
Refer toOverhead controlsin this section.
To open the cover with the Key fob:
Refer toRemote Entry Systemin this section.
To open the cover with the Keyless entry pad:
Refer toKeyless Entry Systemin this section.
Controls and features
75

To open the cover Manually:
If an electrical or battery failure
happens, your vehicle is equipped
with a manual release lever that can
open the tonneau cover.
1. To open, locate the manual
release lever under the right front
corner of the pickup box.
2. Using the ignition key, unlock the
cover and pull the lever down to
manually open the tonneau cover.
3. Push the tonneau cover up for
access to the pickup box.
4. To close, push the tonneau cover
down on the pickup box until it
latches.
INTERIOR TONNEAU COVER RELEASE
Your vehicle is equipped with a mechanical interior tonneau cover
release handle that provides a means of escape for children and adults in
the event they become locked inside the pickup box.
Adults are advised to familiarize themselves with the operation and
location of the release handle.
Controls and features
76

To open the tonneau cover from the
inside, pull the ªTº shaped handle
and push up on the tonneau cover
panel. The material that the handle
is made of will glow for hours in the
darkness of the pickup box following
brief exposure to ambient light. With
the tonneau cover popped up the
right tailgate door can be opened to
exit.
The ªTº shaped handle is located on
the pickup box.
Keep vehicle doors and tonneau cover locked and keep keys and
key fob out of a child's reach. Unsupervised children could lock
themselves in an open pickup box and risk injury. Children should be
taught not to play in vehicles.
On hot days, the temperature in the pickup box can rise very
quickly. Exposure of people or animals to these high
temperatures for even a short time can cause death or serious
heat-related injuries, including brain damage. Small children are
particularly at risk.
SECURILOCKYPASSIVE ANTI-THEFT SYSTEM
SecuriLockypassive anti-theft system is an engine immobilization
system. This system prevents the engine from being started unless a
coded key programmed to your vehicleis used.
The SecuriLockypassive anti-theft system is not compatible with
non-Ford aftermarket remote start systems. Use of these systems may
result in vehicle starting problems and a loss of security protection.
Controls and features
77

Automatic arming
The vehicle is armed immediately
after switching the ignition to the 3
(OFF) position. The
THEFTlight in
the instrument cluster will flash
every two seconds when the vehicle
is armed.
Automatic disarming
Switching the ignition to the 4 (ON) position with acoded keydisarms
the vehicle. The
THEFTlight will illuminate for three seconds and then
go out. If theTHEFTlight stays on for an extended period of time or
flashes rapidly, have the system serviced by your dealership or a
qualified technician.
Key information
Your vehicle is supplied withthree
coded keys(two masters and one
gray valet key). Only acoded key
will start your vehicle.
The valet key only starts the vehicle
and unlocks/locks the drivers door.
The valet lock, located in the front
center console, is used to lock and
unlock access to the tonneau cover.
When locked, the overhead console
access to the tonneau cover is
disabled.
Spare coded keys can be purchased from your dealership. Your
dealership can program your key or you can ªdo it yourselfº, refer to
Programming spare keys.
3
2
1
5
4
Controls and features
78

Large metallic objects, electronic
devices on the key chain that can be
used to purchase gasoline or similar
items, or a second key on the same
key ring as thecoded keymay
cause vehicle starting issues. If
present, you need to keep these
objects from touching thecoded key
while starting the engine. These
objects and devices cannot damage
thecoded key,but can cause a
momentary issue if they are too close
to the key during engine start. If a
problem occurs, turn ignition OFF
and restart the engine with all other
objects on the key ring held away from the ignition key. Check
to make sure thecoded keyis an approved Fordcoded key.
If your keys are lost or stolen you
will need to do the following:
²Use your spare key to start the
vehicle. or
²Have your vehicle towed to a
dealership or locksmith. The key
codes will need to be erased from
your vehicle and new key codes will need to be re-coded.
Replacing coded keys can be very costly and you may want to store an
extra programmed key away from the vehicle in a safe place to prevent
an unforeseen inconvenience.
The correctcoded keymust be used for your vehicle. The use of the
wrong type ofcoded keymay lead to a ªNO-STARTº condition.
If an unprogrammed key is used in the ignition it will cause a
ªNO STARTº condition.
Programming spare keys
A maximum of eight keys can be coded to your vehicle. Only
SecuriLockykeys can be used. To program acoded keyyourself, you
will need two previously programmedcoded keys(keys that already
operate your vehicle's engine) and the new unprogrammed key(s) readily
accessible for timely implementation of each step in the procedure.
Controls and features
79

If two previously programmed coded keys are not available, you must
bring your vehicle to your dealership to have the spare coded key(s)
programmed.
Please read and understand the entire procedure before you begin.
1. Insert the first previously
programmedcoded keyinto the
ignition and turn the ignition from 3
(OFF) to 4 (ON) (maintain ignition
in 4 (ON) for at least one second).
2. Turn ignition to 3 (OFF) then 2
(LOCK) and remove the firstcoded
keyfrom the ignition.
3. Within five seconds of removing
the firstcoded key,insert the
second previously programmedcoded keyinto the ignition and turn the
ignition from 3 (OFF) to 4 (ON) (maintain ignition in 4 (ON) for at least
one second but no more than five seconds).
4. Turn the ignition to 3 (OFF) then 2 (LOCK) and remove the second
coded keyfrom the ignition.
5. Within 10 seconds of removing the secondcoded key,insert the new
unprogrammed key (new key/valet key) into the ignition and turn the
ignition from 3 (OFF) to 4 (ON) (maintain ignition in 4 (ON) for at least
one second). This step will program your new key to a coded key.
6. To program additional new unprogrammed key(s), repeat this
procedure from step 1.
If successful, the new coded key(s) will start the vehicle's engine and the
theft indicator will illuminate for three seconds and then go out.
If not successful, the new coded key(s) will not start the vehicle's engine
and the theft indicator will flash on and off and you may repeat steps 1
through 6. If failure repeats, bring your vehicle to your dealership to
have the new spare key(s) programmed.
REMOTE ENTRY SYSTEM
This device complies with part 15 of the FCC rules and with RS-210 of
Industry Canada. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device
must accept any interference received, including interference that may
cause undesired operation.
3
2
1
5
4
Controls and features
80
