2002 Lexus ES300 fuse box

INTRODUCTION
289
ENGINE COMPARTMENT OVERVIEW
1 Power steering fluid
reservoir
2 Engine oil filler cap
3 Brake fluid reservoir
4 Fuse box
5 Battery
6 Fuse box
7 Radiator
8 Condenser
9 Electric cooling fans
10 Engine oil level
dipstick
11 Washer fluid tank
12 Engine coolant
reservoir

ELECTRICAL COMPONENTS
328
No.FUSEAMPERECIRCUIT
38 POWERPOINT15Power outlet
39 RAD NO.120Car audio system, navigation
system
40 GAUGE110
Gauges and meters, clock,
outside temperature gauge,
multiinformation display, shift
lock system
41 ECUIG10
SRS airbag system, power
windows, antilock brake
system, electronic modulated
suspension, driving position
memory system
42 WIPER25Windshield wipers
43 HTR10Air conditioning system
44 MIR
HTR10Outside rear view mirror
heaters
45 AM15Starting system
46 FOG15Front fog lights
47 SUN
SHADE15Rear sunshade
48 GAUGE210
Auto antiglare inside rear
view mirror, compass, backup
lights, automatic light control
system, automa tic headlight
leveling system, cruise control
system, seat belt reminder
lights
No.FUSEAMPERECIRCUIT
49 PANEL10
Glove box light, console box
light, clock, outside
temperature gauge,
multiinformation display,
instrument cluster lights,
instrument panel lights,
overdriveoff indicator light
50 TAIL10Tail lights, parking lights,
license plate lights
51 PWR NO.420Rear passenger’s power
window (left side)
52 PWR NO.220Front passenger’s door lock
system, front passenger’s
power window
53 OBD7.5Onboard diagnosis system
54 SEAT
HTR20Seat heaters
55 WASHER15Windshield washer
56 FA NRLY10Electric cooling fans
57 STOP15Stop lights, high mounted stop-
light
58 FUEL
OPEN5Fuel filler door opener
59 DOOR NO.225
Multiplex communication
system (power door lock
system, autodoor locking
system, wireless remote
control system)

ELECTRICAL COMPONENTS
333
Driver’s side instrument panel
1. Turn the ignition switch off and remove the auxiliary
box.
Determine which fuse may be causing the problem. The
auxiliary box shows the name of the circuit for each fuse.2. Make sure the inoperative component is turned off. Pull
the suspected fuse straight out with the pullout tool and
check it. If it has blown, push a new fuse into the clips.

ELECTRICAL COMPONENTS
334
GoodBlown
a. Look carefully at the fuse. If the thin wire is broken, the fuse
has blown. If you are not sure or if it is too dark to see, try
replacing the suspected fuse with one of the same value that
you know is good.
b. Only install a fuse with the amperage rating designated on
the fuse box lid.
If you do not have a spare fuse, in an emergency you can pull
out the “RAD NO.1”, “RAD NO.2” or “POWER POINT” fuse,
which may be dispensable for normal driving, and use it if its
amperage rating is the same.
If you cannot use one of the same amperage, use one lower
than, but as close as possible to, the amperage. If the
amperage is lower than that specified, the fuse might blow out
again but this does not indicate anything wrong. Be sure to get
the correct fuse as soon as possible and return the substitute
to its original clips. It is a good idea
to purchase a set of spare fuses and keep them
in your vehicle for emergencies.
If the new fuse immediately blows out, there is a problem with
the electrical system. Have your Lexus dealer correct it as
soon as possible.
CAUTION
Never use a fuse with a higher amperage rating, or any
other object, in place of a fuse. This may cause
extensive damage and possibly a fire.
